Electrical Requirements

WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Electrical Connection
To properly install your air purifier, you must determine the type of
electrical connection you will be using and follow the instructions
provided for it here.
The air purifier should be connected to a 115 V, 60 Hz, 15- or
20-amp fused 3 prong grounded outlet.
The use of a time-delay fuse or time-delay circuit breaker is
recommended.

Starting/Stopping Your Air Purifier

NOTE: Before operating the air purifier, record the date of
installation on the HEPA filter. Under normal conditions, the HEPA
filter should be replaced annually, and the pre-filter should be
replaced every 3 months. To remove and replace either filter, see
"Filter Replacement" in "Air Purifier Care."
A
B
C
A. Low fan speed
C. High fan speed
B. Medium fan
D. HEPA filter
speed
indicator light
4

INSTALLATION REQUIREMENTS

AIR PURIFIER USE

Change
HEPA Filter
D
Change
Pre-Filter
E
Reset
F
E. Pre-filter indicator
light
F. Filter reset button

Location Requirements

A. 6" (15.2 cm) minimum clearance
You will need a level surface at least 6" (15.2 cm) from heat
sources such as ranges or heaters.
Do not block air openings or place air cleaner on a soft
surface such as a bed or sofa.
Operate indoors only.
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
1. Plug into a grounded 3 prong outlet.
NOTE: Both filter indicator lights will flash once during a self-
test when the air purifier is turned on or after a power
interruption.
2. Turn the control knob to the large fan icon (High), the middle
fan icon (Medium) or the small fan icon (Low) to select the
desired fan speed.
3. Turn the control knob to Off to turn off the air purifier.
A
