SUMMER 2003
WIRELESS LAN PRODUCTS
802.11g Wireless LAN PC Card
PCWA-C300S
With Sony original super slim antenna, this PC
card does not stick out from your PC card slot.
Enjoy wireless connection up to 54Mbps
rate at home, office and hotspots. Backward com-
patible wtih 802.11b Wi-Fi certified products.
SPECIFICATIONS
- Standard: IEEE 802.11g
- Data transfer speed: Up to 54Mbps (Link Rate)
- Range: Up to 320 feet
1
- Connector: PC card slot type-II
- Interface: CardBus (PC Card)
- Encryption: 64/128 bits WEP
- Supported OS: Windows
®
2000 Professional, Millennium
Edition, XP Home Edition and XP Professional
- Modulation: DSSS/OFDM
- Frequency rate: : 2.4GHz ISM Band (2.4-2.4835GHZ, 11 chan-
nel)
- Power supply: 3.3V (through PC card slot)
- Power consumption: Approx. 700mA (transmitting), 370mA
(receiving)
- Dimensions (WxHxD): Approx. 2.12" x 0.5" x 3.54"
- Weight: Approx. 1.40 oz.
- Packaged content: CD-ROM (device driver, utility), User manual,
Limited warranty card
802.11g Wireless LAN Router Access Point
PCWA-AR300
This access point offers stylish and
compact design. The separated wire-
less unit offers ability to extend from
router unit for the optimal wireless
signal. 3 LAN ports are available
for PC, printer and more to share Internet connection. Simple set
up with web-based configuration. It supports VPN and UPnP. Up
to 16 users can access to one access point.
SPECIFICATIONS
- Standard: IEEE 802.11g
- Data transfer speed: Up to 54Mbps (Link Rate)
- Range: Up to 320 feet
1
- Frequency rate: 2.4GHz ISM Band (2.4-2.4835GHZ, 11 chan-
nel)
- Power supply: AC 100V-240V 50/60Hz
- Power consumption: Approx. 5W max.
- Network Protocol: TCP/IP
- Encryption: 64/128 bits WEP
- System requirements: Internet Explorer 5.5 or later, Netscape 6.1
or later
- Communication security: MAC address filtering, Dynamic packet
VAIO
(R)
filtering
- Modulation: DSSS/OFDM
transfer
- Recommended number of users: up to 16 users
2
- Interface: WAN : RJ-45 (10/100BASE-TX) port x 1 (MDI/MDI-X
Auto Recognition)
X Auto Recognition) *2 port support Power Supply Function for
Wireless Unit
- Dimensions (exclude cords): Approx. 3.85" x 3.85" x1.5" (wire-
2
less unit), 7.85"x 2.75"x 1.25" (router unit), 4.25" x 2.35 "x 1"
(AC adapter)
- Packaged content: AC adapter, Limited warranty card
The beautiful design fits into your living room or office. The set-up
with non-PC products can be done in seconds without PCs - just
press buttons on DE30 converter and AR300 access point.
SPECIFICATIONS
- Standard: IEEE802.11g
- Data transfer speed: Up to 54Mbps (Link Rate)
- Range: Up to 320 feet
- Frequency rate: 2.4GHz ISM Band (2.4-2.4835GHZ, 11 chan-
nel)
- Power consumption: Approx. 5W max.
- Encryption: 64/128WEP
- Power supply: AC 100V-240V 50/60Hz
- Supported OS: Windows
Edition, XP Home Edition and XP Professional
- System requirements: Internet Explorer 5.5 or later, Netscape 6.1
or later
- Interface on Power Unit : 10Base-T/100Base-TX port (MDI/MDI-
X auto recognition)
- Dimensions: Wireless Unit (WxHxD) : 3 7/8" x 3 7/8" x 1
3/8"
2
Power unit (WxHxD) : 4 1/2"x 1" x 2 3/4"
- Weight : Wireless Unit approx. 0.68 lbs.
- Packaged content: CD-ROM (Utility, Online manual), Power unit,
Limited warranty card
Sony does not gurantee the security of wireless communication.
1 Range varies depending on environmental conditions
2 Transfer speed will be reduced if 802.11b users are included in network. Also,
interference with other wireless devices can reduce transfer speed.
LAN : RJ-45 ( 10/100BASE-TX ) port x 4* (MDI/MDI-
802.11g Ethernet Converter
PCWA-DE30
This converter turns your device into wireless via
Ethernet port. Plug it into Ethernet port on your
desktop PC, VAIO RoomLink
and enjoy the world of high-speed wireless!
1
2000 Professional, Millennium
®
Power Unit approx. 0.29 lbs.
802.11g
TM
, PlayStation
(R)
2
2
