Summary of Contents for JUKI MO-50e
- Page 1 MO-50e/51e Service Manual...
-
Page 2: Height Of The Needle Bar
1. HEIGHT OF THE NEEDLE BAR. A=11±0.2... - Page 3 2. ADJUSTMENT OF THE FEED DOG LIFT.
- Page 4 3. ADJUSTMENT OF THE NEEDLE BAR IN RELATION TO THE FEED DOG SHIFT.
-
Page 5: Height Of The Feed Dog
4. HEIGHT OF THE FEED DOG. A=1.1±0.2... -
Page 6: Projection Of The Upper Looper
5. PROJECTION OF THE UPPER LOOPER. A=4.6±0.3... -
Page 7: Radius Of The Lower Looper
6. RADIUS OF THE LOWER LOOPER. A=65.5±0.2... - Page 8 7. ADJUSTMENT OF THE STOPPING POINT OF THE LOWER LOOPER (SYNCHRONIZATION) (USE CLAMP).
- Page 9 8. CLEARANCE BETWEEN LOWER POINT, WHEN AT LEFT MOST POSITION, TO THE LEFT SIDE OF THE LEFT NEEDLE. A=2.6±0.3...
- Page 10 9. CLEARANCE BETWEEN LOWER LOOPER AND THE LEFT AND THE RIGHT HAND NEEDLE. A=0~0.05...
-
Page 11: Timing Between Upper And Lower Looper
10. TIMING BETWEEN UPPER AND LOWER LOOPER. A=0.5±0.3... -
Page 12: Clearance Between Lower Looper And Upper Looper
11. CLEARANCE BETWEEN LOWER LOOPER AND UPPER LOOPER. A=0.1~0.3... - Page 13 12. CLEARANCE BETWEEN NEEDLE AND NEEDLE GUIDE. A=0~0.05 B=0.05~0.3...
- Page 14 13. POSITION OF THE LOOPER THREAD TAKE-UP LEVER. THE HEIGHT FROM THE BASE PLATE TO THE TOP SIDE OF THE THREAD GUIDE. A=28±0.3...
-
Page 15: Height Of The Presser Foot
14. HEIGHT OF THE PRESSER FOOT. A=4.0~4.5... - Page 16 E1P17...
