Summary of Contents for joule EcoHeat 160L
- Page 1 Joule EcoHeat 160L, 200L, 260L Installation & Maintenance Manual REGISTER THIS PRODUCT ONLINE WITHIN 28 DAYS OF COMMISSIONING UNITED KINGDOM / IRELAND JG-INS-DHW-002 UK Manufactured Unvented Hot Water Cylinder Installation Guide https://register-products.joule.ie...
- Page 2 Heat Pump has been tested to EN 16147 :2017+A1:2022 and the function of all Safety devices has been verified. • WARNING, CAUTION, DANGER removing the front cover of the appliance will give access to live parts! Please read maintenance section in this manual before use www.jouleuk.co.uk | www.joule.ie...
- Page 3 Preface Dear installer, You are about to install a Joule Ecohet hot water heat pump. This system shall only be commissioned by a qualified installer. You the installer must have been trained by Joule. Systems installed by untrained installers will have no warranty guarantee.
- Page 4 Is the system safe to operate? Is there adequate access and free space to the system for the purposes of operation and maintenance? Has the system been left in reasonably clean condition? Are all components in good condition? www.jouleuk.co.uk | www.joule.ie...
- Page 5 Installation Checklist General Is the installation complete with no obvious defects present? Has all protection/packaging been removed such that the system is fully functional? For ducted systems, has ductwork been installed in such a manner that air resistance and leakage is kept to a minimum? Is the ductwork fitted to the correct connections on the heat pump? Has the heat pump and all its ductwork been effectively insulated? Is all pipework connected correctly?
-
Page 6: Table Of Contents
EcoHeat Electrical Schematic ....................... 29 Commissioning the EcoHeat Unit ....................30 Commissioning Controller ......................31 Maintenance of the EcoHeat ......................43 Spare Parts ..........................45 Warranty ............................ 49 Benchmark Checklist ........................52 Service Record ........................... 54 Notes ............................56 www.jouleuk.co.uk | www.joule.ie... -
Page 7: Introduction
These instructions consist of details for installation, servicing, fault finding and replacement of parts for the unit purchased. JOULE will not accept any liability in the event of damage for not complying with the guidance in this instruction manual. - Page 8 A thermostatic mixer should be installed in the system to prevent the risk of scalding. If there are leaks found in the system, shut off the cold water stop valve from the main supply and contact a competent person immediately. www.jouleuk.co.uk | www.joule.ie...
- Page 9 Hot Water Industry Council who manage and promote the scheme. Visit www.centralheating.co.uk HWA Charter Member Joule are proud to be a charter member of the the Hot Water Association (HWA), that has been formed through the union of the two UK industry trade bodies, WMA (Water Heater Manufacturers Association) and MODUS (Manufacturers Of Domestic Unvented Systems).
- Page 10 Consideration should be given to upgrading existing 1⁄2” (15mm) cold mains pipework to a larger size if the recommended minimum pressure / flow rate is not being achieved. JOULE recommend that primary pipework used has a minimum diameter of 22mm to ensure low pressure loss.
- Page 11 Water Chemistry This water heater must be installed in accordance with this advice to be covered by the Joule warranty. This water heater is manufactured to suit the water conditions of most public reticulated water supplies. However, there are some known water chemistries which can have detrimental effects on the water heater and its operation and/or life expectancy.
- Page 12 TDS, in mg/L, is approximately 70% of the conductivity in μS/cm. The JOULE warranty will not cover resultant faults to the storage unit if this water heater is connected at anytime to a water supply where the TDS content of the water exceeds 600 mg/L. 16 In locations where TDS approaches 600 mg/L, e.g.
- Page 13 The Type Plate The Type Plate provides information about the unit. The Type Plate is located in two places on and in the EcoHeat unit shown: EcoHeat Type Plate: Article Number Indicates the exact model version of that specific unit UK Manufactured Unvented Hot Water Cylinder Installation Guide...
- Page 14 The symbols on the Type Plate and on the EcoHeat mean the following: CE MARKING This is the CE logo with which Joule indicates that the product meets the legal requirements. FOR INDOOR USE ONLY This symbol indicates that the EcoHeat may only be used indoors.
-
Page 15: Ecoheat Dimensions
H = 1609mm ECOHEAT 260 H = 1863mm 1000mm 561,19mm 524,26mm 100m DIMENSIONS AND WEIGHT Height (x) 1297 1527 1945 JOULE SOLUTIONS Width ECOHEAT STANDARD Depth EcoHeat Model: FOOTPRINT DRAWING Weight ECOHEAT 200 H = 1609mm CONNECTIONS ECOHEAT 260 H = 1863mm... -
Page 16: Technical Specification
(1.5 m) (1.5 m) (1.5 m) PERFORMANCE Max. water temp. HP/ °C 55/70 55/70 55/70 HP+Immersion Energy Efficiency Class Load Profile SCOP(14°C) REFRIGERANT Refrigerant Type R134a R134a R134a Refrigerant content GWP Value 1430 1430 1430 C02 equivalent www.jouleuk.co.uk | www.joule.ie... - Page 17 INSTALLATION ROOM Max. permissible air humidity installation room Max. allowed temperature Min. allowed temperature CONNECTIONS Air inlet/outlet 150/160/200 150/160/200 150/160/200 Hot water outlet Inch ¾” ¾” ¾” T&P Inch ½” ½” ½” Cold water inlet Inch ¾” ¾” ¾” Coil connections Inch ¾”...
-
Page 18: Pre-Installation Notes
In order to prevent electric shocks, fires or injuries, always stop the unit, disable the protection switch and contact Joule’s technical support if the unit produces smoke, if the power cable is hot or damaged, or if the unit is very noisy. - Page 19 • To avoid your hands being injured by the edge of the parts wear protective gloves to unpack, move, install, and service the unit. Do not touch the internal parts (water pipes, refrigerant pipes, heat exchangers, etc) while running the units. If you need to adjust and touch the units, allow sufficient time for the unit to cool and be sure to wear suitable personal protective equipment.
-
Page 20: First Fix Notes
• The Heat Pump must be installed vertically and be plumb and level. Tank Immersions connected to the EcoHeat must have a power input of 3kW or less www.jouleuk.co.uk | www.joule.ie... -
Page 21: Instalation Location
Installation Location Restrictions around the EcoHeat Heat Pump Certain clearance distances must be adhered to prior to citing an area for installing the unit. Clearance is required to provide sufficient space for installation and maintenance. Minimum Required space around the Eco-Heat Unit min. - Page 22 Ductwork – Supply Air The Supply Air or ‘Air In’ to the Heat Pump is the heat source to the Heat Pump system. The extract air is fed via the ductwork to the Heat Pump from outside the dwelling. www.jouleuk.co.uk | www.joule.ie...
- Page 23 Ductwork – Exhaust Air The Exhaust Air or ‘Air Out’ from the Heat Pump is the exhaust of the cooled air from the Heat Pump to outside the dwelling. It is essential both Supply & Exhaust duct is. When the duct passes through ceiling voids, condensation on the outside of the duct will occur.
-
Page 24: Ventilation Connection
A ceiling void is not considered an unheated space as it is directly above a heated space. Ductwork – Exhaust in heated Spaces Any exhaust ductwork passing through a heated space must be suitably insulated to avoid condensation and/or heat gain. www.jouleuk.co.uk | www.joule.ie... -
Page 25: Ecoheat Schematic
EcoHeat Schematic Mechanical Diagram Description EcoHeat Unit Inlet Control Group Potable Expansion Vessel Mains/Boosted Cold Inlet Balanced Cold Outlet Cylinder Cold Feed Condensate/T&P Safety waste Hot Water Outlet Safety relief valve UK Manufactured Unvented Hot Water Cylinder Installation Guide... -
Page 26: General Pipework
1. Connect the drain hose supplied to the 2. Depending on your installation, the drain condensate connection of the heatpump (A). hose can exit the product at points (B1) (B2). 3. Make sure the drain hose is above the water level of the siphon. www.jouleuk.co.uk | www.joule.ie... -
Page 27: Ecoheat Electrical Connections
EcoHeat Electrical Connections Power Specification Unit Volts Phase Starting Current Mains Fuse EcoHeat 160//200/260 Single 10 Amp 16 Amp • The Heat Pump MUST be connected to the mains through a suitably sized RCBO. • The power cable is pre-wired from the Heat Pump. •... - Page 28 Heat Pumps electronics. If the power cable is damaged, contact Joule to have it repaired before powering On the Heat Pump. The electrical installation must be carried out by a suitably qualified electrician or under the supervision of one.
-
Page 29: Ecoheat Electrical Schematic
EcoHeat Electrical Schematic 8. ELECTRICAL CONNECTION The power supply of the system is 230 V/1/50 Hz. The power line must be protected by a The power supply of the system is 230 V/1/50 Hz. The power line must be protected by a circuit breaker of 2 poles / 16 A. -
Page 30: Commissioning The Ecoheat Unit
To be able to commission the EcoHeat system correctly specific knowledge is required. If you are not certified by Joule, you may not put the EcoHeat into operation. To be certified by Joule the installer must have successfully completed the Joule EcoHeat training course. If you do not meet these requirements, please contact Joule directly to enquire about booking a place in one of our training sessions. -
Page 31: Commissioning Controller
Commissioning Controller 9. COMISSIONING. CONTROLLER. 9.1. User interface description User interface description D E S C R I Symbol Meaning when it lights Symbol Meaning when it lights Compressor switched on Compressor switched on Defrost active Defrost active Fan switched on Fan switched on Alarm active Alarm active... - Page 32 To switch off the system, hold the key for 4 seconds key for 4 seconds key for 4 seconds 9.3. Switching OFF ECOHEAT INSTALLATION AND USER MANUAL ECOHEAT INSTALLATION AND USER MANUAL www.jouleuk.co.uk | www.joule.ie ECOHEAT INSTALLATION AND USER 9.3. Switching OFF...
- Page 33 9.4. Unlockin Unlocking the keypad 9.4. Unlocking the keypad 9.4. Unlocking the keypad When 30 have elapsed without the keys being When 30 have elapsed without the keys being pressed, the display will show the ‘’ LOC’’ label and the keypad will lock automatically pressed, the display will show the ‘’...
- Page 34 The screen will show again the water temperature The screen will show again the water temperature ECOHEAT INSTALLATION AND USER MANUAL ECOHEAT ECOHEAT INSTALLATION AND USER MANUAL INSTALLATION AND USER MANUAL www.jouleuk.co.uk | www.joule.ie ECOHEAT ECOHEAT INSTALLATION AND USER MANUAL INSTALLATION AND USER MANUAL...
- Page 35 9.7. ECO Mode ECO Mode 9.7. ECO Mode 9.7. ECO Mode 9.7. ECO Mode ECO mode: Maximum savings . The system h eats water only by heat pump technology. ECO mode: Maximum savings . The system h eats water only by heat pump technology. 9.7.
- Page 36 Touch to confirm or to cancel Touch key and select SP1. Touch to confirm. The display will show the programmed temperature www.jouleuk.co.uk | www.joule.ie ECOHEAT INSTALLATION AND USER MANUAL ECOHEAT INSTALLATION AND USER MANUAL ECOHEAT ECOHEAT INSTALLATION AND USER MANUAL...
- Page 37 Select this mode to achieve a fast heating by using simultaneously heat pump and ele heater. This mode Works as a rapid heating. Once the setpoint temperature is re system returns to the initial mode. OVERBOOST Mode If Overboost mode is switched on when the system Works from ECO mod Select this mode to achieve a fast heating by using simultaneously heat pump and electric heater.
- Page 38 ECOHEAT INSTALLATION AND USER MANUAL desired temperature Touch to confirm or to cancel ECOHEAT INSTALLATION AND USER MANUAL Touch to confirm or to cancel ECOHEAT INSTALLATION AND USER MANUAL ECOHEAT INSTALLATION AND USER MANUAL www.jouleuk.co.uk | www.joule.ie...
- Page 39 The water temperature set point in ECO mode can be changed with the SP1 parameter. Touch key and select SP1. T Touch key and select SP1. Touch to confirm. 9.7. ECO Mode to confirm. 9.7. ECO Mode ECO mode: Maximum savings . The system h eats water only by heat pump technology. Parameter SP3 allows to set the minimum temperature that Overboost can be actived.
- Page 40 This contact can be also used for Off Peak Rates. To do it, connect into the contact a timer This contact can be also used for Off Peak Rates. To do it, connect into the contact a timer with a zero -voltage output . with a zero -voltage output . 9.11. Displaying/deleting compressor functioning hours www.jouleuk.co.uk | www.joule.ie...
- Page 41 When the contact is closed, the system automatically changes to Photovoltaic mode and the heat pump and electric heater work to achieve the programmed temperature. When the contact is opened, the system returns to the previous mode. This contact can be also used for Off Peak Rates. To do it, connect into the contact a timer with a zero -voltage output .
- Page 42 Switch the device off and on High pressure switch alarm Switch the device off and on Compressor maintenance alarm By touching any key, you delete the compressor functioning hours Evaporator failure alarm Switch the device off and on www.jouleuk.co.uk | www.joule.ie...
-
Page 43: Maintenance Of The Ecoheat
This chapter describes the simplest maintenance work on the EcoHeat Unit itself. Servicing should only be carried out by competent installers and any spare parts used must be purchased from JOULE. Never bypass any safety devices or operate the unit without... - Page 44 Next hold both of these safety valves open, allowing as much water as possible to flow through the tundish. • Release the valves and check that they reseat correctly. Completion of the Benchmark Checklist on pages 46-47 must be adhered to by the installer www.jouleuk.co.uk | www.joule.ie...
-
Page 45: Spare Parts
Joule. Always replace parts of the EcoHeat with original EcoHeat parts from Joule. The use of third-party parts may cause the product to malfunction or create a hazard. Disregarding of these points may have a negative effect on the EcoHeat warranty and void Joules statutory responsibilities. - Page 46 Ref. Joule item No. Description TOP COVER / AIR CONNECTIONS Ø150-160-200mm SUCTION FILTER BACK COVER EVAPORATOR UNIT COMPRESSOR VENTILATION KIT SOLENOID VALVE / COIL EXPANSION VALVE EVAPORATOR CUPPER FILTER CONTACTOR 25A MECHANICAL THERMOSTAT ELECTRICAL CONNECTIONS STRIP 4.10 HIGH PRESSURE SWITCH 4.11...
- Page 47 Safety notes • Always securely disconnect the power for the EcoHeat before installing, opening or performing maintenance on the product. • Ensure that the unit could not be accidently switched on while any maintenance procedure is underway. • Do not use this appliance for functions other than those described in this booklet. •...
- Page 48 This also allows the perfect opportunity to inspect and clean the other parts of the unit that may require it. Opening of EcoHeat procedure: Remove the top cover plate. The plate is held on with 4 screws. The front cover can now pull directly out www.jouleuk.co.uk | www.joule.ie...
-
Page 49: Warranty
Exclusions Registrations It is a condition of the warranty that the System If Joule finds the product to be defective as a sole Recording and Installation Checklist is completed result of defects in material or workmanship - then, and left in the Handover Pack. The online Warranty... - Page 50 Joule Cyclone Warranty Terms & Conditions Unvented Kit & Other Components. The JOULE stainless steel vessel carries a fully transferable 25-year guarantee against faulty The expansion vessel and cold water controls materials or manufacture provided that: supplied with JOULE models carry a 2-year guarantee.
- Page 51 Warning To the Installer • Read the installation instructions before commencing. • Unvented water heaters are a controlled service as defined in the latest edition of the Building Regulations and should only be fitted by a competent installer. • The installation is subject to approval. •...
-
Page 52: Benchmark Checklist
Benchmark Checklist... -
Page 54: Service Record
Service Record It is recommended that your hot water system is serviced regularly and that the apprepriate Service Record’s completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. - Page 55 Service Record Service 1 Service 1 Date ....... Date ....... Engineer Name Engineer Name Company Name Company Name Telephone No ............Telephone No ............Comments ............Comments ..............................................................................................................Signature ............Signature ............Service 1 Service 1 Date .......
-
Page 56: Notes
Notes www.jouleuk.co.uk | www.joule.ie... - Page 57 Notes UK Manufactured Unvented Hot Water Cylinder Installation Guide...
- Page 58 +44 (0) 330 808 8488 +353 (1) 626 9337 +44 (0) 1513 568 336 mail info@joule.ie mail info@jouleuk.co.uk www.joule.ie www.jouleuk.co.uk JOULE PL Strzegomska 55D, 53-611 Wroclaw, Polska +48 (0) 128811171 +48 (0) 814709046 mail biuro@joule-pl.pl www.joule-pl.pl www.jouleuk.co.uk | www.joule.ie ECOHEAT-001...
