Sennheiser evolution e835 Instructions For Use Manual
Hide thumbs
Also See for evolution e835:
- User manual ,
- Instructions for use manual (12 pages) ,
- Instruction manual (9 pages)
Related Manuals for Sennheiser evolution e835
Summary of Contents for Sennheiser evolution e835
- Page 1 835 S Bedienungsanleit ung Instructions for use Notice d‘emploi Istruzioni per l‘uso Inst rucciones para el uso Gebruiksaanwijzing...
- Page 3 Deutsch English Français Italian Español Nederlands...
- Page 5 835 / 835 S 835 is a cardioid lead vocal stage microphone specially designed to perform under pressure. Its balanced frequency response maintains signal qualit y when moving on and off axis during performance. The gentle presence boost ensures vocal clarity and projection.
-
Page 6: Delivery Includes
Feat ures Rugged met al body Excellent feedback rejection Shock-mounted capsule provides excellent suppressi- on of handling noise Uniform on- and off-axis response C ardioid pick-up pattern provides isolat ion from other on-stage signals Humbucking coil Delivery includes 835 / 835 S microphone MZQ 800 microphone clamp Pouch... - Page 7 Pin assignment of XLR-3 connect or 6,3 mm 6,3 mm balanced symmetrisch Removing t he sound inlet basket...
-
Page 8: Posit Ioning T He Microphone
Posit ioning t he microphone Posit ion Result ing sound C omment ary High proximity effect Very little crosstalk (much bass/ from other sound fundamental) sources Powerful, direct sound Less proximity effect More crosstalk from (less bass/ fundamental) other sound sources Some room ambience, natural, balanced sound Very little proximity... -
Page 9: Polar Diagram
Polar diagram ° 30° 30° 60° 60° 90° 90° 120° 120° 150° 150° 180° 2000 Hz 125 Hz 250 Hz 4000 Hz 500 Hz 8000 Hz 16000 Hz 1000 Hz Frequency response curve - 40 - 50 - 60 - 70 - 80 - 90 500 1000 2000... - Page 10 Specificat ions Transducer principle dynamic Frequency response 40..16,000 Hz Pick-up pattern cardioid Sensit ivit y (free field, no load at 1 kHz) 2.7 mV/ Pa 350 Ω Nominal impedance Min. terminat ing impedance 1 kΩ C onnector XLR-3 Weight 330 g Dimensions Ø...
- Page 11 Overview of microphone applicat ions Variant Applicat ion Vocals C hoirs St udio, acoustic instruments Orchest ra Brass / Saxophone Acoustic guitar Acoustic bass Guitar amplifiers Bass amplifiers Leslie Piano, grand piano Kick drums Snare drums Rack toms Floor toms C ongas C ymbals Percussion...
-
Page 12: Manufacturer Declarations
Manufact urer declarat ions Warrant y 2 years Approval Sennheiser electronic GmbH & C o. KG declare that this device is in compliance with the applicable C E standards and regula- tions. WEEE Declarat ion Please dispose of this product at the end of its operational li- fetime by bringing it to your local collection point or recycling centre for such equipment. - Page 14 Sennheiser electronic GmbH & C o. KG 30900 Wedemark, Germany Phone +49 (5130) 600 0 Fax +49 (5130) 600 300 www.sennheiser.com Printed in Germany Publ. 01/ 06 511655/ A03...
