- Page 1 User Manual Nvidia Jetson Series Carrier board Aetina AN110...
- Page 2 Document Change History Version Date Description Authors 2020/02/18 Initial Release. Eric Chu...
- Page 3 1. Introduction Aetina AN110 is an exquisite carrier board for the Nvidia Jetson Nano module, the small low-power AI computer. As the most modest intelligent platform for the Nvidia series, this carrier board is only the size of 87 x 67 mm, will just right for edge AI computing needed nowadays.
-
Page 4: Board Specification
2. Board Specification Specification AN110 Description Module Compatibility Nvidia Jetson Nano/ Xavier NX Dimension 87mm x 67mm Display 1 x HDMI 1 x eDP Audio HDMI Integrated Ethernet 1 x Gigabit Ethernet(10/100/1000) 2 x USB3.2 Gen1 Type A 1 x USB OTG Micro AB... -
Page 5: Block Diagram
3. Block Diagram - 3 -... -
Page 6: Board Placement
3.1 Board Placement - 4 -... - Page 7 260-pin SO-DIMM. Compatible with Jetson Nano/ Xavier NX module HDMI 2.0b Type A USB3.2 Gen1 Type A x2 CN10 USB2.0 OTG Micro-AB x1 CN11 Euroblock connector for Power Input J505 M.2 2230 E Key FFC 15 pins for MIPI CSI-II 2LANES FFC 36 pins for MIPI CSI-II 4LANES RJ45 Debug UART...
-
Page 8: Mechanical Dimensions
3.2 Mechanical Dimensions - 6 -... -
Page 9: Connectors And Pin-Outs
4. Connectors and Pin-outs 4.1 J5 – UART/RS232/GPIO Pin Define Pin Define UART0_RXD_HDR_3V3 RS232_RXD UART0_TXD_HDR_3V3 RS232_TXD UART0_RTS_HDR_3V3 RS232_RTS UART0_CTS_HDR_3V3 RS232_CTS GND0 GND1 GPIO_1 GND2 GPIO_2 GND3 GPIO_3 GND4 GPIO_4 GND5 GPIO_5 GND6 GPIO Pin defin Sysfs GPIO(Nano) GPIO_1 GPIO149 GPIO_2 GPIO79 GPIO_3 GPIO200... - Page 10 4.3 CN5 - SPI Pin Define Pin Define SPI1_SCK_3V3 SPI1_MISO_3V3 SPI1_MOSI_3V3 SPI1_CS0_3V3 SPI1_CS1_3V3 VDD_3V3 4.4 CN6 – I2C/AC OK Pin Define Pin Define AC OK SOC_LED+ +3V3 I2C_DAT_3V3 I2C_CLK_3V3 4.5 CN12 – PSE Power Input Pin Define Pin Define PSE1+ PSE2+ PSE1- PSE2-...
- Page 11 4.7 CN2 – Debug UART Pin Define UART2_RXD_3V3 UART2_TXD_3V3 4.8 CN14 – eDP Power Selection Pin Define Default Setting is 12V 4.9 J8 – FFC 36pin MIPI CSI-II 4Lanes connector Signal Signal Signal Signal VDD_5V CSI_A_CLK_P CSI_A_D3_N SPI_EN_A VDD_5V CSI_A_CLK_N SPI_MOSI VDD_1V8 VSYNC...
-
Page 12: Accessary (Optional)
Signal Signal Signal CSI0_D1_P CAM0_PWDN CSI0_D0_N CAM0_MCLK CSI0_D0_P CSI0_CLK_N CAM_A_I2C_SCL CSI0_CLK_P CAM_A_I2C_SDA CSI0_D1_N VDD_3V3 5. Accessary (Optional) 7W8000000040 US Power Cord SVT 18AWG Cable 1800mm Black 105 °C 7W8000000050 EU Power Cord H05VV-F 0.75mm2/3G SL-6+SL-3 Cable 1800mm Black 9Z3BC0000020 100-240V 60W 12V 5A Adapter 9Z3BC0000020 - 10 -... - Page 13 BIOS flashes, firmware upgrades, or the like. Aetina assumes no obligation to update or otherwise correct or revise this information. However, Aetina reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of Aetina to notify any person of such revisions or changes.
