DRIFTER 13 OWNER'S MANUAL
ALWAYS WEAR A COAST GUARD APPROVED FLOTATION DEVICE
WHEN OPERATING THE DRIFTER 13.
Know the limits of your abilities and the limits of your equipment.
Changes in air temperature and elevation may cause the air inside the Drifter
13 to expand which could cause a tube to burst. Always release some air when
these conditions occur.
Never leave your boat sitting in direct sunlight when it is out of the water.
This owner's manual will help you with initial set-up of your new
Drifter 13, provide basic maintenance tips, and covers simple field repair.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRIFTER 13 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Outcast Sporting Gear DRIFTER 13

Summary of Contents for Outcast Sporting Gear DRIFTER 13

  • Page 1 Never leave your boat sitting in direct sunlight when it is out of the water. This owner’s manual will help you with initial set-up of your new Drifter 13, provide basic maintenance tips, and covers simple field repair.
  • Page 2 BEFORE YOU BEGIN, Check for damaged or missing parts. 2 - Oar mounts 1 - Drifter 13 raft 2 - Seat bottoms with swivels 3 - Seat backs 4 - 3’ Cam straps 2 - Oar locks 1 - Regular seat bottom 2 - 4’...

  • Page 3: Step 2: Seat Assembly

    Step 1: Inflation Items needed: 1 - Drifter 13 raft 1. Remove the dust caps from the valves. 2. Push and turn the valve stem a 1/4 turn. This positions the valve stem in the up or closed position. Having the valve stem in the closed position allows air enter the chamber, but won’t allow air to escape.

  • Page 4: Step 3: Frame Assembly

    2 - Cross bar 1 - U-shaped thigh bar 1 - Raised seat bar 1. Assemble the frame in the inflated Drifter 13 as pictured above using 16 U-bolts, 32 washer and 32 Nylock nuts. 1 - Foot bar 2 - Stern seat rails...

  • Page 5: Step 5: Oar Assembly

    Step 4: Anchor System Assembly Items needed: 1 - Anchor control system with rope jam cleat 1. Remove the bolt that secures the LoPro fitting on the right side of the foot bar. Place the anchor control system on top of the foot bar 1 - Intermediate pulley with the pulley facing the stern of the Drifter 13.

  • Page 6: Storage Tips

    Storage Tips • It is best to store your Drifter 13 to soft pressure under a cover or car port that provides protection from environmental elements. This will help prevent weather and UV damage and will keep your AIREcells aligned.

  • Page 7: Basic Troubleshooting

    • Tighten valve with the valve wrench if necessary. Drifter 13 becomes soft after the inflation process. • Top off air pressure in the cold water to counter thermal contraction. • Determine which air chamber is soft. Make sure the valve is functioning correctly, with no signs of leaking.

  • Page 8: Warranty

    UV damage, abnormal abuse, neglect and/or inappropriate storage. This warranty can be void if the boat is structurally altered or used commercially. The Period of Coverage: Your boat is covered from the original purchase date for a period of five years. Outcast Sporting Gear ~ 844-243-2473 ~ 2021 E Wilson Lane. Meridian, ID 83642 ~ info@outcastboats.com...
