- Page 1 UPER ® CSE-M14T Mobile Rack USER'S GUIDE Rev. 1.0...
- Page 2 Clara County in the State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
-
Page 3: Table Of Contents
Chapter I: Introduction ... 4 Overview ... 4 Product Features ... 4 Contacting Supermicro ... 5 Chapter 2: Technical Specifications ... 6 SASM14V Backplane ... 6 SASM14V Front Panel ... 6 2.B. SASM14V Back Panel ... 7 Chapter 3: Installation Instructions ... 8 Packing list ... -
Page 4: Chapter I: Introduction
PC users who intend to integrate Supermicro's intelligent, highly-expandable and cost-effective mobile rack solutions into their systems. It provides the user with detailed information for the installation and use of the CSE-M14T Mobile Rack. The Supermicro CSE-M14T Mobile Rack, supporting up to four hot-swap SAS/ SATA hard drives, packaged in the small size form factor (5.8"... -
Page 5: Contacting Supermicro
1.3 Contacting Supermicro Headquarters Address: SuperMicro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: SuperMicro Computer B.V. Het Sterrenbeeld 28, 5215 ML... -
Page 6: Chapter 2: Technical Specifications
CSE-M14T Mobile Rack User's Guide SASM14V Backplane 2.A. SASM14V Front Panel SAS/SATA#0 D3 D4 SAS/SATA#1 2.A.1 Front Connectors Front Connectors SAS/SATA#0 SAS/SATA#1 SAS/SATA#2 SAS/SATA#3 2.A.2 Front LED Indicators Front LED Indicators Overheat LED Fan Failure LED SAS/SATA#0 ACT LED SAS/SATA#1 ACT LED... -
Page 7: Sasm14V Back Panel
2.B. SASM14V Rear Panel JP22 JP26 JP42 ACT In SAS In JP18 2.B.1 Rear Side Connectors JP10: 4-pin power connector There is a 4-Pin Power Connector (JP10) located on the rear side of the SASM14V Backplane. This power con- nector must be connected to your power supply to provide adequate power to the backplane. -
Page 8: Chapter 3: Installation Instructions
To avoid personal injury and Stop property damage, please carefully follow all the Safety Guidelines listed below before accessing or servicing the CSE-M14T. Safety Steps Before accessing the Mobile Rack: 1. Turn off all peripheral devices and the power supply connected to the chassis and unplug all power cords from the system or the wall outlets. -
Page 9: Cooling Fan Installation And Removal
CSE-M14T before using it.) Procedures (-Fan Installation) 1. Attach the cooling fan to the CSE-M14T Mobile Rack and secure it to the Mobile Rack with two screws on both sides of the fan. 2. Connect the cooling fan cable to the Fan Connector as shown below. -
Page 10: Hdd Installation
CSE-M14T Mobile Rack User's Guide 3.5 HDD Installation 3.5.1 Removing the HDD Drive Tray Before installing the hard disk into the CSE-M14T, you will need to remove the HDD drive trays from the cage. Procedures 1. Press the release tab toward the right to release the HDD drive tray from the CSE-M14T cage. - Page 11 3.5.2 Installing the Hard Disk Drive into the Drive Tray Procedures 1. Place a 2.5" Hard Drive Disk on top of the drive tray. 2. Align the HDD against the drive tray. 3. Secure the HDD onto the drive tray by installing four M-3 Screws into the holes as shown below.
-
Page 12: Installing The Hard Drive Disk Into The Drive Tray
CSE-M14T Mobile Rack User's Guide 3.5.3 Installing Hard Disk Drives into the Mobile Rack Procedures 1. After you've installed a hard disk drive into a drive tray as indicated in Section 3.5.2, you are ready to install the HDD into the mobile rack. -
Page 13: Rear Window Removal (Optional)
3.6 Rear Window Removal Procedures 1. Follow the procedures listed on Section 3.4 to remove the cooling fan from the CSE-M14T. 2. After the cooling fan is detached, remove the four screws from the CSE-M14T as shown below. 2. Remove the screws. - Page 14 CSE-M14T Mobile Rack User's Guide Notes...
