Summary of Contents for Idis DR-1500 Series
- Page 1 Network Video Recorder Quick Guide DR-1504P DR-1504P-A DR-1508P DR-1508P-A Powered by...
-
Page 2: Safety Precautions
Safety Precautions Important Safeguards 14. Damage requiring Service Unplug this equipment from the wall outlet and refer servicing to qualified 1. Read Instructions service personnel under the following conditions: All the safety and operating instructions should be read before the A. -
Page 3: Fcc Compliance Statement
IDIS Co., Ltd. reserves all rights concerning this document. Use or duplication of this document in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this document are subject to change without prior notice for reasons such as functionality enhancements. - Page 4 Quick Guide Optical USB Mouse Please download IDIS Center software and product manual from this link : - IDIS Website (www.idisglobal.com) Overview Dimensions (Unit - mm) The IDIS logo should be positioned correctly when fixing the product to the wall.
- Page 5 Rear Panel DR-1504P DR-1508P USB Port HDMI Out Port VGA Out Port Network Port Video In / PoE Ports Power In Port Connections on the Rear Panel HDMI Monitor USB HDD VGA Monitor Network Camera IDIS Center Remote Keyboard Monitoring Power...
-
Page 6: Getting Started
Getting Started ● H.265 Camera Codec Setup Setup Wizard • Setup Wizard only appears during initial booting. When you login as an administrator account after initial booting, you can use Wizard to go to Live menu and select Wizard. ● Finish the Quick Setup Wizard •... - Page 7 ● Scan Refresh Interval: Configures the refresh interval to scan the camera. ● Third Party Scan: Used to Scans for IDIS Open cameras that do not support automatic scan feature. - Protocol: Select the protocol used by the camera (or video encoder) you wish to search for.
- Page 8 Enter Verification Code and select OK. Apply/Cancel Buttons While in Camera Registration mode, select Apply to register all changes. Select Cancel to exit Camera Registration mode without applying the changes. It is not possible to register a camera that has already been registered to a different NVR.
-
Page 9: Basic Feature
Lapse Search or Event Log Search Search. The selected search mode will be initiated. Records the live video. Refer to the manual for more information. IDIS Center Program Panic Recording System Requirements Select Live or Search menu's Panic Recording icon to commence panic recording on all registered cameras. -
Page 10: Installation
Close and finish the installation. Device Registration Start Program To use the functions provided by IDIS Center, you must first When IDIS Center software is installed, IDIS Center and register a device and add the device to a device group. - Page 11 Make sure that the device has been added to the device group correctly. Click Device Group on the Sites panel and click on next to Device Group. When you click on a registered device group, a list of devices added the selected device group will be displayed on the right.
- Page 12 Open the App Store on your device. This service requires heavy data traffic, and using a Wi-Fi connection is recommended. Using wireless Enter IDIS Mobile Plus in the search filed of the App internet (3G, LTE) may result in excessive data charges. Store.
- Page 13 Installing or Replacing the HDD You can install an additional HDD or replace an HDD with an existing drive if necessary. (Image below is for illustrative purposes only and may differ from the actual product.) Please follow these steps to add or replace an HDD in an actual place where users use the product. Remove the screws from the bottom and Remove the 4 screws from the bottom of real panel.
- Page 14 Assemble the top cover to the body and secure the 4 hooks on the bottom of the product. Tighten the screws from the bottom and real panel.
-
Page 15: Specifications
PoE(IEEE 802.3at class 4) supported 8 ports, 70W (DR-1508P-A) Camera Power PoE(IEEE 802.3at class 4) supported 4 ports, 30W (DR-1504P) PoE(IEEE 802.3at class 4) supported 4 ports, 35W (DR-1504P-A) Email (attach clip (.cbf) .MP4), Callback to Remote S/W, Push notification (IDIS Mobile), Event Notification HTTP INTERFACE... - Page 16 Internal Buzzer * USB 2.0 x 2 (USB port cannot be used for charging. (Max. 0.5W)) GENERAL Operating System Embedded Linux Unit Dimensions 205mm x 44.5mm x 216.4mm (8.07” x 1.75” x 8.52”) (W x H x D) DR-1508P: 1.38kg (3.04 lb) (3.5” 4TB HDD) Unit Weight DR-1504P: 1.36kg (3.00 lb) (3.5”...
- Page 17 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
