USE AND INSTALLATION MANUAL

SEALED PELLET STOVE

WALL AIR 8 M1

WALL AIR 8 UP! M1

PART 2 - OPERATION AND CLEANING

Instructions in English

Table of Contents

Summary of Contents for MCZ WALL AIR 8 M1

Page 1 USE AND INSTALLATION MANUAL SEALED PELLET STOVE WALL AIR 8 M1 WALL AIR 8 UP! M1 PART 2 - OPERATION AND CLEANING Instructions in English...
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS ....................II 10-FIRST START-UP .....................3 11-SYSTEM REQUIREMENTS ..................4 12-FIRST APP START-UP AND ASSOCIATION WITH MCZ STOVES ........5 13-STOVE ACCESSORY CONFIGURATION ................8 14-COMFORT SET ......................10 15-EMERGENCY PANEL ....................16 16-EMERGENCY PANEL FUNCTIONS ................17 17-MANUAL CONFIGURATION ..................18 18-APP FUNCTIONS....................19...
Page 3: 10-First Start-Up
10-FIRST START-UP WARNINGS BEFORE START-UP GENERAL WARNINGS Remove all parts that may burn from the brazier and the glass (manual, various adhesive labels or any polystyrene). Check that the brazier is positioned correctly and rests properly on the base. The first start-up may not be successful as the feed screw is empty and does not always manage to load the brazier with the required amount of pellets in time to light the flame.
Page 4: 11-System Requirements
11-SYSTEM REQUIREMENTS The MCZ Maestro App is already available on the “Handheld remote control” accessory or will be available in various playstores. STOVE Equipped with MAESTRO system OPERATION For the utmost versatility of use, two Wi-Fi modules have been designed, supporting priority connection with your smartphone and/or handheld remote control (optional).
Page 5: 12-First App Start-Up And Association With Mcz Stoves
12-FIRST APP START-UP AND ASSOCIATION WITH MCZ STOVES The app lets you communicate with MCZ stoves using two technologies: • home Wi-Fi • remote Wi-Fi HOME WI-FI Point-to-point connection between the telephone and the stove, to communicate with the stove without relying on routers or internet connections.
Page 6 12-FIRST APP START-UP AND ASSOCIATION WITH MCZ STOVES IMPORTANT!! Do not lose or remove the QR code from the stove. If the stove is reset and/or the smartphone and/or handheld remote control are changed, you must have the QR code and passwords available to configure the system.
Page 7 12-FIRST APP START-UP AND ASSOCIATION WITH MCZ STOVES MANUAL MODE The QR code and the passwords are located at the back of the stove and in the warranty. In this case, the codes must be used. EXAMPLE OF QR AND PASSWORD LABEL If the stove cannot be configured using the QR code, it can be done using the DIRECT or REMOTE key.
Page 8: 13-Stove Accessory Configuration
In order to configure the accessories, the mobile phone must be near the accessories. CONFIGURATION OF REMOTE WI-FI MODULE FROM MCZ MAESTRO APP To do this connect to the stove in home mode through the app. From the “settings” / “basic settings” menu, select the configure accessories item: if there are still accessories to be configured, the two keys can be selected.
Page 9 13-STOVE ACCESSORY CONFIGURATION CONFIGURATION OF WI-FI TEMPERATURE PROBE FROM MCZ MAESTRO APP The Wi-Fi temperature probe (ACCESSORY) is supplied without batteries. From when the batteries are inserted, the probe can be configured within the next 8 minutes. Therefore insert the three AA batteries shortly before you are ready to proceed with the configuration.
Page 10: 14-Comfort Set
14-COMFORT SET Maestro technology allows the heater to express its utmost potential with even an easier and more intuitive use. A real integrated micro- computer communicates with your smartphone and further improves the performances of the heater that continues to perfectly work even in non-ideal conditions.
Page 11 14-COMFORT SET COMFORT SET The COMFORT set can be selected by typing the relative symbol in the screen that is also highlighted through the notches on the selection ring. The product works in automatic mode, it is not possible to increase the ventilation. To set the desired temperature, press the centre of the ring at the indicated temperature and the pop-up appears to perform the setting.
Page 12 14-COMFORT SET OVERNIGHT SET The OVERNIGHT set can be selected by typing the relative symbol in the screen that is also highlighted through the notches on the selection ring. The user has the possibility to manage ventilation and temperature. To set the desired temperature, press the centre of the ring at the indicated temperature and the pop-up appears to perform the setting. NO POWER VENTILATION SET...
Page 13 14-COMFORT SET MANUAL SET The MANUAL set can be selected by typing the relative symbol in the screen that is also highlighted through the notches on the selection ring. The user has the ability to manage ventilation and power. To set the desired parameters, press the centre of the ring at the indicated temperature and the pop-up appears to perform the setting. Technical Dept.
Page 14 14-COMFORT SET DYNAMIC SET The DYNAMIC set can be selected by typing the relative symbol in the screen that is also highlighted through the notches on the selection ring. The user has the possibility to manage ventilation and temperature. To set the desired temperature, press the centre of the ring at the indicated temperature and the pop-up appears to perform the setting.
Page 15 14-COMFORT SET POWER SET The POWER set can be selected by typing the relative symbol in the screen that is also highlighted through the notches on the selection ring. The user has the possibility to manage ventilation and temperature. To set the desired parameters, press the centre of the ring at the indicated temperature and the pop-up appears to perform the setting. IF YOU GET OUT OF THE POWER MODE BEFORE THE END OF THE 20 MINUTES, YOU CANNOT REACTIVATE BEFORE AN HOUR.
Page 16: 15-Emergency Panel
15-EMERGENCY PANEL At the back of the stove, there is the emergency panel that provides some information about the stove status. A - MULTICOLOUR LED B - BUTTON - functions Green LED that indicates: Turns the product ON • Stove in OPERATION Turns the product OFF Red LED that indicates: Changes the operating POWER:...
Page 17: 16-Emergency Panel Functions
16-EMERGENCY PANEL FUNCTIONS The emergency panel provides the following information: • through a multicolour LED (A) it provides information about the stove status (off-starting-up-in operation-cooling for shutdown-in error conditions) • using the button (B) the following functions can be activated: •...
Page 18: 17-Manual Configuration
(on the QR code label) Once the Wi-Fi probe is connected, you can configure the stove to use the remote sensor; to do so, open the MCZ MAESTRO APP, connect to your previously configured stove, use the shortcut by clicking on the temperature indicator at the top right of the app screen and select the “Wi-Fi probe”...
Page 19: 18-App Functions
18-APP FUNCTIONS Once the devices are configured, the App will automatically try to connect to the last device used. If connection is successful, the App will display the “I/O” screen. It is possible to switch on and use all stove functions from here. If it tries to connect to the last device connected and something goes wrong, the App will display the list of configured devices.
Page 20 18-APP FUNCTIONS FAN SCREEN This screen manages the fan power of each single fan. There are 5 power levels that can be set. Each fan has the option of automatic operation and the option to switch off the fan If the ventilation is set MANUALLY, the function which limits the maximum power of the stove according to the ventilation is enabled. COMFORT AIR (3 FANS): maximum power level = total of the levels of ventilation/2 AIR: maximum power level = twice the total of the levels of ventilation...
Page 21: 19-Side Drop Down Menu
19-SIDE DROP DOWN MENU SET SCREEN The menu can be selected on the top left of the three lines and includes SHORTCUTS (shortcut and / or quick settings) • LANGUAGE • LIST OF DEVICES • CHRONOTHERMOSTAT • ECOSTOP SETTINGS • BASIC SETTINGS •...
Page 22: 20-Shortcuts Settings / Rapid Settings
20-SHORTCUTS SETTINGS / RAPID SETTINGS SHORTCUTS (shortcut and / or quick settings) • LANGUAGE • LIST OF DEVICES • CHRONOTHERMOSTAT • ECOSTOP LANGUAGE SCREEN Entering the side menu, select LANGUAGE and the system will display all the languages available. Select the desired language. Press the SAVE button to confirm the chosen language.
Page 23 20-SHORTCUTS SETTINGS / RAPID SETTINGS LIST OF DEVICES This screen displays which devices have been configured. Only the device depicting the icon of a stove next to it can be selected. From the menu next to the configured device it is possible to access the MODIFY or DELETE function. Technical Dept.
Page 24 20-SHORTCUTS SETTINGS / RAPID SETTINGS CHRONOTHERMOSTAT Temperature selection option (T1-T2-T3) Option to set the weekly programs. Option to set different temperatures for different days of the week and different time bands.
Page 25 20-SHORTCUTS SETTINGS / RAPID SETTINGS ECOSTOP From the ECO STOP menu, it is possible to set and/or edit delayed activation (min) and Reignition hysteresis (C°). ECO is an automatic mode with the only difference that if the set temperature is reached and remains so for the time (in minutes) that was selected from the delayed activation drop-down menu (value ranging between 5 and 30 minutes), the product switches off and remains in stand-by until the room temperature drops below the desired temperature (hysteresis frequency ranges between 2 and 5 minutes).
Page 26: 21-Menu Settings
21-MENU SETTINGS BASIC SETTINGS • DATE AND TIME • BOARD INPUTS • CONFIGURE WIFI PROBE • BEEP ON / OFF • ACCESSORIES DATE AND TIME Press the DATE AND TIME key to access the screen to edit data. After setting the data, press SAVE and exit the screen.
Page 27 21-MENU SETTINGS BOARD INPUTS Room input is used to set the Wi-Fi probe, thermostat or room probe. Click the drop-down menu to select the desired option. Technical Dept. - All rights reserved - Reproduction prohibited...
Page 28 21-MENU SETTINGS CONFIGURE WIFI PROBE This screen configures the frequency (in minutes) and shows the last connection made.
Page 30 21-MENU SETTINGS ACCESSORIES Entering the ACCESSORIES menu it is possible to CONFIGURE: • REMOTE CONFIGURATION • T PROBE CONFIGURATION Refer to Chapter 3 (“Configure stove accessories”) for the mode. REMOTE CONFIGURATION CONFIGURE PROBE T°...
Page 31: 22-Operation Menu
22-OPERATION MENU MODE • CHRONOTHERMOSTAT • ECO STOP • SLEEP CHRONOTHERMOSTAT Temperature selection option (T1-T2-T3) Option to set the weekly programs. Option to set different temperatures for different days of the week and different time bands. Technical Dept. - All rights reserved - Reproduction prohibited...
Page 32 22-OPERATION MENU ECOSTOP From the ECO STOP menu, it is possible to set and/or edit delayed activation (min) and Reignition hysteresis (C°). ECO is an automatic mode with the only difference that if the set temperature is reached and remains so for the time (in minutes) that was selected from the delayed activation drop-down menu (value ranging between 5 and 30 minutes), the product switches off and remains in stand-by until the room temperature drops below the desired temperature (hysteresis frequency ranges between 2 and 5 minutes).
Page 33 22-OPERATION MENU SLEEP Sleep mode allows to quickly set the time when the product must switch off. This function is only available in MAN and AUTO mode. To enable or disable the SLEEP function, touch the relative key. Technical Dept. - All rights reserved - Reproduction prohibited...
Page 34: 23-Settings Menu
23-SETTINGS MENU SETTINGS • FEED SCREW ON • RECIPES • SUMMER/WINTER • PELLET SENSOR • BRAZIER CLEANING FEED SCREW ON This function, which can only be activated with the stove off, enables you to load pellets into the loading system (feed screw), and is used every time pellets in the hopper run out.
Page 35 23-SETTINGS MENU Modifying the pellet recipe and air recipe This function is for adapting the stove to the type of pellet in use. In fact, since there are many types of pellets on the market, operation of the stove varies significantly depending on the good or poor quality of the fuel. The amount of pellets in the brazier can be increased or reduced: • If the pellets tend to jam in the brazier due to an excess of fuel • If the flame is increasingly higher even at low power values...
Page 36 23-SETTINGS MENU SUMMER/WINTER Option to select the operating season.
Page 37 23-SETTINGS MENU PELLET SENSOR The pellet sensor is used to measure the level of pellets in the hopper. It can be activated from the side menu, SETTINGS after having assembled the sensor on the hopper and carried out the appropriate connection in the card (see next page). Technical Dept.
Page 38 23-SETTINGS MENU ASSEMBLING PELLET LEVEL SENSOR The pellet sensor is a fuel reserve indicator that warns the user that the pellets are finishing. With the tank empty, lift the pellet loading cover and manually remove the cap “J” fitted inside, then insert the pellet level sensor “K”...
Page 39 23-SETTINGS MENU BRAZIER CLEANING Only for “MATIC” products with automatic brazier cleaning system. Press “ENABLE” to set a complete cleaning cycle for the product. Technical Dept. - All rights reserved - Reproduction prohibited...
Page 40: 24-Software Version
24-SOFTWARE VERSION SOFTWARE VERSION The SOFTWARE VERSION option is found in the SET menu. Through this item it is possible to know all the stove information e.g. Database and app version...
Page 41: 25-Technical Menu
25-TECHNICAL MENU TECHNICAL MENU To enter the TECHNICAL MENU, select the three dashes at the top, scroll to the end of the drop-down menu and select the item. To enter the functions it is necessary to enter a Password (available for authorized technicians) and press OK. Technical Dept.
Page 42 24-SOFTWARE VERSION The main functions that can be changed and/or controlled from the technical menu are: • PARAMETERS • ACTIVE ON/OFF • SYSTEM T° • DIAGNOSTICS • SELECT DATABASE • FACTORY RESET • SERVICE RESET • LAST ALARMS • WORKING HOURS...
Page 44: 27-Safety Devices
27-SAFETY DEVICES SAFETY DEVICES The product is fitted with the following safety devices. SMOKE TEMPERATURE PROBE It detects the temperature of the smoke, thereby enabling start-up or stopping the product when the smoke temperature drops below the preset value. PELLET HOPPER TEMPERATURE PROBE If the temperature exceeds the preset safety value, it immediately stops the product, which must cool down before the stove is restarted.
Page 45: 28-Alarms
28-ALARMS ALARM SIGNALLING In the event an operating anomaly occurs the stove starts switching off due to the alarm and informs the user of the type of fault that has taken place via a 3 digit code which stays displayed on the rear emergency panel. The alarm is indicated permanently by the relative 3 digit code, by a flashing red LED that lights up on the emergency panel and an intermittent sound signal for the first 10 minutes of the alarm.
Page 46 27-SAFETY DEVICES Faulty gear motor driving sensor (PWM) Contact an authorised service centre. Electronic control unit overheating The structure is too hot because the product has been used for too long at the maximum power or there is poor ventilation. When the stove is sufficiently cold, press button B on the control panel or OFF on the remote control to cancel alarm A13.
Page 47 If these causes are excluded, check and if necessary clean the smoke duct and flue (it is recommended for this operation to be carried out by an MCZ qualified technician). The product can be switched on again only after having eliminated the cause permanently.
Page 48 27-SAFETY DEVICES In the event that alarm A21 is triggered often, please note that: Open stove door Close the door Open fuel loading hatch Close the hatch. SAFETY DE- Lower the fuel level in the hopper. VICES TRIP Air pressure switch Draught difficulties or brazier clogged.
Page 49 27-SAFETY DEVICES (according to the technical data sheet found in the user and maintenance manual), adjustments may be required in worse draught conditions (also due to the position of the flue in areas that are particularly subject to adverse weather such as prevailing winds, snow, northern exposure, etc.) so as to always guarantee the required negative pressure inside the hopper.
Page 50 27-SAFETY DEVICES NEGATIVE PRESSURE INSIDE THE HOPPER WITH FACTORY-SET PARAMETERS AND A DRAUGHT OF 5 Pa (MINIMUM RECOMMENDED) POWER VALUES 13.7/14.2 Pa 15.1/15.6 Pa 17.1/17.5 Pa 19.1/19.5 Pa 22.0/22.2 Pa Draught 6 kW 95°C 110°C 125°C 141°C 165°C Smoke temperature 13.8/14.3 Pa 15.6/16.1 Pa 17.8/18.0 Pa...
Page 51: 29-Recommendations For Safe Use
29-RECOMMENDATIONS FOR SAFE USE ONLY CORRECT INSTALLATION AND APPROPRIATE MAINTENANCE AND CLEANING OF THE APPLIANCE CAN GUARANTEE CORRECT OPERATION AND SAFE USE OF THE PRODUCT. We would like to inform you that we are aware of cases of malfunctioning of domestic pellet-fuelled heating products, mainly due to incorrect installation and use, as well as inadequate maintenance.
Page 52: 30-Cleaning
30-CLEANING EXAMPLE OF A CLEAN BRAZIER EXAMPLE OF A DIRTY BRAZIER Only by properly servicing and cleaning the product is it possible to ensure its safety and correct operation. ATTENTION! All the cleaning operations of all parts must be performed with the product completely cold and the plug disconnected.
Page 53 30-CLEANING REMEMBER THAT ONLY A CORRECTLY POSITIONED AND CLEAN BRAZIER CAN GUARANTEE SAFE IGNITION AND OPTIMAL OPERATION OF YOUR PELLET PRODUCT. IN CASE OF FAILED IGNITION AND AFTER ANY OTHER BLOCK STATE OF THE PRODUCT, IT IS ESSENTIAL TO EMPTY THE BRAZIER BEFORE EVERY RESTART For the brazier to be cleaned properly, remove it from its housing completely and thoroughly clean all the holes and the grate on the bottom.
Page 54 In the event of breakage it must be replaced. ATTENTION! Never let the stove work without the air filter fitted. MCZ cannot be held liable for any damage caused to the internal components if this requirement is not complied with.
Page 55 30-CLEANING PERIODIC CLEANING PERFORMED BY A QUALIFIED TECHNICIAN CLEANING THE HEAT EXCHANGER AND THE LOWER COMPARTMENT Half-way through the winter season, but especially at the end, the compartment through which the exhaust smoke passes will need to be cleaned. This cleaning process is mandatory in order to facilitate the general removal of all combustion residue, before it becomes very difficult to remove it due to moisture compacting it over time.
Page 56 30-CLEANING CLEANING THE EXCHANGER CLEANING THE UPPER COMPARTMENT Clean the upper exchanger when the stove is cold and without the cladding in question. After cleaning the lower compartment (see previous paragraph), use a 1 metre long flexible brush to scrape the walls of the firebox (see arrow) to make the ash fall into the lower compartment.
Page 57 30-CLEANING Use a flexible brush to scrape the walls of the firebox (see arrow - respectively to the right and to the left of the firebox) to make the ash fall into the lower compartment. Use a vacuum cleaner nozzle to vacuum up any remaining ash and dust on the exchanger (see arrow). Then thoroughly clean the lower exchanger, replace any gaskets if needed, and reassemble.
Page 58 30-CLEANING CLEANING THE SMOKE EXPULSION SYSTEM AND GENERAL CHECKS Clean the smoke outlet system, especially around the Tee fittings, elbows and any horizontal sections of the smoke duct. For information on periodically cleaning the flue, contact a skilled chimney sweep. Check the seal of the ceramic fibre gaskets on the door of the stove.
Page 59 30-CLEANING PERIODICAL CHECK OF THE DOOR CLOSURE Make sure the door closure ensures a correct sealing action (with the “paper sheet” test) and that when the door is closed, the closing block (X in the figure) does not protrude from the sheet metal to which it is secured. For some products it will be necessary to disassemble the cladding to be able to assess the anomalous protrusion of the block when the door is closed.
Page 60 30-CLEANING SHUTDOWN (end of season) At the end of each season, before switching the product off, it is recommended to remove all the pellets from the hopper with a vacuum cleaner with a long pipe. We recommend removing the unused pellets from the hopper because they can retain moisture. Disconnect any combustion air ducting that can lead to moisture inside the combustion chamber but, above all, ask the specialised technician to refresh the paint inside the combustion chamber with the special silicone spray paints (available at any store or Technical Assistance Centre) during the necessary annual end of season scheduled maintenance operations.
Page 61: 31-Problems / Causes / Solutions
31-PROBLEMS / CAUSES / SOLUTIONS ATTENTION! All repairs must only be carried out by a specialised technician, with the product switched off and unplugged. ANOMALY POTENTIAL CAUSES SOLUTIONS The pellets are not fed into the The pellet hopper is empty. Fill the hopper with pellets.
Page 62 31-PROBLEMS / CAUSES / SOLUTIONS ANOMALY POTENTIAL CAUSES SOLUTIONS The product works for a few minutes Start-up phase is not completed. Repeat the ignition stage. and then switches off. Temporary power cut. Switch it back on. Clogged smoke duct. Clean smoke duct. Faulty or broken temperature probes.
Page 63 31-PROBLEMS / CAUSES / SOLUTIONS ANOMALY POTENTIAL CAUSES SOLUTIONS The air fan does not switch on. The product has not reached the Wait. temperature. The remote control does not work. The remote control battery is flat. Replace the battery. Remote control faulty. Replace the remote control.
Page 64: 32-Circuit Board
32-CIRCUIT BOARD 1. SMOKE FAN ENCODER 9. AIR FAN 1 2. SOFTWARE UPDATE (USB) 10. AIR FAN 2 (IF ANY) 3. EMERGENCY PANEL 11. AIR FAN 3 (IF ANY) 4. ROOM PROBE/EXTERNAL THERMOSTAT 12. HOPPER OVERLOAD CUT-OUT 5. SMOKE TEMPERATURE PROBE 13.
Page 68 MCZ GROUP S.p.A. Via La Croce n°8 33074 Vigonovo di Fontanafredda (PN) – ITALY Telephone: 0434/599599 a.s. Fax: 0434/599598 Internet: www.mcz.it e-mail: mcz@mcz.it 8901921300 REV.0 03/12/2019...
