Led Brightness - Victron energy Digital Multi Control 200/200A Manual

AC voltage (V) rating
*) The exact value depends on the inverter/charger model. Refer to the "Minimum input current limits" spreadsheet, located in the
"VE.Bus (Multies, Inverters and Quattros)" folder in the firmware section on the

7.3. LED brightness

For your comfort, the light sensor auto-adjusts LED brightness. As ambient light drops the LEDs dim to a more comfortable level
and save power.
Page 10
Digital Multi Control
Power (VA) rating
1600
2000
3000
5000
8000
10000
15000
Minimum configurable AC current limit (A)
2.4 - 2.8 *
2.4 - 4.5 *
3.0 - 4.5 *
3.9 - 6.4 *
7.6 - 10.5 *
8.6 - 10.5 *
10.1 - 14.5 *
Victron Professional website.
Operation
