- Page 1 865 S Bedienungsanleitung Instructions for use Notice d‘emploi Istruzioni per l‘uso Instrucciones para el uso...
- Page 2 Bedienungsanleitung.............. 3 Instructions for use ...............11 Notice d’emploi ..............19 Istruzioni per l’uso..............27 Instrucciones para el uso............35 Gebruiksaanwijzing...............43...
- Page 3 865 / 865 S 865 is a fully professional vocal microphone utilising the very best in condenser microphone technology to achieve new standards of quality and sound. An extended dynamic range and a super-smooth frequency response deliver an outstanding signal quality with excellent vocal projection and the lowest possible distortion.
-
Page 4: Delivery Includes
Features Rugged metal body Extended dynamic response with pronounced presence and vocal “punch” Excellent feedback rejection Very good suppression of handling noise Very high sound pressure handling capability Delivery includes 865 microphone MZQ 800 microphone clamp Pouch Instructions for use Warranty Certificate ON/OFF switch ( 856 S only) Use the screw to lock the switch in the ON position. - Page 5 Pin assignment of XLR-3 connector 6,3 mm balanced symmetrisch Removing the sound inlet basket...
- Page 6 ositioning the microphone Position Resulting sound Commentary High proximity effect Very little crosstalk (much bass/ from other sound fundamental) sources Powerful, direct sound Less proximity effect More crosstalk from (less bass/fundamental) other sound sources Some room ambience, natural, balanced sound Very little proximity Much crosstalk from effect (little bass/...
-
Page 7: Polar Diagram
Polar diagram ° 30° 30° 60° 60° 90° 90° 120° 120° 150° 150° 180° 125 Hz 2000 Hz 250 Hz 4000 Hz 500 Hz 8000 Hz 16000 Hz 1000 Hz Frequency response curve - 40 - 50 - 60 - 70 - 80 - 90 500 1000 2000... -
Page 8: Specifications
Specifications Transducer principle pre-polarised condenser microphone Frequency response 40..20.000 Hz Pick-up pattern super-cardioid Sensitivity (free field, no load at 1 kHz) 3 mV/Pa 200 Ω (balanced) Nominal impedance 100 Ω (unbalanced) Min. terminating impedance 1 kΩ Max. sound pressure level at 1 kHz 150 dB/SPL Phantom powering... -
Page 9: Overview Of Microphone Applications
Overview of microphone applications Variant Application Vocals Choirs Studio, acoustic instruments Orchestra Brass / Saxophone Acoustic guitar Acoustic bass Guitar amplifiers Bass amplifiers Leslie Piano, grand piano Kick drums Snare drums Rack toms Floor toms Congas Cymbals Percussion Overheads... - Page 11 Sennheiser electronic GmbH & Co. KG erklären, dass dieses Gerät die anwendbaren CE-Normen und Vorschriften erfüllt. Approval Sennheiser electronic GmbH & Co. KG declare that this device is in compliance with the applicable CE standards and regulations. Certification Sennheiser electronic GmbH & Co. KG déclarons que cet appareil est en conformité...
- Page 12 Sennheiser electronic GmbH & Co. KG 30900 Wedemark, Germany Phone +49 (5130) 600 0 Fax +49 (5130) 600 300 www.sennheiser.com Printed in Germany Publ. 06/05 511658/A02...
