- Page 1 User Manual Nvidia Jetson Series Carrier board Aetina AN810...
- Page 2 Document Change History Version Date Description V1.0 2020/08/28 Initial Release. V1.1 2020/9/2 Correct CN2 pin-define and description. V1.2 2020/9/21 Correct component’s description. V1.3 2023/07/07 M.2 M-key 2280 will not support mSATA function.
- Page 3 Support for NVIDIA® Jetson Xavier™ NX. You can quickly emulate the functionality of your desired end product for software development and hardware verification. To build a functional prototype of your target system you will need: • NVIDIA® Jetson Xavier™ NX module (Aetina’s P/N: NSO-MD-XNX) • Carrier board (Aetina’s P/N: AN810) •...
-
Page 4: Board Specification
2. Board Specification Specification AN810 Description Module Compatibility NVIDIA® Jetson Xavier™ 384-core NVIDIA Volta™ GPU with 48 Tensor Cores 6-core NVIDIA Carmel ARM®v8.2 64-bit CPU 6MB L2 + 4MB L3 Dimension 120mm x 120mm Display 1 x HDMI Ethernet 1 x Gigabit Ethernet 2 x USB3.2 Gen1 Type A 1 x USB2.0 Micro AB(OTG Only) SD CARD... -
Page 5: Block Diagram
3. Block Diagram 3.1 Board Placement... - Page 7 CN10 CAN Bus Connector. Debug UART. M.2 2280 M Key, support PCIe function device. M.2 3050 B Key, support 4G/5G function device. CN16 SIM Card Socket. Support I2S function. Support GPIO, 2x UART function. CN22 For DC output function device. CN20 6 pins connector for Power input.
-
Page 8: Mechanical Dimensions
3.2 Mechanical Dimensions... -
Page 9: Connectors And Pin-Outs
4. Connectors and Pin-outs 4.1 CN10 : CAN Bus Define Define CAN0H CAN0L 4.2 CN7 : Debug UART Define UART2_RXD_3V3 UART2_TXD_3V3 4.3 CN8 : I2S Define Define AUD_MCLK01 I2S1_LRCLK I2S1_SDOUT I2S1_SDIN SYS_RST_IN# I2S1_CLK... - Page 10 4.4 CN3 : UART and GPIO Define Define UART1_RXD_HDR_3V3 UART0_RXD_HDR_3V3 UART1_TXD_HDR_3V3 UART0_TXD_HDR_3V3 UART1_RTS_HDR_3V3 UART0_RTS_HDR_3V3 UART1_CTS_HDR_3V3 UART0_CTS_HDR_3V3 GND0 GND1 GPIO_1 GND2 GPIO_2 GND3 GPIO_3 GND4 GPIO_4 GND5 GPIO_5 GND6 4.5 CN22 : DC-Output Define DC-Out DC-Out 4.6 CN20 : Power input Define VDD_INPUT VDD_INPUT...
- Page 11 4.7 CN19 : PSE power Input Define Define PSE1+ PSE2+ PSE1- PSE2- 4.8 CN4 : Front Panel Define Define Power ON GND0 Reset GND1 Recovery GND2 GND3 LED_POWER_3V3 EXT_LED In order to boot up the system, pleas quickly short-circuit Pin1 and Pin2. 4.9 CN9 : I2C Define Define...
- Page 12 4.11 CN2 : I2C/Auto Power on switch Define Define LATCH_SET_BUT LATCH_SET VDD_3V3 VDD_3V3 ID_I2C_SDA ID_I2C_SCL Remove Jumper from Pin1 and Pin2 can enable Auto power on function. 4.12 J4 : FAN Power Header Define FAN_PWM FAN_TACH FAN_PWR_VDD 5V...
- Page 13 However, Aetina reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of Aetina to notify any person of such revisions or changes. Aetina MAKES NO REPRESENTATIONS OR WARRANTIES WITH RESPECT TO THE CONTENTS HEREOF AND ASSUMES NO RESPONSIBILITY FOR ANY INACCURACIES, ERRORS OR OMISSIONS THAT MAY APPEAR IN THIS INFORMATION.
