- Page 1 Table of Contents Safety Information What Is Included Specifications Main Power Connection DMX-512 Connection Installation Operation Size & Weight Cleaning & Maintenance Warranty Customer Service...
- Page 2 1. Unit surface may reach high temperature. Allow about 5 minutes after powering the unit before moving. 2. When repositioning rack ears make sure they are securely attached. What is Included Memo Splitter A8 Power Con Type Cable Input Green Screw terminals 3 position Output Orange Screw terminals 3 position 1set Removable rear &...
- Page 3 Specifications Part Numbers Fixture MC1070– Memo Splitter A8 Mechanical Specifications Input DMX Connections: In and Thru RJ45 & In and Thru 3 Port Screw Terminal Output DMX Connectors: 8 output RJ45 & 8 output 3 Port Screw Terminal (can only use one type at a time)
- Page 4 DMX-512 Connection The Memo Splitter A8 is a DMX signal amplifier, distributor and RDM signal regenerator. The unit allows you to split a DMX signal into eight separate signal outputs. Also it boost your DMX signal for extensive cable runs between DMX lighting fixtures.
- Page 5 Operation 1. Connect DMX out from your DMX controller using RJ45 connections or 3 conductor DMX Cable to your DMX in of the Memo Splitter A8 input. 2. Use the eight output channels to send DMX signal to your DMX fix- ture.
- Page 6 Size and Weight 17.62” 5.8” 7.25” 1.75” 19” Fixture Size 19" X 7.25” X 1.75" Fixture Packaged 21.6" X 9.5" X 3" Net Weight Gross Weight Cleaning and Maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electronics checked by an expert every 2 years.
- Page 8 Customer Support Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob- lem. Please visit our website for any other related technical documents. For service related issue please contact our service dept.
