Owner's Manual
Original Instructions
Air Conditioners
DC Inverter U-Match Series Cassette Type Unit
Models:
Indoor Unit
GUD35T/A-S
GUD50T/A-S
GUD71T/A1-S
GUD71T/A-S
GUD100T/A-S
GUD125T/A-S
GUD140T/A-S
GUD160T/A-S
Outdoor Unit
GUD35W/A-S
GUD50W/A-S
GUD71W/A1-S
GUD71W/A-S
GUD100W/A-S
GUD125W/A-S
GUD140W/A-S
GUD160W/A-S
GUD125W/A-X
GUD140W/A-X
GUD160W/A-X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U-Match GUD35T/A-S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gree U-Match GUD35T/A-S

Summary of Contents for Gree U-Match GUD35T/A-S

  • Page 1 Owner's Manual Original Instructions Air Conditioners DC Inverter U-Match Series Cassette Type Unit Models: Indoor Unit Outdoor Unit GUD35T/A-S GUD35W/A-S GUD50T/A-S GUD50W/A-S GUD71T/A1-S GUD71W/A1-S GUD71T/A-S GUD71W/A-S GUD100T/A-S GUD100W/A-S GUD125T/A-S GUD125W/A-S GUD125W/A-X GUD140T/A-S GUD140W/A-S GUD140W/A-X GUD160T/A-S GUD160W/A-S GUD160W/A-X...
  • Page 2 To Users Thank you for selecting Gree’s product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and...
  • Page 3 (10) The final right to interpret for this instruction manual belongs to Gree Electric Appliances Inc. of Zhuhai. Exception Clauses...

  • Page 4: Table Of Contents

    Contents 1 Safety Notices (Please be sure to abide) ........1 2 Product Introduction ................. 6 2.1 Overall Layout ................6 2.2 Product Operating Range ............7 2.3 Standard Accessories .............7 3 Installation ..................8 3.1 Installation Preparation ............8 3.2 Unit Installation ..............17 3.3 Electrical Installation ............

  • Page 5: Safety Notices (Please Be Sure To Abide)

    DC Inverter U-Match Series Cassette Type Unit 1 Safety Notices (Please be sure to abide) SPECIAL WARNING: Do not pierce or burn. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. Be aware that refrigerants may not contain an odor.
  • Page 6 DC Inverter U-Match Series Cassette Type Unit PROHIBITED (1) The air conditioner should be grounded to avoid electric shock. Do not connect the ground wire to gas pipe, water pipe, lightning arrester or telephone wire. (2) The appliance shall be stored in a well-ventilated area where the room size corresponds to the room area as specified for operation.
  • Page 7 DC Inverter U-Match Series Cassette Type Unit WARNING Please install the air conditioner in a secure place that can withstand the weight of air conditioner. Insecure installation may cause the air conditioner falling down and lead to injury. (10) Be sure to adopt independent power circuit. If the power cord is damaged, it must be repaired by the manufacturer, service agent or other professional agents.
  • Page 8 DC Inverter U-Match Series Cassette Type Unit WARNING (24) Do not make the air conditioner wet or electric shock may be lead; Ensure that the air conditioner will not be cleaned by water rinsing under any circumstance. NOTICE Do not put a finger or other objects into the air inlet or air return grill. Please adopt safety protection measures before touching the refrigerant pipe;...
  • Page 9 DC Inverter U-Match Series Cassette Type Unit OBSERVED If wired control is to be used, it should be connected first before powering up the unit, otherwise the wired control may not be able to use. When installing the indoor unit, keep it away from television, wireless waves, and fluorescent.

  • Page 10: Product Introduction

    DC Inverter U-Match Series Cassette Type Unit 2 Product Introduction 2.1 Overall Layout NOTICE: The connection pipe, drain pipe, power cord, for this unit should be prepared by the user.

  • Page 11: Product Operating Range

    DC Inverter U-Match Series Cassette Type Unit 2.2 Product Operating Range Cooling Heating Outdoor temperature DB(°C) -15~48 -15~24 Indoor temperature DB/WB(°C) 32/23 27/- (Maximum) 2.3 Standard Accessories Indoor Unit Accessories Name Appearance Q'ty Usage To connect with the Drain Hose hard PVC drain pipe To fix the installation Bolt with Washer...

  • Page 12: Installation

    DC Inverter U-Match Series Cassette Type Unit Indoor Unit Accessories Name Appearance Q'ty Usage To prevent the communication wire from reaching out the Flannelette electric raceway（only 35/50） Connect the panel and Bolt Assembly body（only 35/50） Outdoor Unit Accessories Name Appearance Q'ty Usage To plug the unused drain...
  • Page 13 DC Inverter U-Match Series Cassette Type Unit Selection of Installation Location for Indoor Unit (Select a location pursuant to the following condition). (1) Air inlet and outlet of the indoor unit should be away from obstacles to make sure the unit’s air flow can reach the entire room. Do not install the unit in a kitchen or a laundry.
  • Page 14 DC Inverter U-Match Series Cassette Type Unit fan and lead to insufficient air flow volume and thus affecting the unit’s performance. (7) Install the outdoor unit at a place that is convenient for it to be connected to the indoor unit. (8) Away from any object that may get the air conditioner generating noise.
  • Page 15 DC Inverter U-Match Series Cassette Type Unit NOTICE Drilling of ceiling opening and installation of air conditioner must be performed by professionals! Unit: mm Item Model GUD35T/A-S GUD50T/A-S GUD71T/A1-S GUD71T/A-S GUD100T/A-S GUD125T/A-S GUD140T/A-S GUD160T/A-S (2) Outdoor units GUD35W/A-S;GUD50W/A-S;GUD71W/A1-S;GUD71W/A-S;GUD100W/A-S:...
  • Page 16 DC Inverter U-Match Series Cassette Type Unit GUD125W/A-S;GUD125W/A-X;GUD140W/A-S;GUD140W/A-X; GUD160W/A-S; GUD160W/A-X: Unit: mm Dimensions Model GUD35W/A-S GUD50W/A-S GUD71W/A1-S GUD71W/A-S GUD100W/A-S 1002 GUD125W/A-S GUD125W/A-X GUD140W/A-S GUD140W/A-X GUD160W/A-S GUD160W/A-X...
  • Page 17 DC Inverter U-Match Series Cassette Type Unit 3.1.3 Diagram of Unit Installation Space and Location (1) Diagram of installation space and location for outdoor unit (Notice: for best performance of the outdoor unit, make sure its installation space conforms to the following installation dimensions). 1) When one outdoor unit is to be installed.
  • Page 18 DC Inverter U-Match Series Cassette Type Unit 2) When two or more outdoor units are to be installed side by side. ≥400 ≥400 (mm) — ≥300 ≥300 ≥1000 A,B,C — ≥300 ≥300 ≥1000 ≥1000 A,B,C,E — ≥2000 — ≥2000 ≥1000 ≥300 ≥2000 <H...
  • Page 19 DC Inverter U-Match Series Cassette Type Unit 3) When outdoor units are installed in rows. ≥400 ≥400 (mm) ≤1/2H b≥250 ≤H b≥300 1/2H<H >H Prohibited...
  • Page 20 DC Inverter U-Match Series Cassette Type Unit 4) When outdoor units are installed one above another. Unit: mm (2) Diagram of installation location and space for indoor unit (Notice: for the best performance of indoor unit, make sure its installation space conforms to the following installation dimensions).

  • Page 21: Unit Installation

    DC Inverter U-Match Series Cassette Type Unit Model H(mm) GUD35T/A-S GUD50T/A-S GUD71T/A1-S GUD71T/A-S GUD100T/A-S GUD125T/A-S GUD140T/A-S GUD160T/A-S 3.2 Unit Installation 3.2.1 Indoor Unit Installation In order to make the front panel cover 20mm of the ceiling, the distance between the ceiling and the unit should be 35mm or less. If the distance between the ceiling and the unit is above 35mm, add some ceiling material to shorten the distance.
  • Page 22 DC Inverter U-Match Series Cassette Type Unit (2) Installing the Main Body Unit. 1) Install the hoisting stand on the hoisting screw by using nuts and gaskets at both the upper and lower sides of the hoisting stand. To prevent the gasket from breaking off, a gasket anchor board can be helpful.
  • Page 23 DC Inverter U-Match Series Cassette Type Unit 3.2.1.2 Leveling The water level test must be done after installing the indoor unit to make the unit is horizontal, as shown below. Horizontal tester 3.2.2 Outdoor Unit Installation (1) If the outdoor unit is installed on a solid ground such as concrete, use M10 screw bolts and nuts to secure the unit and make sure the unit stands erect and level.
  • Page 24 DC Inverter U-Match Series Cassette Type Unit 3.2.3 Connection Pipe Requirement 3.2.3.1 Installation Notice and Requirement on Connection Pipe Installation method: Connect the connection pipes first to the indoor unit and then to the outdoor unit. When bending a connection pipe, be careful not to damage the pipe.
  • Page 25 DC Inverter U-Match Series Cassette Type Unit The requirement on the adding of oil return bend is as below: (1) Outdoor unit is beneath the indoor unit. There’s no need to add non-return bend at the lowest or highest position of the vertical pipe, as shown below: Indoor unit System gas pipe...
  • Page 26 DC Inverter U-Match Series Cassette Type Unit Dimensions for the making of oil return bend are as follows: B(mm) C(mm) Ф9 ≥20 ≤150 Ф12 ≥26 ≤150 Ф16 ≥33 ≤150 3.2.3.2 Pipe Flaring (1) Cut the connection pipe with a pipe cutter. (2) The mouth of connection pipe should face downward.
  • Page 27 DC Inverter U-Match Series Cassette Type Unit (2) Do not bend the pipes in an angle more than 90°. (3) If the pipe is repeatedly bent or extended, it will become hard and difficult to be bent or extended. So do not bend or extend the pipe for more than 3 times.
  • Page 28 DC Inverter U-Match Series Cassette Type Unit Pipe Diameter(In) Tightening Torque(N·m) 1/4" 15-30 3/8" 35-40 1/2" 45-50 5/8" 60-65 3/4" 70-75 7/8" 80-85 Screw on the flare nut of the flaring connecting pipe on the outdoor unit valve. The method of screwing the flare nut is the same with that for indoor unit. Gas pipe Liquid pipe Pipe...
  • Page 29 DC Inverter U-Match Series Cassette Type Unit 3.2.4 Connection Pipe Vacuum Pumping NOTICE Make sure the outlet of vacuum pump is away from fire source and is well- ventilated. (1) Remove the caps of the liquid valve, gas valve and also the service port. (2) Connect the hose at the low pressure side of the manifold valve assembly to the service port of the unit’s gas valve, and meanwhile the gas and liquid valves should be kept closed in case of refrigerant leak.
  • Page 30 DC Inverter U-Match Series Cassette Type Unit Pressure gauge (Low-pressure) gauge manifold Pressure gauge (Hi-pressure) Switch (Low-pressure) Switch (Hi-pressure) Connection pipe Connection pipe (to indoor unit) Liquid valve Gas valve Service pipe Hose Service port Hose with the valve pin Vacuum pump NOTICE: For large-size units, there are maintenance ports for liquid valve and gas valve.
  • Page 31 DC Inverter U-Match Series Cassette Type Unit (2) It is not allowed to connect the condensate drain pipe into rain pipe to prevent rain water from pouring in and cause property loss or personal injury. (3) Condensate drain pipe should be connected into special drain system for air conditioner.
  • Page 32 DC Inverter U-Match Series Cassette Type Unit During the installation, distance from soft drain Insulate the pipe clamp and the pipe to the gasket is A mm when the bolt is drain hose using heat insulation tightened. It is not allowed to apply PVC or sponge.
  • Page 33 DC Inverter U-Match Series Cassette Type Unit (2) If the outdoor unit is above the indoor unit, arrange the pipeline according to the following diagram. 1) Wind the insulating tape from bottom to top. 2) The whole pipeline should be wound together to avoid water returning to the room.
  • Page 34 DC Inverter U-Match Series Cassette Type Unit 3.2.6.3 Notice on Drain Lift Pipe (1) The drain lift pipe should be 1000mm or less away from ground, as shown below. (2) If multiple drain pipes are to be converged, please install according to the following process.
  • Page 35 DC Inverter U-Match Series Cassette Type Unit 3) Install horizontal pipe as shown in the right figure. 3-way connection of Connection of drain elbow Connection of horizontal pipe Drainage pipe joint 3.2.6.4 Check Drainage After the pipeline work is finished, check whether the drainage can go smoothly.
  • Page 36 DC Inverter U-Match Series Cassette Type Unit 3.2.7 Installing the Front Panel As shown below, take off the 4 corner covers from the front panel and loose the hexagon screw bolts on the 4 fasteners to the maximum. The position marked with “PIPING SIDE”...
  • Page 37 DC Inverter U-Match Series Cassette Type Unit Notice (1) Improper screw looseness will lead to the following problem. Gas leakage Gas leakage of ceiling Condensate Water drops (2) After the screws are tightened, if there is still a gap between the ceiling and the decorative front panel, adjust the height of the unit again (as shown below).
  • Page 38 DC Inverter U-Match Series Cassette Type Unit Match the corresponding slots WARNING After installing the panel, the insulated protective cover with the thickness of 1mm shall be used to wrap the wiring terminal, Tighten the insulated glue cover on both sides with bonding tie to fix it.

  • Page 39: Electrical Installation

    DC Inverter U-Match Series Cassette Type Unit 3.3 Electrical Installation 3.3.1 Requirement and Notice on Electrical Installation WARNING: The electrical installation for the air conditioner should observe the following requirements: ① The electrical installation must be conducted by professionals in compliance with local laws and regulations and the instructions in this manual.
  • Page 40 DC Inverter U-Match Series Cassette Type Unit cables, please contact Gree’s local service center. ⑩ Wiring terminals should be connected firmly to the terminal board. Loose connection is forbidden. ⑪ After the electrical installation is finished, please use wire clamps to secure the power cord, connection wire of indoor and outdoor units and the communication cords.
  • Page 41 DC Inverter U-Match Series Cassette Type Unit plugged or unplugged. ③ Circuit breaker and power cord specifications listed in the above table are determined based on the maximum power input of the units. ④ Supply cords of parts of appliances for outdoor use shall not be lighter than polychloroprene sheathed flexible cord (code designation 60245 IEC 57).
  • Page 42 DC Inverter U-Match Series Cassette Type Unit 10mm of the insulation layer. 2) Use a screwdriver to unscrew the terminal screw on the terminal board. 3) Use a round terminal fastener or clamp to fix the round terminal firmly on the peeled wire end. 4) Locate the round terminal conduit.
  • Page 43 DC Inverter U-Match Series Cassette Type Unit WARNING (1) Before working, please check whether the indoor and outdoor units are powered (2) Match the terminal numbers and wire colors with the colors indicated in the indoor unit. (3) Wrong wire connection may burn the electrical components. (4) Connect the wires firmly to the wiring box.
  • Page 44 DC Inverter U-Match Series Cassette Type Unit GUD35T/A-S+GUD35W/A-S GUD50T/A-S+GUD50W/A-S ① Power cord 3×1.5mm ② Power cord 3×1.0mm ③ Communication Cords 2×0.75mm ④ Communication Cords 2×0.75mm GUD71T/A1-S+GUD71W/A1-S GUD71T/A-S+GUD71W/A-S GUD100T/A-S+GUD100W/A-S ① Power cord 3×2.5mm ② Power cord 3×1.0mm ③ Communication Cords 2×0.75mm ④...
  • Page 45 DC Inverter U-Match Series Cassette Type Unit GUD125T/A-S+GUD125W/A-S GUD140T/A-S+GUD140W/A-S ① Power cord 3×4.0mm ② Power cord 3×1.0mm ③ Communication Cords 2×0.75mm ④ Communication Cords 2×0.75mm GUD160T/A-S+GUD160W/A-S ① Power cord 3×6.0mm ② Power cord 3×1.0mm ③ Communication Cords 2×0.75mm ④ Communication Cords 2×0.75mm Three-phase unit: GUD125W/A-X, GUD140W/A-X, GUD160W/A-X.
  • Page 46 DC Inverter U-Match Series Cassette Type Unit GUD125T/A-S+GUD125W/A-X GUD140T/A-S+GUD140W/A-X GUD160T/A-S+GUD160W/A-X ① Power cord 5×1.5mm ② Power cord 3×1.0mm ③ Communication Cords 2×0.75mm ④ Communication Cords 2×0.75mm (5) Electrical wiring of indoor unit. WARNING (1) High and low voltage wires should be led through different rubber rings of the electric box cover.
  • Page 47 DC Inverter U-Match Series Cassette Type Unit 1) Indoor side Take off the electric box cover from the sub-assembly of electric box. Then connect the wires. Connect the connection wires of indoor unit according to the corresponding marks. 2) Outdoor side Remove the big handle/front panel of the outdoor unit and insert one end of the communication cord and the power cord to the terminal board.
  • Page 48 DC Inverter U-Match Series Cassette Type Unit b) Wire routing of unified power supply: Single-phase unit：GUD125W/A-S, GUD140W/A-S, GUD160W/A-S a) Wire routing of separated power supply for single phase.
  • Page 49 DC Inverter U-Match Series Cassette Type Unit b) Wire routing of unified power supply for single phase. Three-phase unit: GUD125W/A-X, GUD140W/A-X, GUD160W/A-X. a) Wire routing of separated power supply for three phase.

  • Page 50: Check After Installation

    DC Inverter U-Match Series Cassette Type Unit b) Wire routing of unified power supply for three-phase. Power cord should be secured along with the right side plate and fixed to the hook with a wire clamp so as to avoid contacting the pipeline. The communication line between indoor and outdoor units should also be laid along with the right side plate but away from the power cord.

  • Page 51: Test Running

    DC Inverter U-Match Series Cassette Type Unit 3.5 Test Running Preparation before connecting the power (1) Power must not be connected if the installation work is not completed. (2) Control circuit is correct and all the wires are firmly connected. (3) Cut-off valves of the gas pipe and liquid pipe are open.

  • Page 52: Maintenance

    DC Inverter U-Match Series Cassette Type Unit 5 Maintenance 5.1 Failures Not Caused by Faults of the AC (1) If your air conditioner fails to function normally, please first check the following items before maintenance: Problem Cause Corrective measure If you turn off the unit and then immediately turn it on, in order to protect the compressor and avoid...
  • Page 53 DC Inverter U-Match Series Cassette Type Unit (2) The following situations are not operation failures. Problem Time of occurrence Cause Mist comes If the unit is running under high from the air During operation. humidity, the wet air in the room conditioner.

  • Page 54: Error Code

    NOTICE: Check the above items and adopt the corresponding corrective measures. If the air conditioner continues to function poorly, please stop the air conditioner immediately and contact Gree’s authorized local service center. Ask our professional service staff to check and repair the unit.
  • Page 55 DC Inverter U-Match Series Cassette Type Unit Number Error code Error Electric box sensor error Compressor overload protection Overload IPM protection DC fan error Driver out-of-step protection Pfc protection Startup failure Compressor phase-sequence protection Power protection IDU and ODU unmatched 4–way valve switch-over error Driver reset protection Over-current protection...

  • Page 56: Unit Maintenance

    DC Inverter U-Match Series Cassette Type Unit NOTICE: When the unit is connected with the wired controller, the error code will be simultaneously shown on it. Instructions to the Error Indicating Lamps on the Panel of the Cassette Type Unit. Power and ON/OFF Indicating Lamp: It goes red when the unit is powered on while it goes white when the unit is started.
  • Page 57 DC Inverter U-Match Series Cassette Type Unit WARNING (5) If you need to replace a component, please ask a professional to repair with a component supplied by the original manufacturer so as to ensure the unit’s quality. (6) Improper operation may get the unit broken, hit by electric shock or cause fire. (7) Do not make the air conditioner wet or electric shock may be lead;...
  • Page 58 DC Inverter U-Match Series Cassette Type Unit How to clean the air filter (4) Fix the 3 cleaners on the filter and then re-install the filter by fitting it into the protruding parts on top of the air intake grill. Pull the handle at the back of the air intake grill to secure the filter.

  • Page 59: After-Sales Services

    (3) Leave the fan running for 2-3 hours to dry the inside of the unit. 5.3.6 Components Replacement Components are available in Gree agency or Gree distributors nearby. 5.4 After-Sales Services Any quality or other issues encountered in the purchased air conditioner,...
