FireWire 800 ExpressCard
Quick Installation Guide
Introducing the FireWire 800 ExpressCard
The FireWire 800 ExpressCard adds FireWire 800 (1394b)
interface to your ExpressCard equipped computer.
Features and Benefits
•
Provides 1 FireWire 800 (9-pin) and 1 FireWire 400
(6-pin) ports for multiple device connections
•
Supports data transfer rates up to 800Mb/s
•
Supports hot-swapping and Plug-n-Play connection
of peripheral devices
•
Works with FireWire devices including DV
camcorders, CD-RW/DVD-ROM drives, portable
hard disks, digital cameras and other audio/video
devices
System Requirements
•
ExpressCard-enabled notebook PC with an available
ExpressCard/54 slot
•
Windows 2000/XP/Server 2003/Vista
Package Contents
•
FireWire 800 ExpressCard
•
Driver CD
•
Quick Installation Guide
04-0442A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FireWire 800 ExpressCard and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG FireWire 800 ExpressCard

Summary of Contents for SIIG FireWire 800 ExpressCard

  • Page 1 FireWire 800 ExpressCard Quick Installation Guide Introducing the FireWire 800 ExpressCard The FireWire 800 ExpressCard adds FireWire 800 (1394b) interface to your ExpressCard equipped computer. Features and Benefits • Provides 1 FireWire 800 (9-pin) and 1 FireWire 400 (6-pin) ports for multiple device connections •...

  • Page 2: Hardware Installation

    However, non-powered FireWire devices require this optional power adapter to work. The power adapter can be purchased at SIIG's Online Store, part # NN-ADA011. Hardware Installation General instructions for installing the card are provided below.

  • Page 3: Driver Installation

    FireWire 800 ExpressCard drivers. Windows 2000 Windows 2000 automatically installs it's built-in 1394a driver for the FireWire 800 ExpressCard. To get the full speed out of this controller, install the Firewire 800 driver using the directions below. Insert the driver CD. Click Start, Run. Type D:\setup.exe, click OK.
  • Page 4 Select the restart Windows option, then click Finish. Windows Server 2003 Windows Server 2003 automatically installs it's built-in FireWire 400 driver for the FireWire 800 ExpressCard. To get the full speed out of this controller, install the Firewire 800 driver using the directions below.
  • Page 5 Windows Vista Windows Vista automatically installs it's built-in FireWire 400 driver for the FireWire 800 ExpressCard. To get the full speed out of this controller, install the Firewire 800 driver using the directions below. Insert the driver CD. Click Start, Run. Type D:\setup.exe, click OK.

  • Page 6: Removing The Expresscard

    Removing the ExpressCard Stop the ExpressCard before removing it from the ExpressCard slot. The utility is located by the system clock. For Windows 2000: Click the Unplug or Eject Hardware icon. Click Remove PCI standard PCI-to-PCI bridge. For Windows XP/Server 2003/Vista: Click the Safely Remove Hardware icon.
  • Page 7 Select Install the Software Automatically, click Next. Click Continue Anyway. (Skip if not prompted) Click Finish to complete the installation. Server 2003 At the Found New Hardware Wizard, For 2003 w/SP1 or later Select No, not this time, then click Next. For 2003 no service pack installed Go directly to step #2.
  • Page 8 ubSwitch Utility In order to use a DV camcorder with this controller, Microsoft's FireWire 400 driver must be installed in the system. We have supplied an easy to use utility that allows switching between Microsoft's driver and the FireWire 800 driver. Before using this utility, unplug all devices from the FireWire 800 card.
  • Page 9 Blank Page...
  • Page 10 Blank Page...

  • Page 11: Technical Support And Warranty

    This product comes with a lifetime manufacturer warranty. Please see SIIG website for more warranty details. If you should happen to have any problems with this product, follow the procedures below. A) If it is within the store's return policy period, please return the product to the store where you purchased from.
  • Page 12 Fremont, CA 94538-3152 FireWire 800 ExpressCard is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. Other names used in this publication are for identification only and may be trademarks of their respective companies.
