Operation

Starting the Hedge Trimmer

1. Remove the protective cover from the blades
(Figure 4).
WARNING
The hedge trimmer blades can cause
cuts or amputation.
Be careful when handling the hedge
trimmer with the protective cover
removed.
1. Protective cover
2. Ensure that the vents on the hedge trimmer are
clear of any dust and debris
1. Hedge trimmer venting areas
Figure 4
2. Blades
(Figure 6).
Figure 5
3. Align the cavity of the battery pack with the
tongue in the handle housing, grasp the handle,
and push the battery pack into the handle until
the latch locks into place
g365006
1. Auxiliary handle
2. Auxiliary-handle switch
3. Lock switch
4. Place 1 hand on the trigger handle. Place the
other hand on the auxiliary handle
5. Press the lock switch and then squeeze
the trigger switch while engaging the
auxiliary-handle switch to turn on the hedge
trimmer (Figure
The trimmer stays on as long as the
auxiliary-handle switch is engaged and the
trigger is squeezed. You may release the
lock switch once the hedge trimmer is running
(Figure 6).
g378082
g378084
8
(Figure 6).
Figure 6
4. Trigger
5. Battery latch
(Figure
6).
g365007
6).
