Installer's Guide
TRANE Link Variable Speed Heat Pumps and Air
Conditioners
5TWV0X24A
5TWV0X36A
5TWV0X48A
5TWV0X60A
The Diagnostics Mobile App is available by scanning a QR code above, the
one located inside this unit or by searching for the Trane or American
Standard Diagnostics App in your App Store ® . This system must include a A/
T HUI2360A200U thermostat and a TSYS2C60A2VVU system controller to
operate and is Link communicating only.
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning
equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person
could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment.
April 2025
5TTV0X24A
5TTV0X25A
5TTV0X36A
5TTV0X48A
5TTV0X60A
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
O O D D R R - - S S V V N N 0 0 0 0 6 6 A A - - E E N N
N N o o t t e e : : Graphics in this document are for representation
only. Actual model may differ in appearance.
N N o o t t e e : : This unit is Link communicating only.
N N o o t t e e : : R-454B refrigerant is an "A2L" refrigerant
meaning: A = non-toxic, 2 = flammable, L = low
burning velocity. The term "A2L" is used
throughout this document.
N N o o t t e e : : This unit requires software version 9.0 or later on
the SC360 and UX360.
