Daewoo DWC-ED1213 Service Manual page 18

4. INLET BOX AS
No. PARTS NAME
D01 HANDLE CAP
D02 CASE HANDLE
SCREW TAPPING
D03 CASE DETERGENT
D04 CAP SOFTENER
D05 INLETBOX
D06 NOZZLE AS
D07 PACKING
D08 HOSE INLET
D09 CLAMP AS
D10 HOSE C
D11 HOSE A
D12 HOSE B
D13 CLAMP SPRING
D14 VALVE INLET
D15 VALVE INLET
D16 PIPE JOINT
D17 HOSE SHOWER
PARTS CODE DESCRIPTION
3612608300 ABS
3611139400 ABS
7121301208 T2S PAN 3x12 SUS
3611139500 PP
3610916600 PP
3617505300 PP
3618103500 PP, DWD-100DR
3614010000 EPDM
3613266400 EPDM
3611203200 ID=60, WIRE+GUIDE+BOLT+NUT
3613267010 EPDM, ID=10, OD=16, L=165mm
3613266600 EPDM, ID=10, OD=16, L=335mm
3613266700 EPDM, ID=10, OD=16, L=420mm
3611203800 ID=15.5, T=0.6, B=10
3615415900 100/130V, 3WAY, PP/BRACKET
3615415000 220/240V, 50/60Hz, 3WAY
3615415010 220/240V, 3WAY, NYLON/BRACKET
3615415800 100/130V, 2WAY, PP/BRACKET
3615414900 220/240V, 50/60Hz, 2WAY
3615414910 220/240V, 2WAY, NYLON/BRACKET
3615415700 100/130V, 1WAY, PP/BRACKET
3615414800 220/240V, 1WAY, PP/BRACKET
3615414810 240V, 1WAY, PP/BRACKET
3614413300 PP
3613270100 EPDM, ID=8.5, OD=12.5, L=620
14
Q'TY REMARK
1 Luxury
1 Luxury
2 HANDLE CAP
1
1
1
1 TOP+UNDER
1
1
1 INLET BOX/TUB R
2 PRE WASH
1 MAIN WASH
1 HOT
8
1 COLD
1 COLD
1 COLD, VDE
1 COLD
1 COLD
1 COLD, VDE
HOT
HOT
1 HOT-AUS
1
1
