USER MANUAL
Safety Information...................................................................3
Specifications.........................................................................4
Main Power Connection............................................................5
DMX-512 Connection...............................................................5
Installation..........................................................................................6
Operation...........................................................................................6
Cleaning & Maintenance.......................................................................7
Parts List................................................................................................7
Advertisement
Table of Contents
Related Manuals for Mega Lite MC1065
Summary of Contents for Mega Lite MC1065
- Page 1 USER MANUAL Table of Contents Safety Information………………………………………………………….3 Specifications……………………………………………………………….4 Main Power Connection…………………………………………………...5 DMX-512 Connection………………………………………………………5 Installation……………................6 Operation……………….................6 Cleaning & Maintenance...............7 Parts List....................7...
- Page 3 Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 2 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5.
-
Page 4: Specifications
Specifications Part Numbers Fixture MC1065– Mega Merger Splitter Mechanical Specifications Input DMX Connections: 2 front 3-pin & 5 Pin XLR connectors Output DMX Connectors: 4 output / 3-pin & 5 Pin XLR connectors Power Connection: IEC power connection to Edison Fastening System: 1U Rack Mountable Front or Back &... - Page 5 Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: 110V Connection Cable (USA) Cable (EU) Connection Black...
- Page 6 Installation The Mega Merger Splitter can be rack mounted from the front or back or wall mounted. For wall mount, remove the rack ears on the front panel and screw them on the side panels. For rear mounting remove the rack ears from the front and mount them on the rear panels Operation 1.
-
Page 7: Parts List
Should you have further questions , please contact your dealer. Parts List MC1060-mpcb Main PCB Card MC1060-ts Terminator Switch MC1060-ps Power Switch MC1060-pc Power Connection MC1060-xlr3m 3 Pin XLR Male MC1060—xlr3f 3 Pin XLR Female MC1060-xlr5m 5 Pin XLR Male MC1065-merpcb Merger PCB... - Page 8 Mega-Lite 5718 Kenwick St San Antonio, TX 78238 Ph 210-684-2600 Fax 210-855-6279 www.mega-lite.com / info@mega-lite.com...
