H-10853
COLEMAN
OUTDOOR OASIS
®
SCREEN CANOPY – 15 x 13'
TOOL NEEDED
Hammer
CAUTION! Select a level site clear of rocks,
branches and other hard or sharp objects to
install shelter.
• Keep clear of overhead power lines.
• Do not set up shelter under trees because of
potential lightning strikes or falling tree limbs
in inclement weather.
• Secure product with all ground stakes,
guylines and fly attachments for optimal
performance and to prevent property
damage or personal injury.
• For best results in windy conditions, point the
corner of shelter into the wind.
• Tree limbs, tree sap, bird droppings or
moisture steadily dripping off tree limbs
can cause damage to shelter fabric and its
coating.
1.
Partially extend shelter frame. (See Figure 1)
NOTE: Do not unfold frame completely. This
will allow easier fit for draping shelter top over
frame.
PAGE 1 OF 6
1-800-295-5510
uline.com
Two Person Assembly
Recommended
SAFETY
• Do not store shelter without drying it off
thoroughly and brushing off dirt.
• Stakes should be removed by pulling on the
stake itself. Never pull on the shelter to remove
stakes as this could result in property damage
or personal injury.
• Prolonged sun exposure can seriously
damage material and/or cause it to become
discolored.
• Keep all flame and heat sources away from
tent fabric.
• Tent is made of flame-resistant fabric. It is
not fireproof. This tent meets flammability
requirements of CPAI-84. The fabric will
burn if left in continuous contact with any
flame source. The application of any foreign
substances to the tent may render the
flame-resistant properties ineffective.
SETUP
Figure 1
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
0623 IH-10853
