  • Page 1 Owner’s Manual Revo 1836 MLAREVO1836 lagunatools.com | lagunacleanair.com | supermaxtools.com...
  • Page 2 Aside from being free of defects upon receiving, consumable parts, like cutters and abrasives, are not covered by this warranty unless otherwise stated by Laguna Tools. These parts are designed to be used at the expense of the operator and are available for replacement or inventory purchase.
  • Page 3 Today, we offer high-performance machines with innovative solutions that meet the needs of Craftsman and their ever-evolving craft. I started Laguna Tools as a woodworker and craftsman; I still am and more. Thank you again for becoming a Laguna Tools customer.

  • Page 4: Table Of Contents

    Table of contents. Page number Safety Rules Warranty Noise emission Specification sheet Receiving your machine Introduction to your machine Parts of the machine What you will receive with the machine Where to locate your machine Unpacking your machine Assembly and setup Maintenance Troubleshooting Electrical drawing...

  • Page 5: Safety Rules

    Safety Rules. "WARNING": For Your Own Safety Read Instruction Manual before Operating Lathe Wear eye protection. Do not wear gloves, a necktie, or loose clothing. Tighten all locks before operating. Rotate work piece by hand before applying power. Rough out work piece before installing on faceplate. Do not mount split work piece or one containing a knot.
  • Page 6 Table A Ampere Rating Volts Total length of cord in feet More Than Not More Than Minimum gage for cord Not Recommended GROUNDING INSTRUCTIONS 1. All grounded, cord-connected tools: In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock.
  • Page 7 Fig. 1...
  • Page 8 Locking the lathe It is strongly recommended that the lathe is never be left unattended in the unlocked condition. To lock the machine it is recommended that a cover (not supplied) is made to lock the control panel. We have supplied two concepts for locking the panel (see below). The cover can be made from wood or plastic.
  • Page 9 Wooden safety cover Padlocks Emergency stop switch Plastic safety cover Padlocks...

  • Page 10: Warranty

    Laguna Tools guarantees all new machines sold to be free of manufacturer's defective workmanship, parts, and materials. We will repair or replace, without charge, any parts determined by Laguna Tools, Inc. to be a manufacturer's defect. We require the defective item/part to be returned to Laguna Tools. In...

  • Page 11: Noise Emission

    Noise Emission. Notes concerning noise emission: Given that there exists a relationship between noise level and exposure times, it is not possible to precisely determine the need for supplementary precautions. The factors affecting the true level of exposure to operators are clearly the amount of time exposed and the characteristics of the working environment, such as other sources of dust and noise, etc., for example, adjacent machines - in other words, the level of ambient noise.

  • Page 12: Receiving Your Machine

    All damage must be noted on the delivery documents and signed by you and the delivery driver. You must then contact the seller (Laguna Tools) as soon as practical. If damage is found after delivery, contact the seller as soon as is practical.
  • Page 13 Identification. There is a plate at the back of the machine listing all the manufacturing data, including the serial number, model, etc. Lathe Bed. The bed is a machined heavy steel welded construction. Underside of lathe bed...
  • Page 14 Lathe legs. The Legs are cast iron, and their heavy construction gives the machine a low center of gravity and ensures that it is very stable. The legs are supplied with adjustable feet to allow the machine to be leveled. Legs with adjustable feet assembled Head stock.
  • Page 15 Tail stock. The tail stock is of cast iron construction, and the spindle has a travel of 4 1/2 in. It can accommodate centers and other tools which have a number 2 Morse Taper. The tail stock can be moved to any position on the lathe bed and locked to suit the job at hand. Tailstock viewed from the front Tailstock viewed from the back Tool rest.
  • Page 16 Electrical system. 220V: The electrical control system (VFD) is housed at the back of the head stock, The VFD converts single phase 220v to three phase. There is a speed readout at the front of the lathe with controls to fine adjust the RPM of the spindle. . A power cord with 220V plug is provided. 110V: The electrical control system (VFD) is housed at the back of the head stock, The VFD converts single phase 110v to three phase.

  • Page 17: What You Will Receive With The Machine

    What you will receive with the lathe. Head stock Tool rest Tail stock Drive &live center storage Tool storage Leg Banjo Adjustable feet...

  • Page 18: Where To Locate Your Machine

    Face plate Tool rack Rotating center Adjustable feet Tail stock bracket Removal tool Drive center Knock out rod Head stock bracket Tail stock knob Tool rest comes fitted to banjo Where to locate your machine. Before you remove your machine from the packaging, select the area where you will use your machine.

  • Page 19: Unpacking Your Machine

    Unpacking your machine. To unpack your machine you will need tin snips, a knife, and a wrench. 1. Using the tin snips, cut the banding that is securing the packing box (If fitted). WARNING: EXTREME CAUTION MUST BE USED, BECAUSE THE BANDING WILL SPRING AND COULD CAUSE INJURY.

  • Page 20: Assembly And Setup

    Note. The machine is heavy. Ensure that you have enough people to do the job safely. Note. If you have any doubt about the described procedure, seek professional assistance. Do not attempt any procedure that you feel is unsafe, or that you do not have the physical capability of achieving.
  • Page 21 Tailstock clamp handle Stop Bed with headstock and tailstock removed Leg fixing screws Lay the bed on 2" X 4" timbers in the upside down position. Lift the legs to the vertical position and lower them onto the bed. Secure with the fixing screws provided. Note.
  • Page 22 Assemble the head stock, tool rest and tailstock back onto the bed of the lathe and fit the stops. Note. If you have any doubt about the described procedure, seek professional assistance. Do not attempt any procedure that you feel is unsafe, or that you do not have the physical capability of achieving.
  • Page 23 If you decide to fit the tool rest after fitting the tail stock, follow the below procedure. Fit the tool rest onto the bed of the lathe ensuring that the washer recess fits into the slot in the bed. Fit the banjo onto the bed with the bolt through the washer and assemble the nut onto the thread.
  • Page 24 Fitting the stock knob. Screw the tail stock knob onto the tail stock handle. Tail stock knob Tail stock handle Connecting the electrical supply. Ensure that the electrical supply corresponds with that of the machine (Single phase 220V or 110V). It is recommended that you use a 15-amp main breaker.
  • Page 25 Fitting the rotating center. Rotating center Ensure that the bore of the tail stock is clean. The rotating center has a number 2 Morse Taper that fits into the tail stock. Push the center into the tail stock bore firmly, and ensure that it is securely located.
  • Page 26 Drive center removal shaft Headstock drive center Ensure that the bore of the head stock is clean. The drive center has a number No. 2 Morse Taper that fits into the head stock Push the center into the head stock bore firmly, and ensure that it is securely located. To remove the center, push the removal shaft into the back of the head stock, and give it a sharp knock.
  • Page 27 Emergency stop button Start / stop buttons Speed display Forward / reverse switch Variable speed adjustment knob Head stock clamp lever Head stock clamp lever. The head stock clamp lever allows the head stock to be released and moved to any position on the lathe bed.
  • Page 28 Variable speed adjustment knob. Increase speed Decrease speed The Variable speed adjustment knob adjusts the spindle speed. Turns clockwise to increase the speed, turns counter-clockwise to decrease the speed High / low speed. The lathe has two sets of pulleys for high (135 - 3500 RPM ) and low (50 - 1300 RPM) speed ranges.
  • Page 29 Pulleys and drive belt Pulley cover Motor lock handle Motor adjustment handle Indexing the spindle. The spindle has 3 sets of indexing holes 14 / 36 / 48. The selection plunger is located at the end of the head stock. To move between the 3 sets of holes, loosen the clamp knobs and slide the indexing plunger assembly to align with the selected hole set.
  • Page 30 Clamping knobs Hole selection indicator Indexing holes Hole selection Indexing plunger Indexing plunger engaged Indexing plunger disengaged...

  • Page 31: Maintenance

    Maintenance. General. Keep your machine clean. At the end of each day, clean the machine. Wood contains moisture, and if sawdust or wood chips are not removed they will cause rust. In general, we recommend that you only use a Teflon-based lubricant on the lathe. Regular oil attracts dust and dirt.
  • Page 32 the tailstock should be slid along the bed to check for any area that it binds in the bed slot. The same procedure as above should be conducted on the head stock should it be required. Note. It is very unlikely that the headstock will require adjustment as it is not moved as often as the tailstock, so has less tendency's for ware.
  • Page 33 Center point alignment. The tailstock has two clamp screws that are accessible from the top of the tailstock. The clamp screws hold the slide plate to the tailstock casting. There is clearance in the holes that allows the tailstock to be moved in relation to the slide plate. The headstock also has two clamp screws, but one is accessible from under the headstock.

  • Page 34: Troubleshooting

    Troubleshooting. Lathe will not start. 1. Check that the start switch is in the correct position. 2. Check that the electrical power cord is plugged into the power outlet. 3. Check that the electrical supply is on (reset the breaker). 4.
  • Page 35 Machine vibrates. 1. Machine not level on the floor. Re-level the machine ensuring that it has no movement. 2. Damaged drive belt. Replace the belt. 3. Job is not balanced. Change to slower speed and/ or balance the job. 4. Damaged pulley. Replace the pulley. 5.

  • Page 36: Electrical Drawing

    Electrical drawing.

  • Page 37: Exploded View Drawings

    Exploded view drawings and parts list.
  • Page 39 REVO 18│36 LATHE Index Part Number Item Description Specification PLAREVO1836-101 PLAREVO1836-102 Spindle Pulley PLAREVO1836-103 Spring PLAREVO1836-104 Spindle Lock Plunger PLAREVO1836-105 Locking Collar PLAREVO1836-106 Bearing Nut PLAREVO1836-107 Door PLAREVO1836-108 Tailstock PLAREVO1836-109 Motor Pulley PLAREVO1836-110 Motor Plate PLAREVO1836-111 Headstock Locking Handle PLAREVO1836-112 Headstock PLAREVO1836-113 3"...
  • Page 40 PLAREVO1836-135 Tool Rest Support Base PLAREVO1836-136 Cord Holder PLAREVO1836-137 Tool Rest Locking Handle PLAREVO1836-138 12" Tool Rest PLAREVO1836-139 PLAREVO1836-140 Lock Handle PLAREVO1836-141 Handwheel PLAREVO1836-142 Quill PLAREVO1836-143 Tailstock Locking Handle PLAREVO1836-144 Live Center Assembly PLAREVO1836-145 Tailstock Adjusting Plate PLAREVO1836-146 Lead Screw PLAREVO1836-147 Stop Bolt PLAREVO1836-148...
  • Page 41 PLAREVO1836-171 Emergency Stop PLAREVO1836-172 Spacer PLAREVO1836-173 Fwd/Rev Switch PLAREVO1836-174 Relay 220V PLAREVO1836-110-150- Relay 110V PLAREVO1836-175 Ball Bearing 6205LLU PLAREVO1836-176 Ball Bearing 6207LLU PLAREVO1836-177 Pillar PLAREVO1836-178 Index Label PLAREVO1836-179 Index Indicator PLAREVO1836-180 Power Cord 220V PLAREVO1836-110-150- Power Cord 110V PLAREVO1836-181 Knob PLAREVO1836-182 Leveling Foot PLAREVO1836-183...
  • Page 42 PLAREVO1836-1106 Phillips Flat Head Screw M6x16 PLAREVO1836-1107 Screw M3x4 PLAREVO1836-1108 Motor Cord PLAREVO1836-1109 Flat Washer D3xD8x1t PLAREVO1836-1110 Nylon Insert Lock Nut M18x2.5 PLAREVO1836-1111 Hex Nut 3/8-16UNC PLAREVO1836-1112 Flat Washer D10xD23x2t PLAREVO1836-1113 Flat Washer D8xD18x2t PLAREVO1836-1114 Lock Washer 5/16" PLAREVO1836-1115 Lock Washer 3/8"...
  • Page 43 PLAREVO1836-1143 O-Ring PLAREVO1836-1144 Speed Label PLAREVO1836-1145 PLAREVO1836-1146 Socket Head Button Screw 1/4-20UNCx3/8" PLAREVO1836-1147 Headstock Bracket 3/8-16UNCx1- PLAREVO1836-1148 Socket Head Cap Screw 1/4" PLAREVO1836-1149 Tailstock Bracket PLAREVO1836-1150 Socket Head Cap Screw 3/8-16UNCx3/4" PLAREVO1836-1151 Magnet PLAREVO1836-1152 Screw M4x6 PLAREVO1836-1153 Hex Nut M4x0.7 PLAREVO1836-1154 Braking Resistor Cover...
  • Page 44 Optional Headstock Guard Part Number Index Item Description Specification PLAREVO1836-201 Plunger PLAREVO1836-202 Retaining Collar PLAREVO1836-203 Guard PLAREVO1836-204 Set Screw 1/4-20UNCx1/4"...
  • Page 46 Optional 20" Bed Extension with Riser Block and Tool Rest Extension Part Number Index Item Description Specification PLAREVO1836-301 20" Bed Extension PLAREVO1836-147 Stop Bolt PLAREVO1836-195 Socket Head Cap Screw 3/8-16UNCx1" PLAREVO1836-304 Riser Block PLAREVO1836-305 Riser Block Locking Handle PLAREVO1836-306 Riser Block Adjusting Plate PLAREVO1836-119 Clamp PLAREVO1836-114...
  • Page 47 Optional 12" Swing-Away Extension Part Number Index Item Description Specification PLAREVO1836-401 12" Bed Extension PLAREVO1836-402 Draw Latch Assembly PLAREVO1836-403 Hinge PLAREVO1836-404 PLAREVO1836-147 Stop Bolt PLAREVO1836-406 Socket Head Cap Screw M6x12 PLAREVO1836-407 Phillips Flat Head Screw M5x12 PLAREVO1836-320 Socket Head Button Screw 3/8-16UNCx1-1/4"...
  • Page 48 Optional Comparator Part Number Index Item Description Specification PLAREVO1836-501 Center PLAREVO1836-502 Lock Handle...
  • Page 49 Optional Industrial Flood Light Part Number Index Item Description Specification PLAREVO1836-601 Work Light PLAREVO1836-602 Screw M4x15...
  • Page 51 Optional Inverter for Vacuum Part Number Index Item Description Specification PLAREVO1836-801 Connecting Shaft PLAREVO1836-802 Vacuum Adaptor Body PLAREVO1836-803 Cover PLAREVO1836-804 Vacuum System Box PLAREVO1836-805 Plate PLAREVO1836-806 Vacuum Generator Bracket PLAREVO1836-807 Vacuum System Bracket PLAREVO1836-808 O-Ring PLAREVO1836-809 Vacuum Generator PLAREVO1836-810 Silencer PLAREVO1836-811 L-Type Fitting PLAREVO1836-812...
  • Page 53 Optional Deluxe Wheel System Part Number Index Item Description Specification PLAREVO1836-901 Support Bracket-Right PLAREVO1836-1115 Lock Washer 3/8" PLAREVO1836-195 Socket Head Cap Screw 3/8-16UNCx1" PLAREVO1836-904 Support Bracket-Left PLAREVO1836-905 Nylon Insert Lock Nut M8x1.25 PLAREVO1836-906 Support Bracket PLAREVO1836-907 Socket Head Cap Screw M8X45mm PLAREVO1836-1146 Socket Head Button Screw...
  • Page 54 Optional 3" Riser Blocks Part Number Index Item Description Specification PLAREVO1836-701 3" Riser Blocks PLAREVO1836-702 Socket Head Cap Screw 3/8-16UNCx3-1/2" PLAREVO1836-1115 Lock Washer 3/8" PLAREVO1836-1146 Socket Head Button Screw 1/4-20UNCx3/8" PLAREVO1836-705 Support Bracket PLAREVO1836-706 Support Bracket PLAREVO1836-707 Socket Head Cap Screw 3/8-16UNCx3/4"...
  • Page 56 Laguna Tools is not responsible for errors or omissions. Specifications subject to change. Machines may be shown with optional accessories. © 2018, Laguna Tools, Inc. LAGUNA® and the LAGUNA Logo® are the registered trademarks of Laguna Tools, Inc. All rights reserved.
