- Page 1 WORKSHOP MANUAL PRINT No. 9--93210 TX130--30/TX130--30 turbo TX130--33/TX130--33 turbo...
- Page 2 AVOID ACCIDENTS Most accidents and injuries occurring in industry, on the farm, at home or on the road, are caused by the failure of some individual to follow simple and fundamental safety rules or precautions. For this reason, MOST ACCIDENTS CAN BE PREVENTED by recognizing the real cause and taking the necessary precautions, before the accident occurs.
-
Page 3: Table Of Contents
Workshop Manual TX130- -30/TX130- -30 Turbo TX130- -33/TX130- -33 Turbo TELEHANDLERS GENERAL LIST OF CONTENTS SECTION 00 - - GENERAL Description ................Page General instructions . -
Page 4: General List Of Contents
................Idler gear case assembly . - Page 5 Thanks very much for your reading, Want to get more information, Please click here, Then get the complete manual NOTE: If there is no response to click on the link above, please download the PDF document first, and then click on it. Have any questions please write to me: admin@servicemanualperfect.com...
- Page 6 GENERAL LIST OF CONTENTS Operation diagram ................Component overhaul .
- Page 7 GENERAL LIST OF CONTENTS Bulb replacement ................Protecting the electrical systems during charging or welding .
-
Page 8: Section 00 - - General
SECTION 00 - - GENERAL GENERAL INSTRUCTIONS IMPORTANT NOTICE All maintenance and repair interventions listed in this Manual must be performed exclusively by the Service Network of the Manufacturer, complying strictly with the indications herein and using, when required, the prescribed special tools. -
Page 9: Main Specifications Of Engines
SECTION 00 - - GENERAL NOTES ON SPARE PARTS Use genuine spare parts guaranteed by the Manufacturer only. Genuine spare parts are the only ones ensuring the same quality, the same life and the same safety as the originally mounted parts, since they are the same as the ones installed in production. Only genuine parts from the manufacturer ensure this guarantee. -
Page 10: Safety Rules
SECTION 00 - - GENERAL SAFETY RULES PAY ATTENTION TO THIS SYMBOL This alert symbol announces important messages involving your safety. Read carefully the safety instructions listed and follow the precautions recommended to avoid potential risks and to safeguard your health and your safety. You will find this symbol in the text of this Manual with the following key words: WARNING - - Cautions intended to avoid improper repair interventions involving potential consequences for the safety of the personnel performing the repairs. - Page 11 SECTION 00 - - GENERAL ground as soon as possible with a certain margin Use only designated towing or attaching points. ◊ of safety. Use care in making attachments. Make sure pins and/or locks are secure before pulling. Stay clear Do not trust worn and /or kinked chains and ◊...
-
Page 12: Troubleshooting
Do not adjust engine fuel cal treatment is not administered immediately. pump when machine is moving. In case pressures must be measured, use ◊ Never lubricate the machine with engine run- ◊... -
Page 13: Product Identification
TH001061 IDENTIFICATION OF ENGINE F4GE0404B*D600 The identification data of the engine are located on the right side of the engine crankcase. Record the information below for quick reference in case of ne- cessity. MODEL No. SERIAL No. DATE CODE TH00R005... - Page 14 SECTION 00 - - GENERAL IDENTIFICATION OF ENGINE F4GE0454C*D600 The identification data of the engine are located on the right side of the engine crankcase. Record the information below for quick reference in case of ne- cessity. MODEL No. SERIAL No. DATE CODE...
- Page 15 The cab identification plate includes the serial number and additional data and is located on the front side of the seat. Please copy here below the serial number for a prompt consultation in case of necessity. SERIAL No. DATE CODE...
-
Page 16: Environmental Considerations
SECTION 00 - - GENERAL ENVIRONMENTAL CONSIDERATIONS The following recommendations can be useful: 4. Avoid spillage when draining used coolant mix- tures, engine oils, transmission and hydraulic fluids, brake fluid. After draining, do not mix Become familiar and make sure you have well •... -
Page 17: Maintenance Techniques
SECTION 00 - - GENERAL MAINTENANCE TECHNIQUES GENERAL NOTICES If a hose swells, this indicates that there is an internal leakage due to a structural failure. This condition Clean the outside of all the components prior to per- deteriorates very quickly and causes the failure of forming any type of repair. - Page 18 SECTION 00 - - GENERAL SPECIFIC SEALING COMPOUNDS The following sealing compounds must be used, complying with the indications provided by the Manual: SEALANTS COMMERCIAL NAME Anaerobic sealant LOCTITE 518 (liquid gasket) RTV silicon sealant LOCTITE SUPERFLEX 593,595 or 596 LOCTITE ULTRA BLUE 587 DOW CORNING SILASTIC 732 GENERAL ELECTRIC RTV 103 or 108 Pipe sealant...
- Page 19 SECTION 00 - - GENERAL MINIMUM TIGHTENING TORQUES FOR FASTENERS IN NEWTON- -METRES (Nm) FOR NORMAL INSTALLATION APPLICATIONS METRIC BOLTS AND LOCK NUTS CLASS 8.8 CLASS 10.9 LOCK NUT CLASS 5.8 CL. 8 PLATED NOMINAL PLATED PLATED with BOLT PLATED Zn/Cr DIMENSION PLATED...
- Page 20 SECTION 00 - - GENERAL MINIMUM TIGHTENING TORQUES FOR FASTENERS IN NEWTON- -METRES (Nm) FOR NORMAL INSTALLATION APPLICATIONS INCH MEASUREMENT SCREWS AND LOCK NUTS LOCK NUTS GRADE SAE 2 GRADE SAE 5 GRADE SAE 8 PLATED PLATED NOMINAL PLATED PLATED NOMINAL Zn/Cr PLATED...
- Page 21 SECTION 00 - - GENERAL GENERAL NOTE: “The Manufacturer” pursues a policy of constant improvements, thus reserves the right to modify at any moment technical and design data, without notice, and without any obligation to modify the machines previously manufactured. All the data provided in this Manual are subject to variations in production.
- Page 22 SECTION 00 - - GENERAL TH00R012 TX130- -30/TX130- -30 Turbo TX130- -33/TX130- -33 Turbo 1200 mm 1260 mm 3120 mm 4396 mm 2145 mm 2730 mm 6345 mm 5204 mm 7545 mm 980 mm 2036 mm 3890 mm 402* mm 2445 mm 1080 mm * Value measured with tyres 405/70x24...
