- Page 1 OWNER’S MANUAL LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. LT36** www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS EXTERNAL CONTROL dEVICE LICENSES SETUP OPEN SOURCE SOFTWARE NOTICE RS-232C Setup Type of connector; D-Sub 9-Pin Male INSTALLATION PROCEdURE RS-232C Configurations Communication Parameters Command reference list ASSEMBLING ANd PREPARING Transmission / Receiving Protocol Unpacking Parts and buttons Lifting and moving the TV Setting up the TV... -
Page 3: Licenses
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. -
Page 4: Installation Procedure
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING NOTE Image shown may differ from your TV. Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. The available menus and options may differ from the input source or product model that you are using. - Page 5 ASSEMBLING AND PREPARING ENERGY TV/RAD SAVING GUIDE INFO RATIO ENERGY AV MODE INPUT SAVING LIST Q.VIEW FLASHBK SETTINGS LIST Q.MENU MARK MUTE Remote control and EXIT MENU INFO Q.MENU ENTER batteries (AAA) MUTE BACK EXIT L/R SELECT FREEZE (See p. 18) Owner’s manual RATIO Cable holder...
- Page 6 ASSEMBLING AND PREPARING NOTE Antenna Isolator Installation Guide - Use this to install TV in a place where there is a voltage difference between TV Set and GND of antenna signal. » If there is a voltage difference between TV Set and GND of antenna signal, the antenna contact might be heated and excessive heat might cause an accident.
-
Page 7: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons Screen (Only 32/37/42/47LT36**) (Only 22/26LT36** ) Remote control Power Indicator (Can be adjusted using the Power Indicator in the OPTION menu.) Speakers Button description Scrolls through the saved programmes. Adjusts the volume level. Turns the power on or off. -
Page 8: Lifting And Moving The Tv
ASSEMBLING AND PREPARING Lifting and moving the TV When transporting a large TV, there should be at least 2 people. When transporting the TV by hand, hold the When moving or lifting the TV, read the following to TV as shown in the following illustration. prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size. -
Page 9: Setting Up The Tv
ASSEMBLING AND PREPARING Setting up the TV Image shown may differ from your TV. Attaching the stand 22/26LT36 ** M4 x 12 4 EA Stand Body M4X20 Front M4 x 16 Stand Base 2 EA Top View (Only 22LT36 ** ) M4 x 12 4 EA (Only 26LT36 ** ) - Page 10 ASSEMBLING AND PREPARING 32/37/42/47LT36 ** M4 x 14 4 EA Stand Body M4X20 Front Stand Base M4 x 14 4 EA Top View CAUTION When attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches.
-
Page 11: Mounting On A Table
ASSEMBLING AND PREPARING Mounting on a table Securing the TV to a table Fix the TV to a table to prevent from tilting forward, Lift and tilt the TV into its upright position on a damage, and potential injury. table. To secure the TV to a table, insert and tighten the - Leave a 10 cm (minimum) space from the supplied screw on the rear of the stand. -
Page 12: Mounting On A Wall
When you attach the TV to other building materials, please contact qualified personnel. LG recommends that wall mounting be performed by a qualified professional installer. 10 cm Insert and tighten the eye-bolts, or TV brackets and bolts on the back of the TV. -
Page 13: Protection Cover
If you install the TV on a ceiling or slanted Separate purchase (Wall Mounting Bracket) wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. 22LT36 32LT36... -
Page 14: Tidying Cables
It will help prevent the power cable from being removed by accident. This section on MAKING CONNECTIONS mainly uses diagrams for the LT36** models. Connect various external devices to the TV and switch input modes to select an external device. For more information of external device’s connection, refer to the manual provided with each device. -
Page 15: Adapter Connection
MAKING CONNECTIONS Antenna connection Adapter connection Connect the TV to a wall antenna socket with an 22/26LT36 ** RF cable (75 Ω). DC IN ANTENNA/ CABLE IN DC Adapter Connect the antenna cable to the antenna input port on the TV. Connect the DC adapter plug to the power input jack on the TV. -
Page 16: Hdmi Connection
MAKING CONNECTIONS HdMI connection dVI to HdMI connection Transmits the digital video signal from an external Transmits the digital video and audio signals from device to the TV. Connect the external device and your PC to the TV. Connect the PC and the TV the TV with the DVI-HDMI cable as shown. -
Page 17: Composite Connection
MAKING CONNECTIONS Composite connection RGB-PC connection Transmits analog video and audio signals from an Transmits the video signal from PC to the TV. To external device to the TV. Connect the external transmit an audio signal, connect an audio cable. device and the TV with th e composite cable as shown. -
Page 18: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching ends to the label inside the compartment, and close the battery cover. -
Page 19: Maintenance
MAINTENANCE / TROUBLESHOOTING MAINTENANCE Cleaning your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges. -
Page 20: Specifications
SPECIFICATIONS SPECIFICATIONS Product specifications may be changed without prior notice due to upgrade of product functions. For the power supply and power consumption, refer to the label attached to the product. 22LT36** 26LT36** MODELS 22LT360C-TA 26LT360C-TA Dimensions With stand 517.0 mm x 386.0 mm x 192.0 mm 626.0 mm x 454.0 mm x 192.0 mm (W x H x D) Without stand... - Page 21 SPECIFICATIONS Digital TV Analogue TV New Zealand, Television System DVB-T PAL/SECAM-B/G/D/K, PAL-I Singapore BG : VHF/UHF 1 to 69, CATV 01 to 47 Programme UHF 21 to 69 I : VHF/UHF 1 to 69, CATV 01 to 47 Coverage DK : VHF/UHF 1 to 69, CATV 01 to 47 Australia Television System DVB-T...
- Page 22 SPECIFICATIONS HdMI/dVI-dTV supported mode Horizontal Vertical Resolution Frequency Frequency (kHz) (Hz) 31.469 59.94 720x480 31.5 720x576 31.25 37.5 1280x720 44.96 59.94 33.72 59.94 33.75 28.125 26.97 23.97 1920x1080 33.716 29.976 33.75 30.00 56.25 67.43 59.94 67.5 RGB-PC, HdMI/dVI-PC supported mode Vertical Horizontal Resolution...
-
Page 23: Ir Codes
IR CODES IR COdES This feature is not available for all models. Code Function Note (Hexa) Remote control Button (Power On/Off) (POWER) ENERGY SAVING Remote control Button INPUT Remote control Button TV/RAD Remote control Button 10-19 Number Key 0-9 Remote control Button LIST Remote control Button Q.VIEW... -
Page 24: External Control Device Setup
EXTERNAL CONTROL DEVICE SETUP EXTERNAL CONTROL dEVICE SETUP RS-232C Setup RS-232C Configurations Connect the RS-232C (serial port) input jack to an 7-Wire Configurations ( Standard RS-232C cable ) external control device (such as a computer or an A/V control system) to control the product’s func- tions externally. -
Page 25: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP Communication Parameters Baud rate: 9600 bps (UART) Stop bit: 1 bit Data length: 8 bits Communication code: ASCII code Parity : None Use a crossed (reverse) cable. Command reference list (Depending on model) dATA dATA COMMANd1 COMMANd2 (Hexadeci- COMMANd1 COMMANd2 (Hexadeci-... -
Page 26: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV.(j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the set ID to choose desired monitor ID number in option menu. Adjustment range is 1 to 99. - Page 27 EXTERNAL CONTROL DEVICE SETUP 01. Power (Command: k a) 04. Volume Mute (Command: k e) ► To control Power On/Off of the set. ► To control volume mute on/off. You can also adjust mute using the MUTE button on remote Transmission[k][a][ ][Set ID][ ][Data][Cr] control.
- Page 28 EXTERNAL CONTROL DEVICE SETUP 09. Tint (Command: k j) 13. Treble (Command: k r) ► To adjust the screen tint. ► To adjust treble. You can also adjust tint in the PICTURE menu. You can also adjust treble in the AUDIO menu. Transmission [k][j][ ][Set ID][ ][Data][Cr] Data Red : 00 to Green : 64 Transmission [k][r][ ][Set ID][ ][Data][Cr]...
- Page 29 EXTERNAL CONTROL DEVICE SETUP 19. Tune Command (Command: m a) 17. Energy Saving (Command: j q) ► Select channel to following physical number. ► To reduce the power consumption of the TV. You can also adjust Energy Saving in PICTURE menu. Transmission [m][a][ ][Set ID][ ][Data0][ ][Data1][ ][Data2][Cr] Transmission [j][q][ ][Set ID][ ][Data][Cr] Data00 : High channel data...
- Page 30 EXTERNAL CONTROL DEVICE SETUP 23. Input select (Command: x b) (Main Picture Input) ► To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data Structure External Input Input Number External Input Data Analogue Component HDMI Input Number Data Input1 Input2...
- Page 32 Record the model number and serial (Only DTV) number of the TV. Refer to the label on the back cover and quote this information to your dealer when requiring any service. Model : Serial No. :...
