- Page 1 Telstra 4GX MF833V USB User Manual...
-
Page 2: Software Update
IMPORTANT Software updates We always recommend that you have the latest software update installed on your USB Modem - this will ensure that you have the latest features, most stable and secure experience while using this device. Refer to section “Settings >... -
Page 3: Setting Up The Device
Indicator LED’s micro-SIM card slot Setting up the Device Step 1 : SIM Type Make sure you are using a Telstra micro-SIM card: micro-SIM (U) SIM nano-SIM Version 1.1 / September 2023 ZTE Copyright © 2023. All rights reserved... - Page 4 Step 2 : Activate SIM If your SIM is not yet active visit telstra.com/activate Follow the prompts to activate your SIM. Step 3 : Inserting Micro SIM Press and slide the front plastic cover Insert your micro SIM as shown - ensure down and remove it.
-
Page 5: Led Indicator Legend
LED indicator legend Red: No Network The device is not registered to the mobile network. There is no micro-SIM card inserted. There is no network service available. Green: 3G Connection Solid: The device is registered to the 3G network. Flashing: Active data transfer on the 3G network. Blue: 4G Connection Solid: The device is registered to the 4G network. - Page 6 Telstra USB volume. To install, simply trigger the contained Telstra 4GX USB app and follow the presented prompts If required to uninstall the driver, navigate to System > Applications and run Uninstall TELSTRA 4G USB app (you will be prompted to remove the USB if connected) Important Note :...
-
Page 7: Screens Overview
192.168.0.1 The home page shows a brief summary of the device status and your remaining • data from Telstra. Software update notifications (if applicable) will be shown on this page • Screens Overview Lock-screen Overview : On the initial loading of the WEB GUI, you will be presented the login screen. - Page 8 SMS messages, service number and site navigation. This device will automatically connect to the Telstra 4G or 3G network. (Some device settings can only be changed when the device is disconnected from the network).
- Page 9 Instructions : To change to manual connection Disconnect or Connect your devices mobile connection: > Click on Connect or Disconnect > The Device & connection status (Disconnect, 3G Connected or 4G Connected) will update on this page to its current state. Quick access to change your SIM PIN page: >...
-
Page 10: Advanced Settings
Overview : The Quick Settings page allows you to configure your device in 5 simple steps to quickly setup your device to your preference. Instructions : Accessing the Quick Settings Wizard for setting up your device: > Navigate to Settings > Quick Settings >... - Page 11 connect to the mobile network once it is connected to a host device e.g. PC or laptop. You may prefer to change the WAN Connection Mode so the device will only connect to the mobile network once you have accessed the Homepage and you clicked to connect.
- Page 12 type for your device to connect to. This device can connect to 4G or 3G technology. Instructions : To modify the network selection: > Select Disconnect to modify the Network Selection. > Navigate to Settings > Network Settings > Network selection >...
- Page 13 > Click on Yes to confirm the changes. Important : This device is Network locked to Telstra and must be unlocked by calling Telstra on 13 22 00 and say ‘unlock device option’ when prompted. You will need to provide your devices IMEI number.
- Page 14 Settings > Device settings > USIM PIN Management Overview : USIM PIN management allows you to enable or disable and change the SIM PIN on this device. By default, the SIM PIN is disabled for ease of use. If the SIM PIN feature is enabled, you will be prompted to enter the SIM PIN each time the device is turned on to use the device.
- Page 15 Important: You will need to contact your Service Provider for the SIM PIN code if you do not have the default SIM PIN. If you incorrectly enter the SIM PIN more than 3 times your SIM will be PUK locked, in this situation you will be prompted to enter the PUK code to unlock to SIM, you will need to contact your Service Provider for an PUK code to continue to use your SIM in the device.
- Page 16 > Click on Yes to confirm the changes. > Your device will restart to factory settings. Important : It is important to note that any custom changes made to the device settings will be lost during this process. Click on the Help icon to get context tips. Settings >...
- Page 17 Instructions : Modifying your devices software update preference: > Navigate to Settings > Device Settings > Software Update > Select Enable or Disable for Automatic Updates > Select Apply Manually checking for new software updates: > Navigate to Settings > Device Settings > Software Update >...
- Page 18 Instructions: To enable DMZ on your device: > Navigate to Settings > Firewall > DMZ: > Select Enable and enter a valid IPv4 address > Click on Apply to confirm the changes. To disable DMZ on your device: > Navigate to Settings > Firewall > DMZ: >...
- Page 19 SMS Settings, as incorrect settings may result in issues receiving SMS on your device. If you encounter an issue with the SMS Settings, it is recommended to factory reset the device to the default Telstra configuration. Click on the Help icon to get context tips. Version 1.1 / September 2023...
- Page 20 Phonebook Overview : The Phonebook allows you to create, view, delete or modify stored contacts on your SIM card. The Phonebook contents are automatically retrieved from stored contacts in your SIM card and can be stored on the device directly. Contacts that are stored on your SIM card will be available if you switch devices.
-
Page 21: Device Information
> Click on Yes to confirm the changes. Device Information Overview : The Device Information page allows you to view high level information about your device’s mobile network status in more detail compared to the Home page. You can view mobile network information such as: •... - Page 22 You may have entered the wrong SIM PIN code too many times, your SIM will be PUK locked. Please contact Telstra (on 13 22 00 and follow the voice prompts) to obtain your 8-digit Personal Unlocking Key (PUK) code. Log into the web interface ( Home >...
- Page 23 No Network Access When you enter the PUK code incorrectly too many times, your SIM card will be PUK blocked. You will need to contact Telstra (on 13 22 00 and follow the voice prompts) to replace your physical SIM.
-
Page 24: Rf Safety Information
manufacturer. Using unauthorised accessories may affect your modem’s performance or damage your modem. 8. Avoid using the modem in areas that emit electromagnetic waves or in enclosed metallic structures e.g. lifts. 9. The modem is not waterproof. Please keep it dry and store it in a cool, dry place. 10. -
Page 25: Technical Specifications
Maximum power is only used at the edge of network coverage so under most circumstances the power output is very low. Under poor network conditions the modem transmits at a higher power level and may get hot. Declaration of Conformity : Specific Absorption Rate (SAR) The USB modem is designed to be used in close proximity to the body. - Page 26 Telstra Copyright © 2023. All rights reserved. Telstra SIM required. Unlocking fee applies for use with a non-Telstra SIM card. More unlocking information at - https://www.telstra.com.au/support/mobiles-devices/unlock-phone-imei Limit 1 per customer and no trade sales. The Pre-Paid offer you select will determine your credit expiry date and bonuses.
