ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
IMPORTANT - This Document is customer property and is to remain with this unit. Please return to service informa-
tion pack upon completion of work.
These instructions do not cover all variations in systems or provide for every possible contingency to be met in connection with
the installation. Should further information be desired or should particular problems arise which are not covered sufficiently for the
purchaser's purposes, the matter should be referred to your installing dealer or local distributor.
Note: The manufacturer recommends installing only approved matched indoor and outdoor systems. Some of the benefits of
installing approved matched indoor and outdoor split systems are maximum efficiency, optimum performance and the best overall
system reliability.
Note: R-454B refrigerant is an "A2L" refrigerant meaning: A = non-toxic, 2 = flammable, L = low burning velocity.
The term "A2L" is used throughout this document.
Table of Contents
Section 1. Safety ..................................................................................... 2
Section 2. Unit Location Considerations.............................................. 3
Section 3. Unit Preparation .................................................................... 4
Section 4. Setting the Unit ..................................................................... 4
Section 5. Refrigerant Line Considerations ......................................... 4
Section 6. Refrigerant Line Routing ..................................................... 5
Section 7. Refrigerant Line Brazing ...................................................... 7
Section 8. Refrigerant Line Leak Check ............................................... 8
Section 9. Evacuation ............................................................................. 8
Section 10. Service Valves ..................................................................... 8
Section 11. Electrical - Low Voltage ..................................................... 9
Section 12. Electrical - High Voltage .................................................. 11
Section 13. Start Up .............................................................................. 11
Section 14. System Charge Adjustment ............................................. 12
Section 15. Checkout Procedures ....................................................... 16
Section 16. Refrigeration Circuits........................................................18
Section 17. Wiring Diagrams................................................................20
Section 18. Pressure Curves................................................................23
Installation and Operation Manual
Condensing Units
5TTX5018 - 060
18-AC130D1-1B-EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trane 5TTX5018
Summary of Contents for Trane 5TTX5018
-
Page 1: Table Of Contents
Installation and Operation Manual Condensing Units 5TTX5018 – 060 ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES IMPORTANT – This Document is customer property and is to remain with this unit. Please return to service informa- tion pack upon completion of work. -
Page 2: Section 1. Safety
Section 1. Safety WARNING WARNING The appliance shall be stored in a room without contin- Only qualified personnel should install and service the uously operating ignition sources (for examples: open equipment. The installation, starting up, and servicing flames, an operating gas appliance or an operating of heating, ventilating, and air-conditioning equipment electric heater). -
Page 3: Section 2. Unit Location Considerations
Section 2. Unit Location Considerations 2.1 Unit Dimensions and Weight Table 2.1 Unit Dimensions and Weight Models H x D x W (in) Weight* (lb) 5TTX5018A 42 x 30 x 33 5TTX5024A 38 x 30 x 33 5TTX5030A 42 x 30 x 33 5TTX5036A 38 x 30 x 33 5TTX5042A... -
Page 4: Section 3. Unit Preparation
2.4 Coastal Considerations If installed within one mile of salt water, including seacoasts and inland waterways, models without factory supplied Seacoast Salt Shields require the addition of BAYSEAC001 (Seacoast Kit) at installation time. Section 3. Unit Preparation 3.1 Prepare The Unit For Installation STEP 1 - Check for damage and report promptly to the carrier any damage found to the unit. -
Page 5: Section 6. Refrigerant Line Routing
5.4 Refrigerant Line Insulation Important: The Vapor Line must always be Vapor Line Liquid Line insulated. DO NOT allow the Liquid Line and Insulation Vapor Line to come in direct (metal to metal) contact. 5.5 Reuse Existing Refrigerant Lines CAUTION REFRIGERANT! Failure to inspect or use proper service tools may result in equipment damage or personal injury. - Page 6 8 Feet Maximum Joist/Rafter Isolator Side View 8 Feet Maximum Line Set Secure Vapor line from joists using isolators every 8 ft. Secure Liquid Line directly to Vapor line using tape, wire, or other appro- priate method every 8 ft. Isolation From Joist/Rafter 8 Feet Maximum Wall...
-
Page 7: Section 7. Refrigerant Line Brazing
Section 7. Refrigerant Line Brazing 7.1 Braze The Refrigerant Lines STEP 1 - Remove caps or plugs. Use a deburing tool to debur the pipe ends. Clean both internal and external surfaces of the tubing using an emery cloth. STEP 2 - Remove the pressure tap cap and valve cores from both service valves. STEP 3 - Purge the refrigerant lines and indoor coil with dry nitrogen. -
Page 8: Section 8. Refrigerant Line Leak Check
Section 8. Refrigerant Line Leak Check 8.1 Check For Leaks After completion of field piping for split systems, the field pipework shall be pressure tested with nitrogen and then vacuum tested prior to refrigerant charging, according to the following requirements: 1. -
Page 9: Section 11. Electrical - Low Voltage
10.2 Open the Liquid Service Valve WARNING Extreme caution should be exercised when opening the Liquid Line Service Valve. Turn counterclockwise until the valve stem just touches the rolled edge. No torque is required. Failure to follow this warning will result in abrupt release of system charge and may result in personal injury and /or property damage. - Page 10 11.2 Low Voltage Hook-up Diagrams With 5TEM4, 6 and C With 5TAM5 and X Outdoor Outdoor Thermostat Air Handler Thermostat Air Handler Unit Unit 24 VAC HOT 24 VAC HOT • Units with pigtails require wirenuts for connections. Cap all unused wires.
-
Page 11: Section 12. Electrical - High Voltage
Section 12. Electrical - High Voltage 12.1 High Voltage Power Supply WARNING LIVE ELECTRICAL COMPONENTS! Failure to follow this Warning could result in property damage, severe personal injury, or death. Follow all electrical safety precautions when exposed to live electrical components. It may be necessary to work with live electrical components during installation, testing, servic- ing, and troubleshooting of this product. -
Page 12: Section 14. System Charge Adjustment
Section 14. System Charge Adjustment 14.1 Temperature Measurements (Systems can be rated with TXV, EEV or Piston. Ensure charging method is correct). Important: Installer must mark/write the total refrigerant charge on the OD unit label after adjusting for indoor coil and lineset. Technicians must have their refrigerant cylinder on a scale during the charging procedure and measure how much additional refrigerant is put in the system (additional over the factory charge). - Page 13 STEP 2 - Determine the final subcooling target using total Line Length and Lift measured in STEP 1 and the charts below. 018 & 030 Models 024, 036 & 042 Models SUBCOOL CHARGING CHART CORRECTIONS TABLE (FOR LINE LENGTH AND RISE) SUBCOOL CHARGING CHART CORRECTIONS TABLE (FOR LINE LENGTH AND RISE) 1°...
- Page 14 STEP 6 - Adjust refrigerant level to attain proper gage pressure. Add refrigerant if the Liquid Gage Pressure is lower than the chart value. 1. Connect gages to refrigerant bottle and unit as illustrated. 2. Purge all hoses. 3. Open bottle. 4.
- Page 15 STEP 10 - If repairs must be made after system is charged, properly and safely remove and isolate refrigerant and purge the section of the system needing repair with oxygen free nitrogen prior to opening the circuit. The refrigerant charge should be recovered into the correctly marked recovery cylinders. Ensure that the correct number of cylinders for holding the total system charge is available.
-
Page 16: Section 15. Checkout Procedures
Calculating Charge Using the Weigh-In Method STEP 1 - Measure in feet the distance between 1. Line length (ft) ______________ the outdoor unit and the indoor unit and record on Line 1. Include the entire length of the line from 2. - Page 17 15.2 Markings and Instructions [symbol ISO 7010-W021 (2011-05)] warning; flammable materials service indicator; read technical [symbol ISO 7000-1659 (2004-01)] manual A2L symbol warning; low burning velocity material [symbol ISO 7000-1701 (2004-01)] pressure ultraviolet radiation, [symbol IEC 60417-6040 2010-08)] instructional safeguard operator’s manual;...
-
Page 18: Section 16. Refrigeration Circuits
Section 16. Refrigeration Circuits 018, 030 & 042 Models PRINTED FROM D158514P01 024 & 036 Models PRINTED FROM D157394P01 18-AC130D1-1B-EN... - Page 19 048 & 060 Models Printed from D159175 16.1 Refrigerant Detection System The approved ID/OD combination will provide sufficient safe ventilation. Airflow provided is sufficient to cover minimum room area including adjustments for altitude. All systems require a refrigerant detection system so no altitude adjustment factors are required. Installer must ensure refrigerant detection system is connected and placed in appropriate orientation per application.
-
Page 20: Section 17. Wiring Diagrams
Section 17. Wiring Diagrams 18-AC130D1-1B-EN... - Page 21 18-AC130D1-1B-EN...
- Page 22 18-AC130D1-1B-EN...
-
Page 23: Section 18. Pressure Curves
Section 18. Pressure Curves COOLING PERFORMANCE CAN BE CHECKED WHEN THE OUTDOOR TEMP IS ABOVE 65 DEG F. TO CHECK COOLING PERFORMANCE, SELECT THE PROPER INDOOR CFM, ALLOW PRESSURES TO STABILIZE. MEASURE INDOOR WET BULB TEMPERATURE, OUTDOOR TEMPERATURE, LIQUID AND SUCTION PRESSURES. ON THE PLOTS LOCATE OUTDOOR TEMPERATURE (1); LOCATE INDOOR WET BULB (2);... - Page 24 PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F. Cooling OD Model @SCFM OUTDOOR TEMPERATURE (Degree F) 5TTX5024A1 5TTX5030A1 INDOOR ENTERING WET BULB CURVES 5TTX5036A1 TOP TO BOTTOM 71, 67, 63 AND 59 DEG F.
- Page 25 PRESSURE CURVES (Refer below table for models) INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F. Cooling OD Model @SCFM OUTDOOR TEMPERATURE (Degree F) 1450 5TTX5060A1 INDOOR ENTERING WET BULB CURVES TOP TO BOTTOM 71, 67, 63 AND 59 DEG F.
- Page 26 Trane has a policy of continuous data improvement and it reserves the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
