JLT JLT6012A Quick Start Manual

Maintenance
Battery replacement
• Unscrew the six Torx 10 screws.
• Lift the lid and gasket.
• Lift the battery and unplug cable.
• Mount battery in reverse order make sure
battery and gasket are in the correct position.
LED indicators & Ambient light sensor
LED 1 LED 2
1. Green, slow blink every 10 sec. 1. Off
Power is connected, unit is turned OFF
WiFi, no connection
2. Orange
2. Green, constantly lit
WiFi is connected, low speed
Power is connected, unit is in
normal operation
3. Green
WiFi is connected, high speed
3. Orange, constantly lit
Unit is running on battery, preparing
Ambient light sensor 3
for shutdown
The ambient light sensor is for auto-
4. Orange/Green alternately
matic brightness adjustment depending
A button is pressed
on condition of surrounding light
Regulatory Compliance and Safety Information for JLT6012A USA
FCC Part 15, Subpart B Unintentional Emissions Interference Statement • Reorient or relocate the receiving antenna.
This equipment has been tested and found to comply with the limits • Increase the separation between the
for a Class B digital device, pursuant to Part 15 of the FCC rules. These equipment and receiver.
limits are designed to provide reasonable protection against harmful • Connect the equipment into an outlet on
interference when the equipment is operated in a residential installation. a circuit different from that to which the receiver is connected.
This equipment generates uses and can radiate radio frequency energy • Consult the dealer or an experienced radio/TV technician for help.
and, if not installed and used in accordance with the instructions, may This device complies with part 15 of the FCC rules. Operation is subject
cause harmful interference to radio communications. However, there is to the following two conditions: (1) This device may not cause harmful
no guarantee that interference will not occur in a particular installation. interference, and (2) this device must accept any interference received,
If this equipment does cause harmful interference to radio or television including interference that may cause undesired operation.
reception, which can be determined by turning the equipment off and on, Compliance of this equipment is confirmed by the following label that is
the user is encouraged to try to correct the interference by one or more placed on the equipment:
of the following measures:
FCC Part 15, Subpart C Intentional Emissions Interference
Statement Compliance of this equipment is confirmed by the
following certification numbers that are placed on the equipment:
Notice: The term "FCC ID:" before the certification number signifies that
FCC technical specifications were met.
RF Radiation Exposure Statement
This equipment complies with the FCC radiation exposure limits set fourth for portable transmitting devices operation in an uncontrolled environment.
End users must follow the specific operating instructions to satisfy RF exposure compliance.
• The equipment should only be used or installed at locations where there is normally at least
a 20cm separation between the antenna and all persons.
• This transmitter must not be co-located or operation in conjunction with any other antenna or transmitter.
• Any changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate this equipment.
Google trademark
Android is a trademark of Google LLC.
Service lid, overview
For further support or guidance, visit:
jltmobile.com/support
Quick Start Guide
JLT6012A
jltmobile.com
P/N 102351
