- Page 1 INSTALLATION MANUAL LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. LT36** LS34** P/NO: MFL66100473 (1201-REV00) Printed in Korea www.lg.com...
-
Page 3: Table Of Contents
LG Hotel Mode Setup . . . . . . . . . . . . . . . . . . -
Page 4: Introduction
The abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’ . The wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators . -
Page 5: Lg Hotel Mode Setup
▼ Previous Use the button to select the LG Hotel Mode Setup . Use the OK button and then button to select Hotel Mode Operation . *When ' Hotel Mode Operation' is set to Yes(Work), all functions of Hotel Mode apply . - Page 6 (3) Setup Menu Display - Decide to enter 'Setup Menu Display' or not in the 'Main Menu' by setting 'Setup Menu Display' as Yes(Enter Possible) or No(Enter Impossible) on the "LG Hotel Mode Setup" OSD . (4) Programme Change - Decide to change channel or not by setting 'Programme Change' as Yes(Change Possible) or No(Change Impossible) when present source is TV .
- Page 7 - Decide whether work the LG remote control or not . - Set to Yes(Work) or No(Do Not Work) . - When ‘LG IR Operation’ is set to NO(Not Work), all keys don’t work . - Although set to No, it can work in Service mode .
- Page 8 Installation Menu LG Hotel Mode Setup (12-2) Programme - If the Input source is DTV or ATV, the set programme is played when the power is turned on . - Only when the Input source is DTV or ATV, it can be entered into the Programme item .
- Page 9 Active De-active Initial Hotel Mode Operation Power On Status Setup Menu Programme Change Input Source Change Menu Display OSD Display LG IR Operation Local Key Operation Max Volume 0~100 DTV Channel Update Auto Manual Auto Power On Default Input Source...
-
Page 10: Tvlink-Loader
In addition to this, TVLink-Loader enables to load programme for menu installation with wireless basis . Image shown may differ from your TV . Installation Menu (V2 . 2 3) LG Hotel Mode Setup TV Link-Loader TV Link-Loader Password Change... -
Page 11: Introduction
USB Cloning Procedure - Introduction (1) Overview USB Cloning Procedure Commercial TVs have the capability to support cloning internal TV data and programme information with an external clone device called “TVLink-Loader”, in order to copy TV data accurately and quickly. The clone internal functions use slightly different internal processes for the two types of commercial TVs . -
Page 12: Send To Usb
Installation Menu Send To USB Image shown may differ from your TV . “Send To USB” must be done first before “Receive From USB” process, as it generate the file to be used “Send To USB”. While writing is in process, the user must not turn TV off nor unplug the USB memory card. -
Page 13: Password Change
Password Change Image shown may differ from your TV . - To ensure more security, Password can be changed by installers’ own design. Installation Menu (V2 . 2 3) LG Hotel Mode Setup Password Change TV Link-Loader Change Password Password Change... -
Page 14: Configuration Setup
Configuration setup Image shown may differ from your TV . Configuration Setup Installation Menu (V2 . 2 3) Configuration Setup Select RCU Enable LG Hotel Mode Setup Select RCU Enable Number of RCU TV Link-Loader Number of RCU Splash Offset Time... -
Page 15: External Speaker
External Speaker Image shown may differ from your TV . Installation Menu (V2 . 2 3) LG Hotel Mode Setup External Speaker TV Link-Loader Fixed ◄ ► Volume Control Password Change 1 Watt Output Set ID Setup Configuration Setup Previous... -
Page 16: Download Splash Image File To Tv Set
Download a splash image Download Splash Image file to TV set Make a ‘LG_DTV’ folder in the USB flash drive and then copy splash image file to the folder . Image shown may differ from your TV . Connect the USB device to the USB IN jack on the TV . OPTION Move Language(Language) - Page 17 WARNING TV Software Update(Expert) CAUTION TV Software Upgrade UPGRADING . . . The Following update files are found in the USB device . DO not unplug! Select the file you want to apply to update this TV Or press EXIT to cancel the update . Wait until the download process is completed .
