OPERATING TIPS
• Cut grass when it is dry.
• Cut grass in two passes when cutting thick, long, or
wet grass. Make the first cut higher than desired.
Make the second cut at desired height.
• Always use full throttle when bagging.
• Adjust ground speed as needed to allow the bagger
to pick up debris.
MAINTENANCE
WARNING: AVOID INJURY. Read and
understand the entire Safety section before
proceeding.
Ariens/Gravely Dealers will provide any service or
adjustments which may be required to keep your unit
operating at peak efficiency.
Interval
Task
Check
Counter-
weight
Check
Bagger
Hose
Check
Mesh
Bags
Each
Check
Use
Fasteners
Inspect
Bagger
Parts
Clean Unit Clear away debris under belt
Action
Ensure counterweight is
installed and securely fastened.
Ensure bagger hose is securely
fastened to cover assembly and
bagger boot.
Ensure mesh bags are installed,
and bagger cover is closed and
securely latched.
Ensure all hardware is tight. Pay
special attention to the guards
and safety shields.
Inspect bagger parts for holes,
abrasions, or structural damage.
Replace any worn or damaged
parts with Ariens/Gravely service
parts.
cover, in bagger boot, in tube,
and in cover assembly.
WARNING: AVOID INJURY. Read and
understand the entire Safety section before
proceeding.
IMPORTANT: NEVER spray unit with high-pressure
water. DO NOT store unit outdoors.
Clean plastic surfaces with sponge and mild detergent.
Dry with a soft cloth.
Clear away debris under belt cover, in bagger boot, in
tube, and in cover assembly before storing.
Remove all dirt, grease, leaves, etc. from unit.
Store in a clean, dry area.
Ensure all fasteners are properly tightened. Inspect
moving parts for damage and wear.
Touch up all rusted or chipped painted surfaces.
TROUBLESHOOTING
Problem
Probable Cause
1. Air flow is
restricted.
Airflow
indicator
points
straight
up.
1. The mesh bags
are full.
Bagger
fails to
pickup
2. Bagger is
grass or
clogged.
leaves.
SPECIFICATIONS
Model Number
Description
Serial Number
Added Length to
Unit
Added Weight
(Bagger
Components
Only)
17
STORAGE
Correction
1. The mesh bags
are full (see
Emptying Mesh
Bags on
page 16).
2. The bagger is
clogged (see
Unclogging
Bagger on
page 16).
1. Empty mesh bags
(see Emptying
Mesh Bags on
page 16).
2. Unclog bagger
(see Unclogging
Bagger on
page 16).
815020
34-Inch Non-Powered Bagger
000101 and up
18-5/8 in. (47.3 cm)
158 lbs (71.7 kg)
