- Page 1 User Manual Nvidia Jetson Series Carrier board Aetina ACE-N510...
- Page 2 Document Change History Version Date Description Authors 2018/03/15 Initial Release. Eric Chu...
-
Page 3: Table Of Contents
Contents Introduction ................................- 1 - Features ............................... - 1 - Board ................................- 1 - Board Specification .............................. - 2 - Block Diagram ............................... - 3 - Board Placement ............................- 3 - Mechanical Dimensions ..........................- 4 - Connectors and Pin-outs ............................ -
Page 4: Introduction
1. Introduction ACE-N510 is the smallest form factor carrier board in Aetina production line. Support for NVIDIA® Jetson™ TX2 and Jetson™ TX1. You can quickly emulate the functionality of your desired end product for software development and hardware verification. To build a functional prototype of your target system you will need: •... -
Page 5: Board Specification
2. Board Specification Specification ACE-N510 Description Module Compatibility Nvidia Jetson TX1 / Nvidia Jetson TX2 Jeston TX1 : Nvidia Maxwell , 256 CUDA cores. Jetson TX2 : Nvidia Pascal , 256 CUDA cores. Jetson TX1: Quad ARM® A57/2MB L2 Jetson TX2: HMP Dual Denver 2/2MB L2 + Quad ARM®... -
Page 6: Block Diagram
3. Block Diagram Board Placement - 3 -... -
Page 7: Mechanical Dimensions
TX1/TX2 Module Connector Compatible with Jetson TX1/TX2 HDMI Type A Euroblock Connector 2-pin DC in USB3.0 Type A CN21 CAN BUS x2 (10-pin) RJ45 USB2.0 OTG Micro-AB Front Panel+Expansion I/O(30-pin) 3.2 Mechanical Dimensions - 4 -... -
Page 8: Connectors And Pin-Outs
4. Connectors and Pin-outs 4.1 J1 (Front Panel and Expansion I/O) Pin number Define Pin number Define PIN 1 UART1_RXD_HDR_3V3 PIN 2 RS232_RXD PIN 3 UART1_TXD_HDR_3V3 PIN 4 RS232_TXD PIN 5 UART1_RTS_HDR_3V3 PIN 6 RS232_RTS PIN 7 UART1_CTS_HDR_3V3 PIN 8 RS232_CTS PIN 9 PIN 10... -
Page 9: Gpio Pin Define
PIN 15 FORCE_RECOVERY_L_R PIN 16 PIN 17 SLEEP_R PIN 18 PIN 19 VDD_3V3_SYS PIN 20 EXT_LED PIN 21 GPIO_1 PIN 22 PIN 23 GPIO_2 PIN 24 PIN 25 GPIO_3 PIN 26 PIN 27 GPIO_4 PIN 28 PIN 29 ACOK PIN 30 * In order to boot up the system, pleas quickly short-circuit Pin11 and Pin12. -
Page 10: Power Input (Euroblock Connector)
4.4 Power Input (Euroblock Connector) 4.5 Micro USB 4.6 Micro SD - 7 -... -
Page 11: Hdmi
4.7 HDMI - 8 -... -
Page 12: Accessary (Optional)
5. Accessary (Optional) Cable kit ACE-N510 Cable Kit(CAN bus / UART / RS232 / Front panel / GPIO) 9Z1253232020 TX1/TX2 Active Heat Sink 9Z2XX4141010 TX1/TX2 Passive Heat Sink 7W8000000040 Power cord. 9Z3BC0000020 100-240V 60W 12V 5A Adapter 7W3000000030 2.5mm DC JACK to Euroblock CABLE 200mm 9Z1253232020 9Z2XX4141010 9Z3BC0000020... -
Page 13: Software & Bsp
When customer use Nvidia standard BSP, some I/O function may not work. In order to support Aetina ACE-N510 system I/O config, please follow below method. (1) Before Installing the BSP you will need to install Jetpack on the x86 host system(UBUNTU14.04) Download the proper JetPack from https://developer.nvidia.com/embedded/downloads... - Page 14 BIOS flashes, firmware upgrades, or the like. Aetina assumes no obligation to update or otherwise correct or revise this information. However, Aetina reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of Aetina to notify any person of such revisions or changes.
