Product introduction
Motherboard overview
•
•
•
•
Place this
side towards
the rear of the
chassis
Scan the QR code to get the detailed pin definitions.
1-1
Unplug the power cord from the wall socket before touching any component.
Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.
Unplug the power cord before installing or removing the motherboard. Failure to do so
can cause you physical injury and damage to motherboard components.
1
2
CPU_FAN
DC_PWR
HDMI1
HDMI2
DP
LAN_USB3_45
Intel
®
I219V
17
BLKT_PWR_SEL
BATT_CON
VCC_PWR_SEL
PANEL_SW
16
15
14
3
14.7cm(5.8in)
DIGI
+VRM
LGA1151
ASM1480
Intel
®
H110
2280
2230
LVDS
CHA_FAN
LCD_BLKT_PANEL
13
12
2
1
4
5
MIC IN
USB3_C1
M.2(WIFI)
USB3_3
Super
I/O
AUDIO
128Mb
ALC
BIOS
3236
TPM
F_PANEL
COM
11
10
9
8
ASUS H110S1
6
7
