Ude MR-400/M Quick Start Manual

MR-400/M
Hand-held wireless microphone
Description
Wireless handheld microphone and receiver set. Designed to offer freedom of movement without
worrying about distances or interferences.
- Automatic synchronization of receiver / transmitter frequencies.
- Microphone with built-in LCD screen.
- Noise reduction filter for spurious frequencies.
- Suitable for small and medium sized installations.
Technical characteristics
System Parameters
Frequency range Frequency range
Signal frequency Signal frequency
Estabilidad de frecuencia Estabilidad de frecuencia
Dynamic range Dynamic range
Frequency response Frequency response
S/N Ratio S/N Ratio
THD THD
Working distance Working distance
Transmitter
Stability Stability
RF Output Power RF Output Power
Microphone capsule Microphone capsule
Power supply Power supply
Battery life Battery life
EQUIPOS Y SISTEMAS MEGAFONÍA / INTERCOM
Tel.: +34 934 772 854 / +34 609 914 787
642-665MHz
250KHz
0.005%
100dB
40Hz - 18KHz ( 3dB)
>105db
< 0.5%
100m aprox. in open spaces
10 PPM
30 mW
Dynamic
2 batteries AA 1,5V
6-8 hours
ude@udeaudio.com
- Receiver MR-400
- Hand-held microphone MH-403
- Power Supply
AC/DC 100-240V 50/60Hz
Receiver
Mode Mode
Audio output Audio output
Sensitivity Sensitivity
Max. Output level Max. Output level
Balanced Balanced
Unbalanced Unbalanced
Power supply Power supply
Connection Connection
21
front
PUBLIC ADDRESS SYSTEMS
BARCELONA - SPAIN
PLL
0-300mV
-105dB
0-400mV
0-200mV
12 15V DC Power supply
XLR balanced
Jack 6.35mm unbalanced
16
5
side
Dimensions in mm
rev.1 610.567A
1 3
