solid fuel stove
DONNA 70
DONNA 90
Instructions for installation and handling
This product meets the requirements of the Ecodesign Directive in terms of efficiency and air pollution level, in
order to contribute to the reduction of energy consumption and negative environmental impact.
ENG_v.1.1
1612003
Advertisement
Table of Contents
Related Manuals for alfaplam DONNA 70
Summary of Contents for alfaplam DONNA 70
- Page 1 METAL INDUSTRY AD 17500 VRANJE , SERBIA Radnička 1,Tel. 017/421-121 solid fuel stove DONNA 70 DONNA 90 Instructions for installation and handling This product meets the requirements of the Ecodesign Directive in terms of efficiency and air pollution level, in order to contribute to the reduction of energy consumption and negative environmental impact.
- Page 2 FIG. 1 Solid fuel stove DONNA 70 and DONNA 90 1.Door of the firebox 2.Sliding handle (air regulator) 3.Drawer for fuel 4.Lateral flue connection 5.Double-glass oven door 6.Cover of the opening for cleaning INSTRUCTIONS FOR INSTALLATION, USE AND HANDLING These instructions for installation, use and handling is applicable for the following type of stove: DONNA 70 and DONNA 90 During stove use you must comply with the national and European norms and regulations.
- Page 3 Contents: TECHNICAL DATA ............................. 1 INSTALLATION OF THE STOVE.......................... 1 HANDLING ................................ 1 3.1. HANDLING WITH THE ASHTRAY........................ 1 3.2. AIR REGULATION ............................2 3.2.1. PRIMARY AIR............................. 2 3.3. HEATING FLAP ............................2 3.4. OVEN DOOR (Figure 1, Position 6) ......................2 3.5.
- Page 4 1. TECHNICAL DATA TYPE: DONNA 70 DONNA 90 Rated heating capacity (kW) 5 kw with split logs 5 kw with split logs ◦C) 290 with split logs 290 with split logs Temperature of waste gases ( Required pressure in the flue (Pa)
- Page 5 We take out the ashtray with a special key (by raising up), removal and returning of the ashtray through the ashtray bracket as shown in figure 2 pos.8. 3.2. AIR REGULATION FIG.3 We perform air regulation with a special key over the sliding handle as shown in figure 3. 3.2.
- Page 6 * Open the sliding handle for primary air at the highest level of air release. ( figure 3, position 9 ) * Open the firebox door * Insert wood wool, sawdust or paper * over this, put 2-3 small wood pieces * Ignite * Close the door of the firebox * Let the wood burn lively...
- Page 7 * Removal of the cooking plate and thorough cleaning of the same outside. * Cleaning soot deposits from the upper side of the oven and in parts where flue gases pass. * Placing the plate. * Opening of the protective cover for cleaning (below the oven door) and removal of the cover. * Removal of soot and ash with a partitioning sheet metal.
