- Page 1 All manuals and user guides at all-guides.com SIMP HOME ® L I F E B Y D E S I G N WARM SHAKER / NORFOLK / LEXINGTON END TABLE MODEL AXWSH002-DCB 1/13...
- Page 2 All manuals and user guides at all-guides.com SIMP HOME ® L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext.
-
Page 3: Safety Information
All manuals and user guides at all-guides.com IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. -
Page 4: Care And Maintenance
All manuals and user guides at all-guides.com IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. -
Page 5: Pre-Assembly Information
All manuals and user guides at all-guides.com PRE-ASSEMBLY INFORMATION MODEL # AXWSH002-DCB PARTS DESCRIPTION RIGHT SIDE LEFT SIDE QTY 1 QTY 1 QTY 1 TOP SHELF BACK BOTTOM SHELF QTY 1 QTY 1 QTY 1 DRAWER FRONT LEFT DRAWER SIDE RIGHT DRAWER SIDE QTY 1 QTY 1... - Page 6 All manuals and user guides at all-guides.com PRE-ASSEMBLY INFORMATION MODEL # AXWSH002-DCB HARDWARE DESCRIPTION ALLEN KEY SCREW CAM LOCK PIN ALLEN KEY M6 X 30 mm CAM LOCK QTY 1 QTY 14 QTY 8 SETS Required - Flathead screwdriver Phillips screwdriver HANDLE WOOD DOWEL Rubber mallet...
- Page 7 All manuals and user guides at all-guides.com COMPONENTS – KEY DIAGRAM MODEL # AXWSH002-DCB 7/13...
- Page 8 All manuals and user guides at all-guides.com ASSEMBLY MODEL # AXWSH002-DCB STEP 1 1. Attach 4 Cam Lock Pins 2 to back of Drawer Front F . 2. Align Cam Lock Pins with guide holes and attach Drawer Sides GL , GR . 3.
- Page 9 All manuals and user guides at all-guides.com ASSEMBLY MODEL # AXWSH002-DCB STEP 3 1. Align Drawer Back H with Drawer Bottom I and press firmly into slot . 2. Attach back using 2 Allen Key Screws 1 through guide holes on each side. 3.
- Page 10 All manuals and user guides at all-guides.com ASSEMBLY MODEL # AXWSH002-DCB STEP 5 1. Insert 4 Dowels 5 into guide holes on the Back E . 2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 11 All manuals and user guides at all-guides.com ASSEMBLY MODEL # AXWSH002-DCB STEP 6 1. Attach Bottom Shelf D to Sides BL , BR using Allen Key Screws 1 through guide holes. 11/13...
- Page 12 All manuals and user guides at all-guides.com ASSEMBLY MODEL # AXWSH002-DCB STEP 7 1. Insert 2 Dowels 5 into guide holes on each Side BL , BR . 2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of Dowels should be exposed.
-
Page 13: Warranty
All manuals and user guides at all-guides.com SIMP HOME ® L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
