Summary of Contents for Sound Storm SDVD-250
-
Page 2: Use This Product Safely
FEATURES Compatible with PAL DVD (Video CD) and NTSC DVD (Video CD) This player can play discs recorded in either PAL or NTSC format. • A single LSI chip now integrates all major DVD playback circuit functions including MPEG2 decoder, video D/A converter, and audio decoders. -
Page 3: Table Of Contents
CONTENTS Safety Information ...4 Disc Notes ...5 Installation ...6 Using the Detachable Front Panel ...8 Electric Connection ...9 Front Panel Control and Remote Control ...10 Operation ...14 General Operation ...14 Radio Operation...14 CDC Operation ...15 Loading CD/CDC/DVD ...15 Ejecting a Disc ...15 Basic Operation ...16 On-Screen Display Function...16 Multi-audio Function...16... -
Page 4: Safety Information
SAFETY INFORMATION CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE MOBILE DVD PLAYER CORRECTLY AS INSTRUCTED. -
Page 5: Disc Notes
DISC NOTES Disc formats supported by this player 12 cm disc/8 cm disc (Single-sided disc only) Video CD 12 cm disc/8 cm disc 12 cm disc/8 cm disc Discs which cannot be played with this player • DVD-ROM • DVD-R/DVD-RAM •... -
Page 6: Installation
INSTALLATION Notes: • Choose the mounting location where the unit will not interfere with the normal driving function of the driver. • Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. -
Page 7: Din Rear-Mount (Method B)
INSTALLATION Removing the unit 1. Frame 2. Insert fingers into the groove in the front of frame and pull out to remove the frame. (When reattaching the frame, point the side with a groove downwards and attach it.) 3. Lever Insert the levers supplied with the unit into the grooves at both sides of the unit as shown in figure until they click. -
Page 8: Using The Detachable Front Panel
USING THE DETACHABLE FRONT PANEL To Detach the Front Panel 1. Press the OPEN button and the front panel will drop down. Open 2. Remove the front panel by grasping it in the middle and pulling toward you. Front Panel 3. -
Page 9: Electric Connection
ELECTRIC CONNECTION FL_OUT GREY WHITE FR_OUT GREY RL_OUT BLACK WHITE RR_OUT BLACK C OUT BROWN BLACK MEMORY BACK-UP (YELLOW) ACC (RED) GND (BLACK) ILLUM (PINK) PWR ANT (BLUE/WHITE) AMP CONTROL (GREEN) FL_OUT (WHITE) FR_OUT (GREY) RL_OUT (GREEN) RR_OUT (PURPLE) CENTER_OUT (BROWN) MEMORY BACK-UP (YELLOW) -
Page 10: Front Panel Control And Remote Control
FRONT PANEL CONTROL AND REMOTE CONTROL 14 27 21 24... - Page 11 FRONT PANEL CONTROL AND REMOTE CONTROL (Tray closed) (Tray opened)
- Page 12 FRONT PANEL CONTROL AND REMOTE CONTROL POWER/MUTE EJECT OPEN SOURCE ENTER 10. BAND /AS/PS 12. SELECT 13. + / – 14. AUDIO 15. ANGLE 16. DISP 17. SUBTITLE 18. TITLE/LOC 19. SETUP 20. 0 - 9 21. M1 - M6 22.
- Page 13 FRONT PANEL CONTROL AND REMOTE CONTROL Preparing the Remote Control Inserting the Batteries 1. Open the battery compartment cover. 2. Insert the new batteries (two AAA size). Make sure the positive and negative terminals of the batteries are oriented as indicated. 3.
-
Page 14: Operation
OPERATION GENERAL OPERATION TRANSMIT INDICATOR During pressing the key on the remote controller, the TRANSMIT INDICATOR (29) will be lighted. REMOTE SENSOR (IR) Point the remote handset to the REMOTE SENSOR (27). Receive the signal from remote handset. ON/OFF Switch on the by pressing the POWER button (1) shortly in front of panel, press it again to turn off the unit. -
Page 15: Cdc Operation
OPERATION frequency and detected station is stored into the preset memory. If LOC is selected, 1 LOC state and if 6ch. is not fully memorized, A/S search continued by DX state. At the end of Auto Store operation, mode is changed to Preset Scan. - Preset Scanning Press AS/PS button (11) shortly to scan preset station. -
Page 16: Basic Operation
OPERATION BASIC OPERATION STOPPING PLAY - Brief press the STOP button (11) to stop the unit playback, when press the PLAY button (9) it can continuous normal playback. - Press STOP button (11) twice to stop the playback and go back to initial Track/Chapter. -
Page 17: Menu Function
OPERATION Notes: - The language number is different according to the disc. - Some discs contain only one language soundtrack. - When no different language soundtracks, displayed in the top left corner of the screen. VCD/CD: Press AUDIO button (14) during playback. -
Page 18: Extra Function Control
OPERATION EXTRA FUNCTION CONTROL The colour, contrast and brightness can be adjusted in “STOP” mode. ANGLE : Select the colour, contrast and brightness : Decrease the level : Increase the level DISP : Recover to the normal value Notes: 1. For MP3 disc, the above modes cannot be adjusted. -
Page 19: Setup
SETUP INITIAL SETUP SETUP MENU --- MAIN PAGE GENERAL SETUP SPEAKER SETUP DOLBY DIGITAL SETUP DOLBY SURROUND SETUP PREFERENCES EXIT SETUP 1. Press SETUP button (19) in the stop mode. [Press the STOP button (11) twice to ensure the player under STOP mode.] 2. - Page 20 SETUP --- GENERAL PAGE --- TV DISPLAY TV TYPE MULTI PIC MODE NTSC ANGLE MARK OSD LANG SPDIF CAPTION MAIN PAGE TV TYPE setup This player can play discs recorded in either PAL or NTSC format. Select NTSC format, when you connected to NTSC TV.
-
Page 21: Speaker Setup
SETUP --- GENERAL PAGE --- TV DISPLAY TV TYPE PIC MODE ANGLE MARK OSD LANG SPDIF CAPTION MAIN PAGE SPDIF setup Select the SPDIF optical output ON/OFF. --- GENERAL PAGE --- TV DISPLAY TV TYPE PIC MODE ANGLE MARK OSD LANG SPDIF CAPTION MAIN PAGE... - Page 22 SETUP --- SPEAKER SETUP PAGE --- DOWNMIX CENTER REAR SUBWOOFER CNTR DELAY REAR DELAY TEST TONE BASS MAIN PAGE Select ON/OFF to turn on/off the rear speaker. This item can only be selected when the DOWNMIX is OFF. --- SPEAKER SETUP PAGE --- DOWNMIX CENTER REAR...
-
Page 23: Dolby Digital Setup
SETUP --- SPEAKER SETUP PAGE --- DOWNMIX CENTER REAR SUBWOOFER CNTR DELAY REAR DELAY TEST TONE BASS MAIN PAGE This item can only be selected when the DOWNMIX is OFF. If this item is set to ON, the player will send test tone to each speaker in turns of this: LEFT CENTER... -
Page 24: Dolby Surround Setup
SETUP --- DOLBY DIGITAL SETUP --- OP MODE DUAL MONO MAIN PAGE DRC-dynamic range control Select DRC and adjust the dynamic range of a Dolby Digital encoded program. There are 8 steps between full compression and off compression. DOLBY SURROUND SETUP --- DOLBY SURROUND SETUP --- ON/OFF MAIN PAGE... - Page 25 SETUP --- PREFERENCES PAGE --- LANGUAGE SUBTITLE DISC MENU ENGLISH LOCALE FRENCH PARENTAL SPANISH PASSWORD CHINESE DEFAULTS JAPANESE MAIN PAGE DISC MENU language setup Select the preferred DISC MENU language. --- PREFERENCES PAGE --- LANGUAGE SUBTITLE DISC MENU CHINA LOCALE FRANCE PARENTAL HONG KONG...
- Page 26 SETUP --- PREFERENCES PAGE --- LANGUAGE SUBTITLE DISC MENU LOCALE PARENTAL PASSWORD DEFAULTS RESET MAIN PAGE Load DEFAULT setting Select RESET to load the factory initial setting, as listed following: DEFAULT SETTING DOLBY DIGITAL SETUP DOLBY SURROUND SETUP GENERAL SETUP SPEAKER SETUP PREFERENCES SETUP TV DISPLAY...
-
Page 27: Specifications
SPECIFICATIONS GENERAL Power Supply Requirements Chassis Dimensions Weight Tone Controls - Bass (at 100 Hz) - Treble (at 10 KHz) - Middle Maximum Output Power LINE Output Level Subwoofer Output Current Consumption - With Power Amplifer - Without Power Amplifer DVD PLAYER Signal to Noise Ratio Channel Separation... - Page 28 88-V1621-06...
