USER MANUAL
Safety Information...............................................................3
Specifications.....................................................................4
Main Power Connection........................................................5
DMX-512 Connection...........................................................5
Installation.....................................................................................6
Operation......................................................................................6
Cleaning & Maintenance..................................................................7
Parts List..........................................................................................7
Advertisement
Table of Contents
Related Manuals for Mega Lite Mega Splitter
Summary of Contents for Mega Lite Mega Splitter
- Page 1 USER MANUAL Table of Contents Safety Information………………………………………………………3 Specifications……………………………………………………………4 Main Power Connection………………………………………………..5 DMX-512 Connection…………………………………………………..5 Installation……………..............6 Operation………………..............6 Cleaning & Maintenance..............7 Parts List..................7...
- Page 3 Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 2 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5.
- Page 4 Specifications Part Numbers Fixture MC1060– Mega Splitter Mechanical Specifications Input DMX Connections: Front and Rear 3-pin & 5 Pin XLR connectors Output DMX Connectors: 4 output / 3-pin & 5 Pin XLR connectors Power Connection: IEC power connection to Edison Fastening System: 1U Rack Mountable Front or Back &...
- Page 5 DMX-512 Connection The Mega Splitter is a DMX signal amplifier and distributor. The unit allows you to split a DMX signal into four separate signal outputs. Also it boost your DMX signal for extensive cable runs between DMX lighting fixtures DMX—output...
- Page 6 Installation The Mega Splitter can be rack mounted from the front or back or wall mounted. For wall mount, remove the rack ears on the front panel and screw them on the side panels. For rear mounting remove the rack ears from the front and mount...
- Page 7 Cleaning and Maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electronics checked by an expert every 2 years. The following points have to be considered during the inspection: 1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
- Page 8 Customer Support Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob- lem. Please visit our website for any other related technical documents. For service related issue please contact our service dept.
