  • Page 1 Network Video Recorder Installation Manual DR-8364 DR-8364D DR-8364F DR-8364FD Powered by...
  • Page 2 Before reading this manual This manual contains basic instructions on installing and using DirectIP™ Network Video Recorder, an IDIS product. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Before reading this manual Important Safeguards 1. Read Instructions All the safety and operating instructions should be B. If liquid is spilled, or objects have fallen into the equipment. read before the appliance is operated. C. If the equipment has been exposed to rain or water. 2.
  • Page 4 Before reading this manual In-Text Symbol Type Description Caution Important information concerning a specific function. Note Useful information concerning a specific function. User’s Caution Statement Caution: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
  • Page 5 IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice.

  • Page 6: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 7 Product Features .

  • Page 7: Part 1 - Introduction

    Part 1 – Introduction Product Features This is a DirectIP™-enabled video recorder that supports surveillance, recording, and playback of video from network cameras (or video encoders). This NVR (Network Video Recorder) unit offers the following features: ● Real-time 64 channel DirectIP™ network surveillance ●...
  • Page 8 Part 1 – Introduction VGA Monitor HDMI Monitor Audio Out DirectIP™ Gigabit Network PoE Switch Camera USB HDD Flash Memory Network Camera Alarm Out Network Video Recorder Analog Alarm Video Encoder Camera Sensor (1-4) Mouse Network Connection IR Remote Control...

  • Page 9: Accessories

    Part 1 – Introduction Accessories Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included. Network Video Recorder Power Cable Quick Guide Optical USB Mouse IR Remote Control (Optional)

  • Page 10: Overview

    Part 1 – Introduction Overview Front Panel Panic Recording SATA LED Status LEDs USB Ports Button Power LED Front Door Lock Rack Mount Ears • Some buttons have more than one function. • Remote control sensor is located on the left side of the front panel. Ensure that the sensor remains unobstructed at all times.
  • Page 11 Part 1 – Introduction 4 USB Ports 5 Power LED ● Storage Device Connection Lights up while the main unit is in operation. Connect an external USB hard drive or a USB flash memory device to one of the USB ports for use with the Clip Copy feature.
  • Page 12 Part 1 – Introduction RAID Configuration Precautions The four types of RAID configuration supported are as follows. *R1(1,2), R1(5,6) Configuration 1 HDD connection to Internal SATA Port 1,2,5,6 R1(1,2), R1(3,4), R1(5,6), R1(7,8) Configuration 2 After setting Configuration 1, add HDD to Internal SATA Port 3,4,7,8 R5(1,2,3,4), R5(5,6,7,8) Configuration 3...

  • Page 13: Dimensions

    Part 1 – Introduction Dimensions Unit : mm...

  • Page 14: Rear Panel

    Part 1 – Introduction Rear Panel DR-8364/DR-8364F DR-8364D/DR-8364FD Video In Ports Power In Port Network Port - SFP (1~2) / RJ45 (3~5) eSATA Ports USB 3.0 Ports Audio Connection Ports VGA Out Port HDMI Out Port Alarm Connection Ports RS-485 Port...
  • Page 15 Part 1 – Introduction * (This table is only for the DR-8364D/DR-8364FD model) The LED and Buzzer Control Rules of Redundant Power Condition Power Module #1 Power Module #2 Buzzer AC Cord Included / Not Included Power Module #1 Power Module #2...

  • Page 16: Rear Panel Connections

    Part 1 – Introduction Rear Panel Connections Video Connection ● SFP Video In Port These ports are used to connect to higher devices that Power Cable Connection are some distances away via optical cables. You can Connect the power cable to this port. This NVR does not connect Gigabit Fiber Media Converters (Optional: feature a separate power on/off button and will turn on DA-MC1101) or external hubs (Optional: DH-2112PF,...
  • Page 17 Note 1000 BASE-T network. Orange LED on the left will then support only RAID 10, RAID 5 and IDS1004 IDIS flash once a link has been established. port multiplier is not supported For stable video transmission, it is recommended Do not connect or disconnect an eSATA device while to connect less than 32 network cameras or video the NVR is powered on.
  • Page 18 Part 1 – Introduction Use the AUDIO IN port to establish two-way ● Alarm In 1 through 4 communication with cameras. This NVR is capable of responding to event signals from exterxnal alarm in devices. Connect mechanical or • This NVR does not feature a built-in audio amplifier electrical switches to AI 1 through 4 and the G (ground) unit and therefore requires the user to purchase a connector.
  • Page 19 Part 1 – Introduction ● NC/NO (Relay Alarm Outputs) RS-485 Connection This NVR is capable of activating/deactivating buzzers, This NVR supports the RS-485 half-duplex serial lights, and other external devices. Connect the device to communication protocol for connecting to external the C (Common) and NC (Normally Closed) or C and NO devices such as POS units.
  • Page 20 Part 1 – Introduction Connections on the Rear Panel Power Network Camera DirectIP™ Gigabit PoE Switch Network eSATA Storage Camera Device Microphone Network Sensor IDIS Center Remote Monitoring Speaker Keyboard Alarm VGA Monitor HDMI Monitor...

  • Page 21: Remote Control

    Remote Control (Optional) ID Button PANIC Button Camera Buttons STATUS Button LAYOUT Button PTZ Control Buttons REGISTER MODE Button THUMBNAIL Button CALENDAR Button KEYLOCK Button SETUP Button FREEZE Button LOG Button Enter Button Arrow Buttons ALARM Button SEQUENCE Button & ZOOM Button PTZ Button &...
  • Page 22 Part 1 – Introduction 1 ID Button 7 REGISTER MODE Button Used to assign remote control ID values. Used in Live mode to access Camera Registration mode. No additional remote control assignment is necessary if the system's ID is 0. If the system's ID is a number 8 THUMBNAIL Button between 1 and 99, however, you will need to press the Used in Playback mode to access Thumbnail Search...
  • Page 23 Part 1 – Introduction $ Enter Button b MENU Button Pressing the MENU button while in Live mode Used to make menu option selections and register data entries. In addition, pressing this button while displays the Live menu. Alternatively, pressing the a camera screen is selected by pressing the Menu button while in Time-lapse Search mode displays the button in Live or Playback mode displays the Camera...

  • Page 24: Part 2 - Appendix

    Part 2 - Appendix Supported SFP Transceiver Module List The system's SFP ports support the following types of SFP modules: Wavelength Standard Diameter (um) Length Mode Connector SFP Module (nm) 50/125 550m Multi ATOP 1000BASE-SX APSB85123CDL05 62.5/125 500m Multi ATOP 1000BASE-LX 9/125 1310...

  • Page 25: System Log Types

    Part 2 - Appendix System Log Types Boot Up Panic On System Shutdown Panic Off Restart Clear All Data Upgrade Success Clear Disk Upgrade Error Format Disk Power Failure Disk Full Time Changed Auto Deletion Time Zone Change Search Begin Time Sync.

  • Page 26: Error Code Types

    Part 2 - Appendix Error Code Types Upgrade Error Codes Type Type Unknown Error Remote Network Error Incorrect File Version No Remote Upgrade Permission Incorrect OS Version Remote Upgrade File Save Failure Incorrect Software Version Remote Upgrade Cancelled by User Incorrect Kernel Version USB Storage Device Mount Failure Storage Device Mount Failure...
  • Page 27 Part 2 - Appendix Clip Copy Error Codes Type Type Unknown Error Disk Error Device Error Clip Player Execution File Not Found Device Connection Failure Clip Player Execution File Access Failure CD Media Not Found Clip Player Execution File Save Failure Incorrect Media Image Generation Failure File Name Taken...
  • Page 28 Part 2 - Appendix Network Error Codes Type Type Cause of Failure Unknown Connection Cancelled by User Normal Logout No Response from Network Device Host All Channels in Use - Connection Denied High Network Noise Level Incorrect Product Version Info Transmission Queue Full Incorrect User Name or Password Incorrect OEM Info...

  • Page 29: Troubleshooting

    Part 2 - Appendix Troubleshooting Problem Solution ● Check the power cable connection status. The main unit won't turn on. ● Check the power outlet. ● Check the camera's video cable connection status. ● Check the monitor's video cable connection status. Unable to display Live video.

  • Page 30: Specifications

    Video in Connection Gigabit Ethernet(Video In) x3, SFP(Video In ) x 2 Transmission Speed 400Mbps / 500Mbps(BRP Mode) Email (attach clip (.cbf ) .MP4), Callback to Remote S/W, Push notification (IDIS Event Notification Mobile) INTERFACE Local(NVR) : 1 RCA / 1RCA + 1HDMI...
  • Page 31 Part 2 - Appendix GENERAL Operating System Embedded Linux Unit Dimensions 482.6mm x 88mm x 523.3mm (19"x3.5"x20.6") (W x H x D) 10.9kg (24.03lb) (with 2 HDDs) DR-8364(F) Unit Weight 12.3kg (21.12lb) (with 2 HDDs) DR-8364(F)D Working Temperature 0°C to 40°C Operating Humidity 0% ~ 90% 100-240V~, 6-3A, 50/60Hz...
  • Page 32 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...

This manual is also suitable for:

Dr-8364Dr-8364fDr-8364fd

Table of Contents
