VCH SERIES
COOK & HOLD
CABINETS
MODEL
VCH5
VCH8
VCH16
VCH88
For additional information on Vulcan-Hart or to locate an authorized parts
and service provider in your area, visit our website at www.vulcanhart.com
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
REPLACEMENT PARTS
ML-126339
ML-126340
ML-126341
ML-126342
CATALOG OF
MODEL VCH16
P.O. BOX 696, LOUISVILLE, KY 40201-0696
FORM 37118 (Oct. 2007)
TEL. (800) 814-2028
Advertisement
Table of Contents
Related Manuals for Vulcan-Hart VCH16 ML-126341
Summary of Contents for Vulcan-Hart VCH16 ML-126341
-
Page 1: Replacement Parts
VCH8 ML-126340 VCH16 ML-126341 VCH88 ML-126342 For additional information on Vulcan-Hart or to locate an authorized parts and service provider in your area, visit our website at www.vulcanhart.com VULCAN-HART DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC WWW.VULCANHART.COM CATALOG OF REPLACEMENT PARTS MODEL VCH16 P.O. - Page 2 VCH SERIES COOK & HOLD CABINET REPLACEMENT PARTS 2 - 3 - 4 8 - 9 - 1 0 1 1 - 1 2 - 1 3 1 8 - 1 9 PL-57201-V CABINET AND DOOR – 2 –...
- Page 3 ILLUS. PART PL-57201-V NO. 00-851800-00066 Gasket – Hot Top Seal (Orange) ... AR 00-851800-00091 Tunnel – Air Flow (VCH5) ... 1 00-851800-00092 Tunnel – Air Flow (VCH8, VCH88) ... AR 00-851800-00093 Tunnel – Air Flow (VCH16) ... 1 00-851800-00037 Grate – Blower Air ... AR 00-851800-00017 Gasket –...
- Page 4 VCH SERIES COOK & HOLD CABINET REPLACEMENT PARTS 2 - 3 1 0 - 1 1 7 - 8 - 9 1 3 - 1 4 2 6 - 2 7 1 7 - 1 8 2 3 - 2 4 PL-57200-V 2 1 - 2 2 CONTROLS AND COMPONENTS...
- Page 5 ILLUS. PART PL-57200-V NO. 00-851800-00043 Cover – Control Top ... AR 00-851800-00035 Motor – Blower (120 V.) ... AR 00-851800-00036 Motor – Blower (208-240 V.) ... AR 00-851800-00087 Thermostat – Cooling Fan ... AR 00-851800-00086 Thermostat – Hi-Limit ... AR 00-851800-00081 Suppressor (Orange) ...
- Page 6 VCH SERIES COOK & HOLD CABINET REPLACEMENT PARTS 4 T H RU 8 PL-57202 POWER BOX – 6 –...
- Page 7 ILLUS. PART PL-57202 00-851800-00062 Fuse (3 Amp.) ... AR 00-851800-00061 Holder – Fuse ... AR 00-851800-00085 Block – Terminal ... AR 00-851800-00048 Cord – Power (6 Ft.) (208 V.) (VCH5, VCH8, VCH88) ... AR 00-851800-00049 Cord – Power (6 Ft.) (208 V.) (VCH16) ... 1 00-851800-00050 Cord –...
-
Page 8: Recommended Spare Parts
VCH SERIES COOK & HOLD CABINET REPLACEMENT PARTS PART 00-851800-00017 Door Gasket (By Foot) ... AR 00-851800-00018 Door Hinge ... 4 00-851800-00035 Blower Motor Kit (115 V.) ... AR 00-851800-00036 Blower Motor Kit (208-240 V.) ... AR 00-851800-00040 Contactor (2-pole, 115 V.) ... 1 00-851800-00041 Contactor (2-pole, 208-240 V.) ...
