- Page 1 ASSEMBLY INSTRUCTION KALUNDBORG GAMING TABLE ITEM CODE 70446...
-
Page 2: Pre-Assembly Preparation
PRE-ASSEMBLY PREPARATION Before you start: 1.Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product 2.Take care when lifting. Product should be assembled as near as possible to the point of use 3.Ensure that you have all required contents for complete assembly 4.Always read the assembly instructions carefully before beginning assembly. -
Page 3: Parts List
PARTS LIST ST3.5X14mm M6X50 mm M6X30 mm M6X12mm 2pcs 4pcs 4pcs 8pcs 6pcs ST4X25mm 2pcs 2pcs 2pcs 4pcs 2pcs Desktop panel Support Pipe Left Frame Rack Right Frame Connection Pipe... - Page 4 STEP 1: Insert the fitting H into the P1 and P2. STEP 2: 1.Assemble the P3 to P1 and P2 with fitting C. 2.Then assemble the P4 with P1 and P2 with fitting A.
- Page 5 STEP 3: Assemble the Panel 1 onto the metal frame with fitting B. STEP 4: Install the rack G at right side of the desktop with fitting C and D.
- Page 6 STEP 5: Put the fitting E and F accordingly as the below picture. STEP 6: 1. Install the belt K onto the desktop with fitting D. 2. Insert the fitting J into the wall, and connect it with the belt by fitting I.
- Page 7 STEP 7: Assembly complete!
- Page 8 To protect your furniture, we suggest the following: • Avoid placing your furniture in direct sunlight. • Do not place furniture directly under windows. • Do not place sharp materials (knife, fork, etc.) directly onto your furniture as sharp material may scrape and damage the finish.
