M S-7558 M ainboard

Back Panel

Mouse
Keyboard
Serial Port
M ouse/Keyboard
The standard PS/2 ®
Serial Port
The serial port is a 16550A high speed communications port that sends/ receives 16
bytes FIFOs. You can attach a serial mouse or other serial devices directly to the
connector.
1394 Port (optional)
The IEEE1394 port on the back panel provides connection to IEEE1394 devices.
USB Port
The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard,
mouse, or other USB-compatible devices.
LAN
The standard RJ-45 LAN jack is for connection to
the Local Area Network (LAN). You can connect a
network cable to it.
LED Color LED State
Off
Left Yellow On (steady state)
On (brighter & pulsing) The computer is communicating with another computer on the LAN.
Green Off
Right On
Orange On
2-10
1394 Port
(optional)
USB Port
mouse/keyboard DIN connector is for a PS/2
Condition
LAN link is not established.
LAN link is established.
10 Mbit/sec data rate is selected.
100 Mbit/sec data rate is selected.
1000 Mbit/sec data rate is selected.
LAN
LAN
(optional)
USB Port USB Port
Yellow
Line-In
RS-Out
Line-Out CS-Out
Mic SS-Out
® mouse/keyboard.
Green / Orange
