GDC SERIES GAS DUPLEX COOKERS
MODELS
GDC24
ML-52581
GDC36
ML-52582
GDC48
ML-52583
GDC60
ML-52584
GDC72
ML-52585
V U L C A N - H A R T C O M P A N Y , P . O . B O X 6 9 6 , L O U I S V I L L E , K Y 4 0 2 0 1 - 0 6 9 6 , TEL. (502) 7 7 8 - 2 7 9 1
FORM 30501 (Rev. A, 11-95)
OPERATION MANUAL
Get other manuals https://www.bkmanuals.com
INSTALLATION &
MODEL GDC48
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vulcan-Hart GDC Series
Summary of Contents for Vulcan-Hart GDC Series
- Page 1 INSTALLATION & OPERATION MANUAL GDC SERIES GAS DUPLEX COOKERS MODELS GDC24 ML-52581 GDC36 ML-52582 GDC48 ML-52583 GDC60 ML-52584 GDC72 ML-52585 MODEL GDC48 V U L C A N - H A R T C O M P A N Y , P . O . B O X 6 9 6 , L O U I S V I L L E , K Y 4 0 2 0 1 - 0 6 9 6 , TEL. (502) 7 7 8 - 2 7 9 1 FORM 30501 (Rev.
-
Page 2: Important For Your Safety
CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT. IN THE EVENT OF A POWER FAILURE, DO NOT ATTEMPT TO OPERATE THIS DEVICE. — 2 — © VULCAN-HART COMPANY, 1989 Get other manuals https://www.bkmanuals.com... -
Page 3: Installation
KEEP THESE INSTRUCTIONS FOR FUTURE USE GENERAL The GDC Series Gas Duplex Cookers combine a high efficiency gas griddle with adjustable-height, thermostat-controlled electric platens to provide fast production of grilled foods. Vulcan Duplex Cookers are produced with quality workmanship and material. -
Page 4: Installation Codes And Standards
Casters (Optional) If the cooker is equipped with casters, the gas connector (available from Vulcan-Hart) must comply with the Standard for Connectors of Movable Gas Appliances, ANSI-Z21.69 (latest edition), and a quick- disconnect device that complies with the Standard for Quick-Disconnect Devices for Use With Gas Fuel, ANSI-Z21.41 (latest edition). -
Page 5: Gas Connections
Fig. 1 Stand (Fig. 1) 1. Thread leg extension into fixed nut in griddle frame. 2. Thread adjustable leg through undershelf into leg extension. 3. Tighten both leg extension and adjustable legs. 4. If casters are furnished instead of adjustable legs, the locking swivel casters must be placed in the front. -
Page 6: Electrical Connections
When test pressures are psig (3.45 kPa) or less, the cooker must be isolated from the gas supply piping system by closing its individual shutoff valve. ELECTRICAL CONNECTIONS Make supply connections using insulated copper wire suitable for at least 90°C for the rated load. When initially selecting conduit size, keep in mind the possibility of additional platens being added to the duplex cooker at a later date. -
Page 7: Operation
OPERATION WARNING: THE DUPLEX COOKER AND ITS PARTS ARE HOT. BE CAREFUL WHEN OPERATING, CLEANING, AND SERVICING THE DUPLEX COOKER. CONTROLS (Fig. 2) Each griddle zone, one foot wide, and each platen has its own separate controls. TOP - SIDE COOKER HANDLE TWIN - CAM FEET PLATEN... -
Page 8: Before First Use
BEFORE FIRST USE The griddle plate is shipped with a protective coating. Remove this coating before cooking with griddle. Clean the griddle with a damp cloth and mild detergent. Rinse with a clean damp cloth and wipe dry. The griddle must be seasoned prior to first use. See the section titled SEASON GRIDDLE SURFACE for seasoning procedure. -
Page 9: Cleaning The Griddle
PREHEAT GRIDDLE CAUTION: Care must be exercised not to overheat the griddle plate by setting the thermostats well above recommended temperatures. Overheating the plate may cause plate warpage, and will carbonize any grease on the plate and cause sticking. 1. Set thermostat to desired griddle temperature. Burners should light. 2. - Page 10 After Each Use Clean the griddle with a flexible spatula or griddle scraper. Take care not to contact the platen surfaces as these can be easily scratched, shortening the life of the coating and promoting sticking. During The Day Flush the hot griddle with water and scrape with griddle scraper to reduce carbonized grease build-up. Follow by a light coating of oil to prevent product sticking.
-
Page 11: Maintenance
4. Check the flue for obstructions on an annual basis. 5. To recalibrate the thermostat, contact your Vulcan-Hart authorized servicer. REPLACEMENT OF THE PLATEN SURFACE Contact your Vulcan-Hart authorized servicer for replacement kits for platen surfaces. — 11 — Get other manuals https://www.bkmanuals.com... - Page 12 Tools required: socket (magnetic) drive drive universal joint drive 6" extension drive ratchet 1. Remove platen cover (Fig. 3). 2. Remove all bolts from platen. Remove platen surface. (Fig. 4) Fig. 3 Fig. 4 3. Clean surface thoroughly. Make sure all foreign particles are removed from both surfaces (Fig. 5). 4.
-
Page 13: Service And Parts Information
To obtain service and parts information concerning this duplex cooker, contact the Vulcan-Hart Service Agency in your area (refer to listing supplied with the duplex cooker), or Vulcan-Hart Company Service Department at the address or phone number shown on the front cover of this manual. -
Page 14: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE Red light won't come on when main switch is on. Not plugged in. Problem with On-Off switch. Building circuit breaker tripped. Problem with lamp in switch. Red light won't go off when Main On-Off or Thermostat Problem with On-Off switch. - Page 15 PROBLEM POSSIBLE CAUSE Heat doesn't turn off; amber light is off; temperature Problem with thermostat gas valve. is above thermostat setting. Heat doesn't turn off; amber light is on; temperature Problem with temperature controller. is above thermostat setting. Problem with remote set-pot. Fat appears to smoke excessively.
- Page 16 FORM 30501 (Rev. A, 11-95) — 16 — Get other manuals https://www.bkmanuals.com...
