Glentronics PHCC-1730 Additional Instructions

Maintenance Free Battery Instructions
The PHCC Pro Series Maintenance Free Battery is
compatible with most PHCC Pro Series systems
including, the PHCC-1000, PHCC-1730 (with
Remote Terminals), PHCC-1850, PHCC-2400,
PS-C11, PS-C22 (with Remote Terminals), and
PS-C33. This battery is maintenance free in
that it does not require fluid or distilled water.
Depending on the PHCC Pro Series system and the
inflow of water, this battery will keep your backup
system pumping intermittently for days.
Please review the instruction manual of your PHCC Pro Series
sump pump system for additional safety instructions.
Connection Instructions
1. Place the battery in a protective battery box.
2. Unscrew each bolt and washer from the battery terminals.
3. Insert one bolt through the washer and then the NEGATIVE ( - ) ring
terminal from the controller and screw it into the NEGATIVE ( - )
terminal of the battery.
4. Insert the other bolt through the washer and then the POSITIVE ( + )
ring terminal from the controller and screw it into the POSITIVE ( + )
terminal of the battery.
5. Attach the fluid sensor from the controller to the POSITIVE ( + )
battery terminal by placing the fluid sensor between the washer and
the POSITIVE ( + ) ring terminal. This will silence the fluid alarm.
If the sensor is not attached the low fluid alarm will sound
continuously.
6. Check to ensure all connections are snug.
Maintenance
To help prolong the life of the battery please clean any corrosion off the
ring lugs and battery posts.
• Use a stiff brush or sandpaper to clean battery terminals and ring lugs.
• DO NOT apply corrosion resisting sprays, gels or pads to the ring lugs or
battery posts after you have cleaned them, this could prevent the
battery from charging properly.
Distributed by Glentronics, Inc.
645 Heathrow Drive
Lincolnshire, IL 60069
800.991.0466
www.stopflooding.com
Made in Vietnam
Never smoke or allow a spark or flame in the vicinity of the battery
•
Be sure the area around the battery is well ventilated
•
DO NOT drop a metal tool onto the battery. It might short circuit
•
the battery and cause an explosion
Remove personal metal items such as rings, bracelets, watches, etc.
•
when working with the battery. A short circuit through one of
these items can melt causing a severe burn
• ALWAYS remove the charger from the electrical outlet before
connecting or disconnecting the battery cables
• Heavy Battery. Always use two hands when carrying the battery
• Battery posts and terminals contain lead, lead compounds or other
chemicals known to the State of California to cause cancer, birth
defects or other reproductive harm. Wash hands after handling.
See https://www.p65warnings.ca.gov/
WARRANTY
One Year Free Replacement
(Receipt Required)
! WARNING
NEGATIVE POST
NEGATIVE Ring Lug
from Controller
Battery Terminal
POSITIVE POST
Flat Bolt
Washer
Battery POSITIVE Ring Lug
Terminal from Controller
Please recycle old batteries.
Do NOT place in trash. Take
old batteries to a service or
recycling center.
Bolt
Flat
Washer
Fluid
Sensor
09/19
