USER INSTRUCTION MANUAL
SELF
RETRACTABLE
LIFELINE
MADE IN INDIA
This instruction manual
applies to the following models:
PCWB 11FT-SK, PCGS 10FT-SK, PCGS 60FT(R)-SK,
PCGS 18FT(LE)-SK, PCGS 20FT(LE)-SK, PCWB 20FT-SK,
PCGS 25FT(LE)-SK, PCGS 30FT(LE)-SK, PCWB 30FT-SK,
ELE06FT-SK, ELE06FT-SKRebar
ANSI Z359.14
BKLSKR 04-02
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ANSI PCWB 11FT-SK
Summary of Contents for ANSI PCWB 11FT-SK
- Page 1 USER INSTRUCTION MANUAL SELF RETRACTABLE LIFELINE MADE IN INDIA This instruction manual applies to the following models: PCWB 11FT-SK, PCGS 10FT-SK, PCGS 60FT(R)-SK, PCGS 18FT(LE)-SK, PCGS 20FT(LE)-SK, PCWB 20FT-SK, PCGS 25FT(LE)-SK, PCGS 30FT(LE)-SK, PCWB 30FT-SK, ELE06FT-SK, ELE06FT-SKRebar ANSI Z359.14 BKLSKR 04-02...
- Page 2 This manual must be read and understood in its entirety and used as part of fall protection training program as required by OSHA or any state regularity agency. These instructions are intended to meet the manufacturer instructions as required by ANSI Z 359.14 and OSHA 1926. The user must fully understand the proper equipment use and limitations.
- Page 3 Conforms for the vertical usage as per ANSI Z 359.14-2014 and Horizontal usage as per ANSI Z 359.14-2014 SRL-LE Ÿ Connect the end of Lifeline, adjacent to Energy Absorber, to the dorsal attachment of the body support.
- Page 4 All authorized persons/users must refer the regulations governing occupational safety, as well as applicable ANSI or CSA Ÿ standards. Please refer to product labeling for information on specic OSHA regulations, ANSI and CSA standards met by product. Proper precautions should always be taken to remove any obstructions, debris, material, or other recognized hazards from the Ÿ...
- Page 5 operations of this equipment in any environment, contact SAFE KEEPER for further instructions. Ÿ Do not use the equipment near sharp edges and abrasive surfaces. Ÿ Do not use the equipment around moving machinery or electrical hazards. SAFE KEEPER Self Retractable lifeline should be used only with the combinations of components, sub-systems or both which Ÿ...
-
Page 6: Description Of Product
DESCRIPTION OF PRODUCT: Retractable: All SAFE KEEPER Retractables are hereby referred to as Self Retracting Lifelines (SRL). The device is used to safely expand the working area where a harness with a 6 ft. lanyard is not adequate. Also, a SRL is designed to reduce the shock loading to the body of a worker by limiting the distance of a fall. -
Page 7: System Requirements
Consult regulatory agencies for more information on personal fall arrest system and associated components. This product is designed to comply with OSHA and ANSI Z359.14 standards when used properly, and in accordance with manufacturer's instructions. - Page 8 Personal Fall Arrest System (PFAS): Personal fall arrest systems used with this equipment must meet applicable state, federal, OSHA, and ANSI requirements. A full body harness must be worn when this equipment is used as a component of a personal fall arrest system.
- Page 9 3,600 lbs. with certication of a qualied person, or 5,000 lbs. without certication. Refer to OSHA and ANSI for specic denition. This device is only to be used by one person. When more than one personal fall arrest system is attached to the same structure, the strength requirements stated above must be multiplied by the number of personal fall arrest systems attached to the structure.
- Page 10 After a Fall Arrest: Inspect the impact indicator on the snap hook of the SRL and look for an exposed red color band. Do Ÿ not attempt to reset the impact indicator. Remove the retractable from service immediately and return to SAFE KEEPER or an authorized repair center.
- Page 11 Ÿ After a Fall: Components which have been subjected to the forces of arresting a fall must be removed from service and destroyed. Retractable must be returned for servicing to SAFE KEEPER or an authorized repair center. Rescue: The employer must have a rescue plan when using this equipment. The employer must have the ability to perform Ÿ...
- Page 12 Made In India WARNING:: To maintain the longetivity of the self-retractable blocks, SAFE KEEPER strongly recommends to get them serviced at a Ÿ SAFE KEEPER Authorized Service Centre only. If not, SAFE KEEPER shall not be liable for any warranty claims. Alternation or misuse of this product or failure to follow instructions may lead to serious injury or even death.
- Page 13 LIFESPAN: The estimated product Lifespan is 10 years from the date of manufacturing. The following factors can reduce the Lifespan of the product: intense use, contact with chemical substances, specially aggressive environment, extreme temperature exposure, UV exposure, abrasion, cuts, violent impacts, bad use or maintenance. DISCLAIMERS: This information on the product is based upon technical data that SAFE KEEPER obtained under laboratory conditions and believes to be reliable.
- Page 14 SAFE KEEPER, 314 E. CANAL ST. MULBERRY, FL 33860...
