- Page 1 BSLBATT & VICTRON Installation Manual 10.2kw Power Wall V 1.3...
- Page 2 BSLBatt & Victron Setup-Guide SAFETY GUIDELINES Work or maintenance on the BSLBatt should be carried out by qualified personal only. Do not attempt to open or dismantle battery and / or cells. The electrolyte contained in the battery cells is highly corrosive. In the event of any damage to or leakage from cells, treat contents with care, do not allow contact with exposed skin or eyes.
-
Page 3: Table Of Contents
BSLBatt & Victron Setup-Guide Contents SAFETY GUIDELINES ............................i Contents ................................ii Pin-out Diagram ............................ 1 Battery Set-up ............................3 General ............................3 2.1.1 Turning battery on & Off ..................... 3 2.1.2 CAN Communication ......................3 2.1.3 Dry Contacts.......................... 3 2.1.4 Other Ports .......................... -
Page 4: Pin-Out Diagram
BSLBatt & Victron Setup-Guide Pin-out Diagram Figure 1: Pin-out diagram for 5.1kWh BSL Battery. Reset button (Hold for 5sec to reset) DIP switches for parallel connection Dry contacts RS485 port (Port 1) CAN port (port 2) RS232 programming port (port 3) RS485 right ports (ports 4&5) Circuit Breaker ( Terminal power connect/disconnect) Positive terminal... - Page 5 BSLBatt & Victron Setup-Guide Power light Run light Alarm light SOC indicator lights Display screen Push buttons to adjust settings Page...
-
Page 6: Battery Set-Up
BSLBatt & Victron Setup-Guide Battery Set-up General 2.1.1 Turning battery on & Off The battery can be switched on or off by holding down the small recessed button marked “RESET” for around 3 seconds. 2.1.2 CAN Communication A VE.Can to CAN-bus BMS “Type B” cable is required for CAN-Bus communication between the BSL battery and the Victron GX device. -
Page 7: Multiple Batteries
BSLBatt & Victron Setup-Guide Multiple Batteries 2.2.1 Max Number of Parallel Batteries A maximum of 30 batteries can be connected in parallel. Each battery will require a unique binary address which can be setup via the dip-switches located on the front of the battery. -
Page 8: Dip Switch Settings For Multiple Batteries (8.2 Kwh, 15 Kwh)
BSLBatt & Victron Setup-Guide 2.2.5 Dip Switch Settings for Multiple Batteries (8.2 kWh, 15 kWh) Table 2 Dip-switch set-up for multiple batteries Address DIP Switch Position Notes Master Pack Auxiliary Pack 1 Auxiliary Pack 2 Auxiliary Pack 3 Auxiliary Pack 4 Auxiliary Pack 5 Auxiliary Pack 6 Auxiliary Pack 7... -
Page 9: Inverter Set-Up
BSLBatt & Victron Setup-Guide Inverter Set-up Batteries Per Inverter Size 3.1.1 5.1 kWh (100 Ah) Inverter Size Recommended Batteries Minimum Batteries 15 kVA 10 kVA 8 kVA 5 kVA 3 kVA 3.1.2 6.4 kWh (125 Ah) Inverter Size Recommended Batteries Minimum Batteries 15 kVA 10 kVA 8 kVA... -
Page 10: Kwh (172 Ah)
BSLBatt & Victron Setup-Guide 3.1.5 8.8 kWh (172 Ah) Inverter Size Recommended Batteries Minimum Batteries 15 kVA 10 kVA 8 kVA 5 kVA 3 kVA 3.1.6 10.2 kWh (200 Ah) Inverter Size Recommended Batteries Minimum Batteries 15 kVA 10 kVA 8 kVA 5 kVA 3 kVA... -
Page 11: Battery Set-Up On Victron Gx Device
BSLBatt & Victron Setup-Guide Battery Set-up on Victron GX Device 1. The VE.Can to CAN-bus BMS Type B cable needs to be connected to the VE- Can port on the GX device and the second unused VE.Can port needs to be terminated with the Victron blue terminator. -
Page 12: Battery Set-Up On Victron Mppt Device
BSLBatt & Victron Setup-Guide Battery Set-up on Victron MPPT Device Page... -
Page 13: Inverter Settings (Victron)
BSLBatt & Victron Setup-Guide Inverter Settings (Victron) General Tab Total battery bank capacity Page... -
Page 14: Grid Tab
BSLBatt & Victron Setup-Guide Grid Tab Page... -
Page 15: Inverter Tab
BSLBatt & Victron Setup-Guide Inverter Tab Take Note: Shutdown on SOC optional but recommended to untick, inverter will use battery Voltage instead. Page... -
Page 16: Charger Tab
BSLBatt & Victron Setup-Guide Charger Tab Page... - Page 17 BSLBatt & Victron Setup-Guide Page...
-
Page 18: Assistant Tab (A)
BSLBatt & Victron Setup-Guide Assistant Tab (a) Page... -
Page 19: Assistant Tab (B)
BSLBatt & Victron Setup-Guide Assistant Tab (b) Page... -
Page 20: Assistant Tab (C)
BSLBatt & Victron Setup-Guide Assistant Tab (c) Page... -
Page 21: Assistant Tab (D)
BSLBatt & Victron Setup-Guide Assistant Tab (d) Page... -
Page 22: Assistant Tab (E)
BSLBatt & Victron Setup-Guide Assistant Tab (e) Page... -
Page 23: Assistant Tab (F)
BSLBatt & Victron Setup-Guide 4.10 Assistant Tab (f) Page... -
Page 24: Revision History
BSLBatt & Victron Setup-Guide Revision History Version Date Editor Changes Nov 2021 D. E. Cornew - Feb 2022 P. J. Andrew - Address 0 column removed from Dip switch settings for multiple batteries (Tables 1 and 2) - Formatting Nov 2022 P.J. Andrew - Update on BSLBatt Branding.
