  • Page 2 For the enthusiast user who wants to have insights, curiosities and detailed information about the characteristics and functions of the vehicle, Fiat gives the opportunity to consult a dedicated section which is available in electronic format. ONLINE VEHICLE OWNER HANDBOOK The following symbol ...
  • Page 3 In the attached Warranty Booklet you will also find a description of the Services that Fiat offers to its customers, the Warranty Certificate and the detail of the terms and conditions for maintaining its validity.
  • Page 4 ELECTRICAL ACCESSORIES If, after buying the vehicle, you decide to add electrical accessories (with the risk of gradually draining the battery), contact a Fiat Dealership. They can calculate the overall electrical requirement and check that the vehicle's electric system can support the required load.
  • Page 5 USE OF THE OWNER HANDBOOK OPERATING INSTRUCTIONS Each time direction instructions (left/right or forwards/backwards) about the vehicle are given, these must be intended as regarding an occupant in the driver's seat. Special cases not complying with this rule will be specified as appropriate in the text. The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the image do not correspond to the actual arrangement of your car.
  • Page 6 VEHICLE CHANGES/ALTERATIONS IMPORTANT Any change or alteration of the car might seriously affect its safety and road holding, thus causing accidents, in which the occupants could even be fatally injured.
  • Page 7 KNOWING YOUR CAR KNOWING THE INSTRUMENT PANEL SAFETY STARTING AND DRIVING IN AN EMERGENCY SERVICING AND CARE TECHNICAL DATA MULTIMEDIA INDEX...

  • Page 9: Table Of Contents

    KEYS ..........IThe handbook that you are reading IGNITION DEVICE ......10 simply and directly explains how it THE FIAT CODE SYSTEM ....10 is made and how it works. DOORS........... 11 That’s why we advise you to read it seated comfortably on board, so that SEATS ..........

  • Page 10: Dashboard

    DASHBOARD The presence and position of controls, instruments and gauges may vary depending on the versions. F1D0131 1. Adjustable air vents 2. Exterior light control stalk 3. Driver front airbag 4. Windscreen wiper/rear window wiper/trip computer control lever 5. Adjustable and directable central air vents 6. Passenger front airbag 7. Glove compartment (for versions/markets, where provided) 8. Radio (for versions/markets, where applicable) 9.

  • Page 11: Keys

    The metal insert A fig. 2 of the key If you need a new mechanical key or a containers, otherwise take them to a Fiat operates: new key with remote control, go to a Dealership, which will deal with their the ignition device;...

  • Page 12: Ignition Device

    2) If the ignition device has been tampered immobiliser. with (e.g. an attempted theft), have it checked by a Fiat Dealership before driving The code is sent only if the Fiat CODE again. system control unit has acknowledged 3) Always remove the key when you leave the code received from the key.

  • Page 13: Doors

    Mechanical key: insert the metal voltage drop). Should the fault persist, LOCKING/UNLOCKING insert in the lock and turn it. DOORS FROM THE contact a Fiat Dealership. Key with remote control (for INSIDE versions/markets where provided): Push the control lever A fig. 4 towards...

  • Page 14: Seats

    SEATS Backrest angle adjustment Operate lever C fig. 7 to reach the desired position, then release it. FRONT SEATS 7) 8) 9) 10) Longitudinal adjustment Lift lever A fig. 6 and push the seat forwards or backwards: in the driving position, you should be able to rest your arms on the rim of the steering wheel.
  • Page 15 FRONT SEAT ELECTRIC operate the levers at the sides of the 9) Once you have released the adjustment HEATING lever, always check that the seat is locked rear seats fig. 10 pushing them (for versions/markets, where provided) on the guides by trying to move it back and towards the inside of the vehicle, fold forth.

  • Page 16: Head Restraints

    HEAD RESTRAINTS REAR HEAD RESTRAINTS Upwards adjustment: raise the head WARNING 11) 12) restraint until it clicks into place. FRONT HEAD Downward adjustment: press button 11) All adjustments must be made with the RESTRAINTS A fig. 12 and lower the head restraint. car stationary.

  • Page 17: Steering Wheel

    STEERING WHEEL REAR VIEW MIRRORS WARNING 13) 14) ADJUSTMENTS 13) All adjustments must be carried out REAR-VIEW MIRROR only with the car stationary and engine off. The steering wheel can be adjusted The mirror is fitted with a safety device 14) It is absolutely forbidden to carry out vertically.

  • Page 18: Exterior Lights

    EXTERIOR LIGHTS The left stalk fig. 17 controls the operation of the headlights, side lights, dipped beam headlights, parking lights, main beam headlights, direction indicators, and "Follow me home" device. F1D0015 F1D0016 To carry out the adjustment, proceed as Manual folding follows: When required, fold the mirrors toward select the desired mirror (left or right)
  • Page 19 SIDE LIGHTS / DAYTIME MAIN BEAM HEADLIGHTS "Lane Change" function RUNNING LIGHTS (DRL) To switch on the main beam headlights, If you wish to signal a lane change, "Daytime Running Lights" pull the stalk towards the steering place the left stalk in the unstable (for versions/markets, where provided) wheel beyond the end of travel click position for less than half a second.
  • Page 20 Deactivation: keep the stalk pulled With front fog lights on, the warning 17) Daytime running lights cannot replace dipped beam headlights when driving at towards the steering wheel for more light on the instrument panel will come night or through tunnels. The use of than two seconds.

  • Page 21: Interior Lights

    INTERIOR LIGHTS pressed to the left (position 0): lights ROOF LIGHT TIMING C and D are always switched off; On certain versions, to facilitate getting pressed to the right (position 2): in/out of the vehicle at night or in FRONT CEILING LIGHT lights C and D are always switched on.

  • Page 22: Window Washing

    (even after turning the key and restarting position to operate the rear window for which the stalk is held in this the engine), contact a Fiat Dealership. wiper as follows: position. When released, the stalk will 5) Do not operate the windscreen or rear...

  • Page 23: Climate Control System

    CLIMATE CONTROL SYSTEM MANUAL HEATER / CLIMATE CONTROL (for versions/markets, where provided) Controls F1D0132 A - Air temperature adjustment knob (red-hot / blue-cold). B - Air recirculation knob: internal air recirculation. air intake from outside.
  • Page 24 IMPORTANT It is advisable to switch the air recirculation on whilst queuing or in tunnels, or whilst driving on dusty roads, to prevent the introduction of polluted air. However, it is better not to use the function for long periods, particularly if there are many people on board, to prevent the windows from misting.
  • Page 25 AUTOMATIC CLIMATE CONTROL SYSTEM (for versions/markets, where provided) Controls F1D0708 A - Turns on the AUTO function (climate control system automatic operation). B - Increases the air temperature. C - Decreases the air temperature. D - Selects manual air distribution. By pressing the buttons, one of the five possible air flow distribution patterns can be selected: air flow to the windscreen and front side window diffusers to demist or defrost them.
  • Page 26 . The use of other coolants affects the efficiency and condition of the system. The lubricant used for the compressor is also strictly linked to the type of cooling gas, please refer to a Fiat...

  • Page 27: Electric Windows

    ELECTRIC WINDOWS MANUAL REAR WINDOW BONNET WINDERS ELECTRIC FRONT OPENING To open/close the window operate the WINDOWS Proceed as follows: handle on the door panel. 19) 20) pull lever A fig. 25 in the direction These operate when the ignition key is indicated by the arrow;...
  • Page 28 lift the bonnet and, at the same time, CLOSING release the supporting rod C fig. 27 Proceed as follows: WARNING from its catch D, then insert the end of keep the bonnet raised with one the rod into housing E in the bonnet hand and remove rod C fig.

  • Page 29: Boot

    BOOT The tailgate can be opened at any time, if the doors are unlocked. To open it, enable the handle, opening one of the The boot unlocking is electrically front doors or unlocking the doors operated and is deactivated when the with the remote control or using the key car is in motion.

  • Page 30: Usb Port

    USB PORT NOTE The USB port handles data transmission from the Pen Drive/ (for versions/markets, where provided) WARNING Smartphone, etc. and slow recharging, Depending on the trim level, the car which is not guaranteed as it depends may be equipped with a USB port on 25) Be careful not to hit objects on the on the device type/brand of the external storage shelf when you open the tailgate.

  • Page 31: Smartphone Docking

    SMARTPHONE DOCKING (for versions with Uconnect Mobile) Depending on the trim level, the car may be equipped with a smartphone docking station to be installed on the dashboard. Installing/uninstalling the station F1D1015 F1D1016 Install the smartphone docking station Inserting/removing the lay the smartphone on the front by inserting it in the specific seat on the smartphone...

  • Page 32: Version With Lpg System

    To remove the smartphone from the VERSION WITH LPG docking station: SYSTEM turn the ring nut A fig. 35 so that it clicks into position take out the smartphone by pressing 30) 31) 14) 10) 11) 12) 13) it down to open the gripping hand; INTRODUCTION remove the smartphone from the The LPG version features two fuel...
  • Page 33 LPG and the four malfunctions leading to the risk of fire. country has expired, go to a Fiat Dealer bars of the digital gauge turn off. to have the tank replaced. 32) Do not switch between the two operating modes whilst starting the engine.

  • Page 34: Version With Methane System (Natural Power)

    LPG levels in the tank or METHANE CYLINDERS later refitted by a Fiat Dealership. Although request for high performance (e.g. The vehicle is equipped with two the LPG system has numerous safety...
  • Page 35 IMPORTANT If the vehicle has been To guarantee switching in full safety, the registered in a country other than Italy, actual change to the chosen fuel the certification data, identification system takes place depending on the and inspection procedures for car usage conditions;...
  • Page 36 In the 33) The Fiat Panda Natural Power is 20) If the fuel runs out while running on event of low methane levels in the tank or a...
  • Page 37 KNOWING THE INSTRUMENT PANEL This section of the handbook gives you CONTROL PANEL AND all the information you need to ON-BOARD INSTRUMENTS ... 36 understand, interpret and use the DISPLAY ......... 37 instrument panel correctly. WARNING LIGHTS AND MESSAGES ........39 - Red warning lights ......

  • Page 38: Control Panel And On-Board Instruments

    CONTROL PANEL AND ON-BOARD INSTRUMENTS The instrument background colour and type may vary according to the versions. The warning lights on the instrument panel may change according to the version/trim level (e.g. LPG, Cross etc.) of the vehicle. F1D0809 A. Speedometer – B. Multifunction display – C. Rev counter...

  • Page 39: Display

    DISPLAY L Engine coolant temperature indicator. M Fuel level indicator. GEAR SHIFT INDICATOR The display fig. 46 will show the The GSI (Gear Shift Indicator) system following information: advises the driver to change gear through a specific indication on the control panel.
  • Page 40 LANGUAGE by pressing the “Trip A” can be used to display the buttons, select "Yes" (to confirm values relating to: "Outside temperature BUZZER VOLUME activation/deactivation) or "No" (to (for versions/markets, where provided)", SEAT BELT BUZZER (for versions/ cancel); "Range", "Travel Distance", "Average markets, where provided) Fuel consumption", "Current fuel press the...

  • Page 41: Warning Lights And Messages

    For permanent deactivation of the acoustic signal (buzzer) of the S.B.R. (Seat Belt Reminder) system contact a Fiat Dealership. The system can be reactivated using the Setup Menu.
  • Page 42 On certain versions a dedicated message is displayed. amber Drive very carefully to the nearest Fiat Dealership to have the system inspected immediately. amber AIRBAG FAILURE When the ignition key is turned to MAR, the warning light switches on but should switch off after a few seconds.
  • Page 43 An acoustic signal is activated with the doors open and the car moving. WARNING 39) If the warning light switches on when travelling, stop the car immediately and contact a Fiat Dealership.
  • Page 44 The warning light turns on constantly, on some versions along with a dedicated message on the display, when the system detects that engine oil pressure is insufficient. WARNING 40) If the warning light switches on when travelling (on certain versions together with the message on the display), stop the engine immediately and contact a Fiat Dealership.
  • Page 45 20 seconds and then restart the engine. If the warning light, on some versions along with a dedicated message on the display, remains on, contact a Fiat Dealership. IMPORTANT After the battery is disconnected, the steering must be initialised. The warning light switches on to indicate this.

  • Page 46: Amber Warning Lights

    In addition, the airbag system automatically disables the airbags on the passenger's side (front and side bags where provided). Before continuing, contact a Fiat Dealership immediately to have the system checked.
  • Page 47 Fiat Dealership as soon as possible.
  • Page 48 If the warning light does not switch off or stays on while driving, on some versions along with a message on the display, contact a Fiat Dealership. Flashing of the warning light while driving indicates the intervention of the ESC system.
  • Page 49 50 km (or equivalent value in miles), on some versions, the display will show a dedicated message. IMPORTANT The warning light will flash to indicate a system fault. If this is the case, go to a Fiat Dealership amber to have the system checked.
  • Page 50 The warning light switches on, on some versions along with a message on the display, when a temporary or permanent City Brake Control system fault is detected. If the fault is permanent: contact a Fiat Dealership to have the system checked.
  • Page 51 ELD system failure (for versions/markets, where provided) The warning light switches on, on some versions along with a dedicated message on the display, when a fault is detected in the 4x4 drive. Contact a Fiat Dealership as soon as possible.
  • Page 52 If this is not the case, carry out the Tyre reset procedure after restoring the normal operating conditions. If the malfunction warning persists, contact a Fiat Dealership as soon as possible. LPG FUEL RESERVE (for versions/markets, where provided) The warning light switches on when the residual quantity of LPG drops below 1/5 of the tank capacity.

  • Page 53: Green Warning Lights

    The warning light on flashing indicates activation of the electronic locking differential (ELD) function. green GRAVITY CONTROL SYSTEM (Panda Cross 4x4 versions) The warning light on constantly, along with a dedicated message on the display, indicates activation of the Gravity Control function. Deactivation of the function is signalled by flashing of the warning light, by an acoustic warning and by a dedicated message on the display.

  • Page 54: Blue Warning Lights

    Warning light What it means SIDE LIGHTS AND DIPPED BEAM HEADLIGHTS/FOLLOW ME HOME Side lights and dipped beam headlights The warning light switches on when the side lights or dipped headlights are turned on. Follow Me Home The warning light comes on, on some versions along with a dedicated message on the display, when the green "Follow me home"...

  • Page 55: Symbols And Messages On The Display

    In this case, contact a Fiat Dealership as soon as possible, running on petrol FUEL LEVEL SENSOR FAILURE The symbol appears and all the notches disappear in the event of fuel gauge sensor failure. Contact a Fiat Dealership as soon as possible.
  • Page 56 SAFETY The chapter that you are about to read ACTIVE SAFETY SYSTEMS .... 55 is very important: it describes the DRIVING ASSISTANCE SYSTEMS .. 61 safety systems with which the vehicle is OCCUPANT PROTECTION equipped and provides instructions on SYSTEMS ........65 how to use them correctly SEAT BELTS ........

  • Page 57: Active Safety Systems

    ACTIVE SAFETY HH (Hill Holder) SYSTEM 42) 43) 44) 45) 46) 47) 48) 49) 50) SYSTEMS This system is an integral part of the ESC (Electronic Stability ESC system and facilitates starting on Control) SYSTEM slopes. (for versions/markets, where provided) ABS (Anti-lock Braking It is automatically activated in the This is an electronic system that...
  • Page 58 IMPORTANT The Hill Holder system is HBA (Hydraulic Brake Assist) system not a parking brake, therefore do not leave the vehicle without activating the The HBA system is designed to handbrake, switching off the engine, improve the car’s braking capacity and engaging first gear, with the vehicle during emergency braking.
  • Page 59 50 km/h. Above this speed, it is fig. 49 (Panda 4x4 versions) or turn automatically deactivated and it is the ring to the left fig. 50 (Panda Cross reactivated when the speed falls below 4x4 versions) and keep it in this position 50 km/h.
  • Page 60 Noise and vibrations coming from the System intervention IMPORTANT On level ground in urban wheel sides (brakes) when the Gravity areas it is advisable to deactivate the You must travel at a speed slower than Control system is activated are normal. Gravity Control system intervention 25 km/h for the system to activate.
  • Page 61 IMPORTANT The Gravity Control Engagement/disengagement If the Traction Plus system is faulty, the system is deactivated when exceeding ESC warning light on the instrument The system is deactivated when 25 km/h and at speeds lower than panel switches on constantly. starting.
  • Page 62 48) The capability of the ABS must never 56) The capability of the ESC system must 64) The HBA system is an aid for the driver, be tested irresponsibly and dangerously, in never be tested irresponsibly and who must always pay full attention while such a way as to compromise personal dangerously, in such a way as to driving.

  • Page 63: Driving Assistance Systems

    DRIVING The system is only active if: Versions equipped with Start&Stop ASSISTANCE system: at the end of the automatic the ignition key is at MAR; SYSTEMS braking, the Start&Stop system will the vehicle speed is between 5 and activate as described in the "Start&Stop 30 km/h;...
  • Page 64 vehicles with small dimensions If one tyre only is flat, the system can and/or not aligned in the driving lane indicate its position: it is in any case (see fig. 55); recommended to check the pressure on all four tyres. lane change by other vehicles (see This indication is displayed also when fig.
  • Page 65 To carry out the RESET procedure, with Under special conditions (e.g. vehicle 67) The laser beam is not visible at the naked eye. Do not look directly, or with the vehicle stopped and the ignition loaded asymmetrically on one side, optical instruments (e.g.
  • Page 66 29) If the windscreen must be replaced WARNING due to scratches, chipping or breakage, contact exclusively a Fiat Dealership. 26) The laser sensor may have limited or Do not replace the windscreen on your absent operation due to weather...

  • Page 67: Occupant Protection Systems

    OCCUPANT SEAT BELTS To unfasten the seat belts, press button PROTECTION C. Guide the seat belt with your hand All vehicle seats are equipped with seat SYSTEMS while it is rewinding, to prevent it from belts with three anchor points and a twisting.
  • Page 68 Always adjust the height of the seat belt to fit the person wearing it: this WARNING precaution could greatly reduce the risk of injury in the case of collision. 76) Never press button C fig. 57 when Correct adjustment is obtained when travelling.

  • Page 69: Sbr (Seat Belt Reminder) System

    Once the cycle is complete, the warning (see the following paragraphs). warning lights stay on with a fixed light NOTE Contact a Fiat Dealership to until the vehicle is turned off or the deactivate this acoustic warning seat belt fastened.

  • Page 70: Pre-Tensioners

    82) 83) 84) 85) rear belts are already fastened the affected by water and/or mud, contact icons will be displayed for 30 a Fiat Dealership to have it replaced. seconds. The vehicle is equipped with front seat IMPORTANT To obtain the highest...
  • Page 71 GENERAL The seat belt strap must not be twisted. INSTRUCTIONS FOR The upper part must pass over the USING THE SEAT BELTS shoulder and cross the chest Seat belts are also to be worn by diagonally. The lower part must adhere pregnant women: the risk of injury in to the pelvis (as shown in fig.

  • Page 72: Child Protection Systems

    CARRYING CHILDREN SAFELY 82) The pretensioner may be used only 33) Operations which lead to impacts, once. Contact a Fiat Dealership to have it vibrations or localised heating (over 100°C 86) 87) 88) 89) replaced after it has been deployed.
  • Page 73 These devices are according to the instructions, which recommended having been specifically must be included. designed for Fiat vehicles. IMPORTANT Following an accident of a certain importance, it is recommended to replace both the child restraint system and the seat belt to which it...
  • Page 74 Group 0 and 0+ Group 3 Babies up to 13 kg must be carried For children between 22 kg and 36 kg, with a rear facing child restraint system there are boosters which allow the of a type as shown in fig. 66 which, seat belt to be applied correctly.
  • Page 75 PASSENGER SEAT COMPLIANCE WITH REGULATIONS ON UNIVERSAL CHILD RESTRAINT SYSTEM USE The car complies with the new European Directive 2000/3/EC which governs the arrangement possibilities for child restraints on the various seats of the car as shown in the following table: Rear central Front passenger's seat(*) passenger (for...
  • Page 76 INSTALLING AN ISOFIX CHILD CARSEAT 93) 94) 95) 96) The outer rear seats of the vehicle are equipped with ISOFIX anchorages, a European standard which makes fitting a child restraint system quick, simple and safe. The ISOFIX system lets you install the ISOFIX child restraining system without F1D0060 using the car seat belts but connecting...
  • Page 77 SUITABILITY OF PASSENGER SEATS FOR ISOFIX CHILD RESTRAINT SYSTEM USE The table below shows the various installation possibilities for ISOFIX child restraint systems on seats fitted with the specific anchorages in accordance with European standard ECE 16. Child restraint system Weight group Isofix size class Rear side Isofix positions...
  • Page 78 i-Size CHILD RESTRAINT SYSTEMS These child restraint systems, built and type-approved according to the i-Size (ECE R129) standard, ensure better safety conditions to carry children on board a vehicle: the child must be transported rearward facing until 15 months; child restraint system protection is F1B0124C increased in the event of a side NOTE See the table shown on the...
  • Page 79 The following table, according to European standard ECE 129, indicates the possibility of i-Size child restraint system installation. i-Size POSITIONS ON THE CAR Rear side Rear central Device Front passenger passengers passenger ISO/R2 i-Size child restraint systems ISO/F2 i-U: suitable for Universal i-Size child restraint systems, both rearward facing and forward facing. X: seat not suitable for Universal i-Size child restraint systems.
  • Page 80 CHILD RESTRAINT SYSTEMS RECOMMENDED BY FCA FOR YOUR PANDA ® Lineaccessori MOPAR includes a complete range of child restraint systems to be fixed using the seat belt with three anchorage points or the ISOFIX anchorages. IMPORTANT FCA recommends fitting the child restraint system according to the instructions, which must be included.
  • Page 81 Child restraint system Type of child restraint system Child restraint system installation BeSafe iZi Modular iSize Fiat order code: 71808565 i-Size approved child restraint system. It must be installed on the car Group 0+/1: together with the iZi Modular i-Size from 9 up to 18 kg Base (available separately).
  • Page 82 Group 3: Britax Römer KidFix XP ISOFIX anchorages of the vehicle, if from 22 to 36 kg (for versions/markets, where present. Fiat recommends installing from 136 cm to 150 provided) it using the vehicle’s ISOFIX Fiat order code: 71807984 anchor points.
  • Page 83 Main recommendations to carry Always check that the seat belt is children safely well fastened by pulling on it. WARNING Install the child restraint systems on While travelling, do not let the child the rear seat, which is the most sit incorrectly or unfasten the belts.

  • Page 84: Supplementary Restraint System (Srs) - Airbag

    90) Incorrect fitting of the child restraint 96) Fit the child restraint system when the SUPPLEMENTARY system may result in an inefficient car is stationary. The child restraint system RESTRAINT SYSTEM protection system. In the event of an is correctly fixed to the brackets when (SRS) - AIRBAG accident the child restraint system may you hear the click.
  • Page 85 In the event of an impact, those not The airbags are not deployed in the wearing a seat belt are projected event of minor frontal impacts (for forwards, and may come into contact which the restraining action of the seat with the bag which is still inflating.
  • Page 86 Deactivating the passenger side airbags: front airbag and side bag If a child must be carried on the front seat in a rearward facing child restraint system, deactivate the passenger front airbag and the side bags. With airbags deactivated, the (A-fig.
  • Page 87 Passenger side front airbag and child restraint systems: IMPORTANT F1D0127...
  • Page 88 80 and covered with trims that protect Airbag checking, repair and F1D0067 the heads of front and rear occupants replacement must be carried out at a in the event of a side impact. Fiat Dealership.
  • Page 89 Therefore, are deactivated. When the "red" warning always deactivate the passenger side light is on, before proceeding contact a Fiat activate one or more of the devices airbag when a rearward facing child Dealership to have the system immediately does not indicate a system malfunction.
  • Page 90 If this does not happen please contact is turned to MAR, there may be a fault with child. Therefore, always deactivate the a Fiat Dealership. If the car is switched the “red” warning light. In this case, after passenger side airbag when a rearward...
  • Page 91 STARTING AND DRIVING Let’s get to the "heart" of the vehicle: STARTING THE ENGINE ....90 seeing how you can exploit all of its PARKING THE VEHICLE ....91 potential to the full. MANUAL TRANSMISSION ....92 We’ll look at how to drive it safely in any MODE SELECTOR......

  • Page 92: Starting The Engine

    115) Remember that the power brake and electrical power steering are not seat, the interior rear view mirrors, Contact a Fiat Dealership if you still operational until the engine is started, the door mirrors and fasten the seat cannot start the engine.

  • Page 93: Parking The Vehicle

    Always remove the key from the ignition when leaving the car and take it with you. 117) The car should be braked after a few clicks of the lever, if it is not, contact a Fiat Dealership to have it adjusted. F1D0146...

  • Page 94: Manual Transmission

    118) In the case of parking manoeuvres on MANUAL IMPORTANT The clutch pedal should roads on a gradient, the front wheels TRANSMISSION be used only for gear changes. Do must be steered towards the pavement not drive with your foot resting on the (when parking downhill), or in the opposite 119) clutch pedal, however lightly.

  • Page 95: Mode Selector

    MODE SELECTOR "AUTO" MODE IMPORTANT When the "Off Road" mode is activated, the Start&Stop (Panda Cross 4x4 versions) It is a driving mode aimed at comfort system is temporarily disabled. and safety in normal grip and driving This device allows, using the ring of the Temporary deactivation of the system conditions.

  • Page 96: Dualdrive Electric Power

    "GRAVITY CONTROL" DUALDRIVE FUNCTION ELECTRIC POWER STEERING This driving function permits a constant vehicle speed to be maintained 120) 121) downhill. This only operates with the key turned On/Off to MAR and the engine started. The For engaging/disengaging the Gravity steering allows the force required at the Control function refer to the "Active steering wheel to be adjusted to suit...

  • Page 97: Eco Function

    121) Before servicing the vehicle, switch off ECO FUNCTION START&STOP the engine and remove the key from the SYSTEM (for versions/markets, where provided) ignition switch to activate the steering lock. This is especially important when the To activate the function press the ECO vehicle wheels are not touching the button fig.

  • Page 98: Parking Sensors

    F1D0040 WARNING F1D0045 122) If the battery needs to be replaced, ACTIVATION/ always contact a Fiat Dealership. Replace DEACTIVATION the battery with one of the same type (HEAVY DUTY) and with the same The sensors are automatically activated specifications.
  • Page 99 OPERATION WITH A the presence of ultrasonic systems TRAILER (e.g. pneumatic brake systems of WARNING trucks or pneumatic drills) near the The operation of the sensors is vehicle could alter the signals sent to automatically deactivated when the 41) For correct operation of the system, the sensor;...

  • Page 100: Refuelling The Vehicle

    REFUELLING THE REFUELLING Emergency refuelling PROCEDURE VEHICLE Proceed as follows: IMPORTANT If the filler compartment is open the boot and take the adapter washed with a high pressure jet, keep B fig. 90 located in the tool box it at a distance of at least 20 cm. (versions equipped with space-saver 125) 126) 127) wheel - for versions/markets, where...
  • Page 101 LPG versions Natural Power versions To access the LPG filler, open the access flap A fig. 91 and undo the cap To access filler B fig. 93, open the flap and undo cap A turning it anticlockwise. The profile of filler B for refilling is the universal type, compatible with Italian and NGV1 standards.
  • Page 102 Before proceeding with refuelling, E10: Unleaded petrol containing up to 126) Do not bring naked flames or lit cigarettes near to the fuel filler: fire risk. check the symbols inside the fuel filler 3.7% (m/m) oxygen and with maximum Keep your face away from the fuel filler to flap (where provided) and compare 10.0% (V/V) ethanol compliant with prevent breathing in harmful vapours.

  • Page 103: Towing Trailers

    2.5 weight of the trailer. Engage a low gear when driving On Panda Cross and Panda 4x4 downhill, rather than constantly using versions, in the event of prolonged the brake.

  • Page 104: Saving Fuel

    SAVING FUEL Electrical devices Unnecessary actions Only use electrical devices for the Avoid revving up when at traffic lights or Here are some suggestions which can amount of time needed. The heated before switching off the engine. This help you to save fuel and lower harmful rear window, additional headlights, action and also double declutching is emissions.
  • Page 105 CONDITIONS OF USE Cold starting Short distances and frequent cold start-ups will prevent the engine from reaching optimal running temperature. Consequently, both consumption (from +15 to +30% on urban cycle ) and emissions will increase. Traffic and road conditions Rather high fuel consumption is caused by heavy traffic, for instance when travelling in a queue with frequent use of low gears or in large towns with...
  • Page 106 IN AN EMERGENCY A punctured tyre or a burnt-out bulb? HAZARD WARNING LIGHTS...105 At times, a problem may interfere CHANGING A BULB .......105 with our journey. REPLACING FUSES......111 The pages on emergencies can help REPLACING A WHEEL ....114 you to deal with critical situations FIX&GO KIT........117 independently and with calm.

  • Page 107: Hazard Warning Lights

    HAZARD WARNING CHANGING A BULB NOTE When the weather is cold or LIGHTS damp or after heavy rain or washing, the surface of headlights or rear lights Press button A fig. 94 to switch the may steam up and/or form drops of lights on/off.
  • Page 108 Light bulbs Type Power Dipped/main beam headlights Front side lights/Day lights (DRL) P21/5W Rear side lights P21/5W Front direction indicators PY21W Side turn light Rear direction indicators PY21W Stop P21/5W Third brake light Fog lights Reverse gear W16W Rear fog light W16W Number plate...
  • Page 109 FRONT LIGHT CLUSTERS making sure that it is locked correctly, (Panda Cross versions) then reinsert the connector in its On the Panda Cross versions, the bulbs housing rotating it clockwise; are arranged inside the front light Side cluster fig. 96 as follows:...
  • Page 110 F1D0081 refit the new lamp and carry out the FRONT FOG LIGHTS procedure described previously in (for versions/markets, where provided - except Panda Cross versions) reverse. To replace the bulb, proceed as follows: FOG LIGHTS (Panda Cross versions) steer the wheel completely inwards, adjust the screws A fig.
  • Page 111 DAYTIME RUNNING RUNNING LIGHTS (DRL) LIGHTS (DRL) (for versions/markets, where provided - (Panda Cross versions) except Panda Cross versions) IMPORTANT To change LED DRLs To replace the bulb, proceed as follows: contact a Fiat Dealership. steer the wheel completely, adjust REAR LIGHT CLUSTERS the screws A fig.
  • Page 112 These are located in the tailgate and contacts, then refit the lens A fig. 110. are LED lights. For replacement, contact a Fiat Dealership. WARNING NUMBER PLATE LIGHTS To replace the bulbs, proceed as...

  • Page 113: Replacing Fuses

    44) Where possible, it is advisable to have REPLACING FUSES DASHBOARD FUSE BOX bulbs changed at a Fiat Dealership. The The fuse box fig. 112 is located near correct operation and direction of the the left side of the steering column and...
  • Page 114 ENGINE COMPARTMENT JUNCTION BOX fig. 111 USERS FUSE AMPERE Body Computer node Passenger compartment fan Fog lights Horns Main beam headlights Heated windscreen Air conditioning compressor Front power socket (with or without cigar lighter) Fuel pump Blow-by (*) reversing lights Mirror demisting Heated rear window Battery charge status sensor...
  • Page 115 DASHBOARD FUSE BOX fig. 112 USERS FUSE AMPERE (*) headlight alignment corrector (*) Ignition-operated control with inhibition during engine starting (**) (*) brake pedal switch (NO) Central door locking Two-way windscreen washer pump Front electric window (driver side) Front electric window (passenger side) (**) (*)+15 = ignition-operated positive pole (**)+30 = battery direct positive pole (not ignition-operated)

  • Page 116: Replacing A Wheel

    (compulsory by law) before and/or disengaged. device may be fitted on the jack. getting out of the vehicle; 139) Contact Fiat Dealership if a safety open the boot and lift up the mat A system (airbags, brakes), engine system Jack maintenance (engine, gearbox) or steering system fig.
  • Page 117 Then take the space-saver wheel C. B fig. 117 fits correctly into the side remove the wheel cap after For the Panda VAN and Panda 4x4 member C (next to the mark on the loosening the 3 fixing bolts and finally versions, the jack and the tools can be side member);...
  • Page 118 REFITTING THE use the wrench provided to fully STANDARD WHEEL tighten the bolts, passing alternately WARNING from one bolt to the opposite one; reinsert the press-fitted hub cap, Following the procedure described 140) The space-saver wheel (for making sure that the reference hole on previously, raise the car and remove the versions/markets where provided) is the wheel is aligned with the reference...

  • Page 119: Fix&Go Kit

    (e.g. on the dashboard) after repairing thoroughly. use, e.g. to jack up other vehicle models or the tyre; 47) Contact a Fiat Dealership as soon as different things, is strictly prohibited. Never possible to have the correct tightening one compressor B;...
  • Page 120 REPAIR PROCEDURE Proceed as follows: stop the car in a position that is not dangerous for oncoming traffic where you can carry out the procedure safely. The ground must be flat and sufficiently compact; stop the engine, engage the hazard warning lights and the parking brake;...
  • Page 121 / 26 psi, restore the pressure and WARNING sealant; stop the vehicle safely, operate drive safely to a Fiat Dealership as soon the handbrake and restore pressure as possible. If, however, the pressure 146) The information required by the using the black inflation pipe I fig.

  • Page 122: Jump Starting

    Lift the cover to access the Cable connection contact the Fiat Dealership immediately. positive terminal. Proceed as follows: Proceed as follows to carry out a jump IMPORTANT NOTES...

  • Page 123: Fuel Cut-Off System

    Only Fiat Dealership. use the specific earth point; do not use any To restore the correct operation of the other exposed metallic part.

  • Page 124: Towing The Vehicle

    F1D0095 Manually remove the cap A fig. 124 on switching off the engine. the front bumper, or A (for versions/ Panda Cross 4x4 and Panda 4x4 Natural Power versions: in the event versions markets, where provided) on the rear of an impact, the power supply is...
  • Page 125 153) Whilst towing, remember that as the assistance of the brake servo and the electric power assisted steering is not available, greater force needs to be exerted on the brake pedal and more effort is required on the steering wheel. Do not use flexible cables when towing and avoid jerky movements.
  • Page 126 SERVICING AND CARE Correct maintenance permits the SCHEDULED SERVICING ....125 performance of the vehicle to be BATTERY RECHARGING ....132 maintained over time, as well as limited ENGINE COMPARTMENT....134 running costs and safeguarding the efficiency of the safety systems. BRAKES .........138 This chapter explains how.

  • Page 127: Scheduled Servicing

    (less under the best conditions. regarding the car’s proper operation than 7-8 km) and repeated journeys For this reason, Fiat has planned a with your Fiat Dealership, before waiting with sub-zero outside temperatures; series of checks and services at fixed for the next coupon redemption.
  • Page 128 SERVICE SCHEDULE WARNING: Once you have carried out the last intervention in the table, continue with the scheduled servicing, maintaining the frequency indicated in the plan by marking each operation with a dot or dedicated note. Warning: simply restarting the maintenance from the start of the plan may cause the allowed interval to be exceeded for some operations! Thousands of miles Thousands of kilometres...
  • Page 129 Visually inspect condition and wear of rear disc brake pads and integrity of pad wear indicator (Panda Cross 4x4 and Panda 4x4 versions only) Visually check condition and wear of rear drum brake...
  • Page 130 Check tappet clearance and adjust if necessary (1.2 8V 69 HP LPG versions) Check manual gearbox with drive transmission idler unit (PTU) oil level (Panda Cross 4x4 and Panda 4x4 versions only) Check rear differential oil level (Panda Cross 4x4 and...
  • Page 131 Thousands of miles Thousands of kilometres Years Check fuel system operation and parameters using the diagnosis socket (LPG versions only) Visually inspect condition of: methane pipes and connectors and methane cylinder fastening, restore if necessary (Natural Power versions only) (3) Check pressure regulator and replace internal filter, if necessary (Natural Power versions only) (3) Check fuel system operation and parameters using self-...
  • Page 132 (see the "Engine" paragraph in the "Technical specifications" chapter); strictly comply with the spark plugs replacement intervals in the Service Schedule. It is advisable to contact a FIAT Dealership for plug replacement.
  • Page 133 Thousands of miles Thousands of kilometres Years Replace filter inside the pressure regulator (LPG versions only) Replace paper filter (LPG in gaseous state) (LPG versions only) Replace the passenger compartment cleaner (6) (O) (●) (6) If the vehicle is used in dusty areas, this cleaner must be replaced every 15,000 km. (O) Recommended operations.

  • Page 134: Battery Recharging

    At the RECHARGING procedure is given as information only. end of the charging process, switch the You are advised to contact a Fiat battery charger off; 156) 157) Dealership to have this operation after having disconnected the carried out.
  • Page 135 WARNING 156) Battery fluid is poisonous and corrosive: avoid contact with your skin and eyes. The battery should be charged in a well ventilated place, away from naked flames or possible sources of sparks: danger of explosion and fire. 157) Do not attempt to recharge a frozen battery: first it must be thawed, otherwise there is a risk of explosion.

  • Page 136: Engine Compartment

    ENGINE COMPARTMENT CHECKING LEVELS 158) 159) 0.9 TwinAir Turbo versions F1D0097 A. Engine oil cap/filler – B. Engine oil dipstick – C. Engine coolant fluid – D. Windscreen/rear window washer fluid – E. Brake fluid – F. Battery...
  • Page 137 1.2 8V 69 HP versions F1D0098 A. Engine oil cap/filler – B. Engine oil dipstick – C. Engine coolant fluid – D. Windscreen/rear window washer fluid – E. Brake fluid – F. Battery...
  • Page 138 A plug. Unscrew the cap again and check 160) periodic check carried out at a Fiat that the engine oil level is between the Dealership is, however, necessary to The coolant level must be checked MIN and MAX marks on the dipstick.
  • Page 139 To change the oil and filters, windscreen washer is essential for Topping up with an unsuitable fluid could we advise you to contact a Fiat Dealership. improving visibility. Some commercial severely damage your vehicle. windscreen washer additives are...

  • Page 140: Brakes

    In this case, it is still possible to continue driving, with caution. fit the new blade, inserting the tab However, contact a Fiat Dealership as into the special slot in the arm, making soon as possible to have the worn sure that it is locked;...

  • Page 141: Lifting The Vehicle

    The nozzle holder is located above 169) the rear window. 170) 171) If the vehicle needs to be raised, go to a Fiat Dealership which is equipped 58) 59) 60) 61) WARNING with arm lifts and workshop lifts fig. SUGGESTIONS ABOUT 132.

  • Page 142: Bodywork

    BODYWORK Dry the less visible parts (e.g. door frames, bonnet, headlight frames etc.) WARNING with special care, as water may stagnate more easily in these areas. PRESERVING THE 170) Do not cross switch the tyres if they BODYWORK The car should not be taken to a closed are "unidirectional"...

  • Page 143: Interior

    INTERIOR WARNING 172) 173) 5) Detergents pollute the environment. Only wash your vehicle in areas equipped SEATS AND FABRIC to collect and treat wastewater from this PARTS type of activity. Remove dust with a soft brush or a vacuum cleaner. Rub the seats with a sponge moistened with a solution of water and neutral detergent.
  • Page 144 TECHNICAL DATA IDENTIFICATION DATA....143 Everything you may find useful for ENGINE ..........144 understanding how your car is made WHEELS .........145 and works is contained in this chapter DIMENSIONS........153 and illustrated with data, tables and graphics. For the enthusiasts and the WEIGHTS........156 technician, but also just for those who REFUELLING ........159...

  • Page 145: Identification Data

    134: rear doors on the driver side to access A Paint manufacturer. it). It contains the following information: B Colour name. C Fiat colour code. D Respray and touch up code. F1D1005 A Name of Manufacturer B Type-approval number.

  • Page 146: Engine

    ENGINE 0.9 TwinAir Turbo 85 HP 4x4 / Versions 1.2 8V 70 HP 85 HP Cross 4x4 Engine code 169A4000 312A2000 Cycle Otto Otto Number and position of cylinders 4 in line 2 in line Piston bore and stroke (mm) 70.8 ×...

  • Page 147: Wheels

    WHEELS SNOW CHAINS 177) 178) 179) Important notes 174) 175) 176) The use of snow chains should be in Alloy or pressed steel rims. Tubeless compliance with local regulations of radial carcass tyres. each country. In certain countries, tyres All approved tyres are listed in the marked with code M+S (Mud and Registration Document.
  • Page 148 RIMS AND TYRES PROVIDED Panda versions Space saver spare Versions Wheels Tyres provided Winter tyres wheel 5.5J x 14H2 - ET35 (**) 175/65 R14 82Q (M+S) 135/80 R14 84M 175/65 R14 82T 1.2 8V 70 HP (****) (°) 185/55 R15 82Q (M+S)
  • Page 149 Panda 4x4 versions Space saver spare Versions Wheels Tyres provided Winter tyres wheel 5.5J x 14H2 - ET35 (**) 175/65 R14 84Q (M+S) 135/80 R14 84M 175/65 R14 82T 175/65 R14 82T (**) Goodyear Duragrip 5.5J x 14H2 - ET35...
  • Page 150 (***) Tyre not suitable for fitting snow chains. NOTE For Panda Cross 4x4 and Panda 4x4 versions if the space-saver wheel is used, the control unit for 4x4 drive detects its presence (via the wheel speed signals) and reduces the intervention of the four-wheel drive to a minimum, while guaranteeing...
  • Page 151 Panda Cross 4x2 versions Space saver spare Versions Wheels Tyres provided Winter tyres wheel 6J x 15H2 ET35 (**) – 125/80 R15 95M 175/65 R15 84T 1.2 8V 70 HP S&S 6J x 15H2 ET30 185/65 R15 88H (M+S) 185/65 R15 88H (M+S) 125/80 R15 95M (*) For versions/markets, where provided.
  • Page 152 When the tires are warm, the inflation pressure should be + 0.3 bar in relation to the recommended figure. However, recheck that the value is correct with the tyre cold. With winter tyres the pressure should be +0.2 bar compared with the recommended figure for the tyres that comes with the vehicle. Panda versions Unladen/medium load Full load...
  • Page 153 (**) For Panda Cross versions NOTE For Panda Cross 4x4 and Panda 4x4 versions, do not drive deliberately for long distances with the tyres flat (not at the prescribed pressure) and/or with greatly varying pressures between front axle and rear axle, in order to avoid any malfunction of the 4x4 drive.
  • Page 154 WARNING 63) With snow chains, use the accelerator with extreme care to prevent, or to limit as much as possible, slipping of the drive wheels that could cause chain breakage, resulting in damage to the car body or mechanical components.

  • Page 155: Dimensions

    DIMENSIONS Dimensions are expressed in mm and refer to the vehicle equipped with its standard-supplied tyres. Height is measured with car unladen. LUGGAGE COMPARTMENT CAPACITY Capacity (VDA standards) =225 litres Panda versions F1D0103 3653 2300 1551 1407 1643 1409 1882...
  • Page 156 Panda 4x4 versions F1D0104 3686 / 1672/ 765 / 747 2300 1605 1408 1411 1882 621 / 606 3653 1643 (*) VAN versions.
  • Page 157 Panda Cross versions F1D0121 1406 / 1403 / 1656.5 / 1412 – 1416 – 3705 772.5 2300 632.5 1662 1882 1635 1422 1426 (*) Panda Cross 4x2 versions...

  • Page 158: Weights

    WEIGHTS Panda versions Weights (kg) 1.2 8V 70 HP Unladen weight (with all fluids, fuel tank 90% full and (****) 940/965 without optional equipment): (****) (****) Payload including the driver: 480 (4-seater) / 455 (4-seater) / 500 (5-seater) / 475...
  • Page 159 Panda Cross and Panda 4x4 versions Weights (kg) 0.9 TwinAir Turbo 85 HP 1.2 8V 70 HP Unladen weight (with all fluids, fuel tank 90% full and without optional 1050 1000 equipment): 480 (4-seater) / 500 (5-seater) 455 (4-seater) / 475 (5-seater)
  • Page 160 Panda VAN versions Weights (kg) 0.9 TwinAir Turbo 85 HP 4x4 1.2 8V 70 HP Unladen weight (with all fluids, fuel tank 90% full and without optional 1035 935 (2-seater) / 945 (4-seater) equipment): 505 (2-seater) / 490 (4-seater) Payload including the driver:...

  • Page 161: Refuelling

    Mixture of water and PETRONAS DURANCE SC35 washer fluid reservoir (litres): (**) When the vehicle is used in particularly harsh weather conditions, we recommend using a mixture of 60% PARAFLU and 40% demineralised water. (***)Panda Cross 4x4 and Panda 4x4 versions...

  • Page 162: Fluids And Lubricants

    FLUIDS AND LUBRICANTS Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of the Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission specifications.
  • Page 163 Reference N° F702.G07 consistency 1-2. Grease for constant TUTELA STAR 700 velocity joints with low Differential side constant 9.55580 - GRASS II Contractual Technical friction coefficient. N.L.G.I. velocity joints Reference N° F701.C07 consistency 0-1. (°) Panda Cross 4x4 and Panda 4x4 versions.
  • Page 164 Original fluids and Features Specification Applications lubricants Synthetic fluid for brake and clutch systems. TUTELA TOP 4/S Hydraulic brakes and Brake fluid Exceeds specifications: 9.55597 or MS.90039 Contractual Technical hydraulic clutch controls FMVSS no. 116 DOT 4, Reference N° F005.F15 ISO 4925 SAE J1704.

  • Page 165: Performance

    PERFORMANCE Top speeds after the initial period of usage of the car. Versions km/h 0.9 TwinAir Turbo 85 HP 4x4 – 0.9 TwinAir Turbo 85 HP Cross 4x4 – 1.2 8V 70 HP 1.2 8V 70 HP S&S Cross 4x2 –...

  • Page 166: Fuel Consumption And Co2

    FUEL CONSUMPTION AND CO EMISSIONS The fuel consumption and CO emission figures declared by the manufacturer are determined on the basis of the type-approval tests laid down by the applicable standards in the country where the vehicle is registered. The type of route, traffic conditions, weather conditions, driving style, general condition of the car, trim level/equipment/ accessories, use of the climate control system, car load, presence of roof racks and other situations that adversely affect the aerodynamics or wind resistance lead to different fuel consumption values than those measured.

  • Page 167: Prescriptions For Handling The Vehicle At The End Of Its Life

    PRESCRIPTIONS FOR HANDLING THE VEHICLE AT THE END OF ITS LIFE (Where provided) FCA has been committed for many years to safeguarding the environment through the constant improvement of its production processes and manufacturing products that are increasingly "eco-compatible". To grant customers the best possible service in terms of respecting environmental laws and in response to European Directive 2000/53/EC governing vehicles at the end of their life, FCA is offering its customers the chance to hand over their vehicle at the end of its life without incurring any additional costs.
  • Page 168 MULTIMEDIA RADIO..........167 This chapter describes the main UCONNECT MOBILE – functions of the Radio, Uconnect UCONNECT BLUETOOTH ....175 Mobile system and Uconnect Bluetooth OFFICIAL TYPE APPROVALS ..190 system that can be fitted on the vehicle.
  • Page 169 In the case of loss of the vehicle radio code digits in the same way. The radio is equipped with an anti-theft passport, contact the Fiat Dealership, If the four digits are not entered within protection system based on an...
  • Page 170 QUICK GUIDE F1D0695...
  • Page 171 General functions Button Functions Mode Ignition short button press Switching off short button press Volume adjustment turn knob left/right FM AS FM1, FM2, FM Autostore radio source selection short cyclical button press MW1, MW2 radio source selection short cyclical button press MEDIA CD source selection short cyclical button press...
  • Page 172 Radio functions Button Functions Mode Automatic search: press buttons (hold the Radio station search: button down for fast forward) Automatic search Manual search: press buttons (hold the button Manual search down for fast forward) Long button press for memory preset 1 to 6 Store current radio station respectively 1 2 3 4 5 6...
  • Page 173 GENERAL INFORMATION CD section FUNCTIONS AND ADJUSTMENTS Direct selection of the disc; The radio has the following functions: Turning On the Radio Track selection (forward/back); Radio section Fast advance (forward/back) through The radio comes on when the PLL tuning with FM/AM/MW tracks;...
  • Page 174 Press the button again to deactivate EQUALISER: activation and RADIO ON VOLUME: maximum the Mute function. The volume will selection of factory-set equaliser levels; radio volume limit activation/ gradually increase until it reaches the deactivation. USER EQUALIZER: customised level set previously. equaliser setting.
  • Page 175 Each time the button is pressed, the Manual tuning Press the (EJECT) button with the AM and FM bands are selected radio on to activate the motorised Select the desired frequency band and cyclically: CD ejection. After ejection, the last then press the button briefly audio source listened to before playing...
  • Page 176 "Pause" function 184) Looking at the display for a long time: while driving, do not use any function To pause the CD player, press the WARNING that requires looking at the display for a button. The words "CD Pause" will long time.
  • Page 177 Uconnect Mobile – Care and maintenance The code is made up of four digits from Uconnect Bluetooth 1 to 6, each corresponding to one of Only clean the cover with a soft, the dashes. anti-static cloth. Cleaning and polishing 186) 187) 188) 189) 190) 191) 192) 193) 194) 195) To enter the first digit, press the products may damage the surface.
  • Page 178 Uconnect system is stolen. In the case of loss of the vehicle radio passport, contact the Fiat Dealership, taking an ID document and the vehicle ownership documents.
  • Page 179 QUICK GUIDE F1D1006...
  • Page 180 General functions Button Functions Mode Ignition short button press Switching off long button press Volume adjustment turn knob RADIO Select the radio source FM, AM, DAB (where present) short cyclical button press ABC – 1 2 3 4 5 6 Select preset ranges short cyclical button press MEDIA...
  • Page 181 Radio functions Button Functions Mode Automatic search: press buttons (hold the button Radio station search: down for fast forward) Automatic search Manual search: press buttons (hold the button Manual search down for fast forward) Store current radio station Long button press for memory preset 1 to 6 respectively 1 2 3 4 5 6 Stored station recall Brief press on buttons for memory preset 1 to 6...
  • Page 182 CONTROLS ON THE STEERING WHEEL F1D0106...
  • Page 183 Button Functions Mode Enable/disable Audio Mute Short button press Return to the previous menu mode function Increasing volume Button press – Decreasing volume Button press Select sources FM, AM, DAB (where provided), Button press ® Bluetooth Audio and USB Radio: automatic search for the next tunable broadcaster - Button press USB source: selecting the next track Radio: automatic search for the previous tunable...
  • Page 184 Button Functions Activation of voice recognition Interruption of the voice message in order to give a new voice command Adjust the audio volume of all functions: hands-free, text message reader, multimedia supports, voice messages, Radio, USB, depending on the active source. Scroll through Menu items on the panel Select multimedia support tracks Scroll through SMS messages in the list...
  • Page 185 GENERAL INFORMATION Right/left channel balance. If the volume level is changed during the transmission of traffic news, the The Uconnect systems have the Bluetooth® new setting will only be maintained until following functions: For the Bluetooth® function, see the the news is finished. Radio section description in the dedicated paragraph.
  • Page 186 The functions managed by the Menu NOTE FM following in DAB (where NOTE The AF SWITCHING, TRAFFIC are: provided; the radio switches INFORMATION and REGIONAL MODE automatically to FM in case of low DAB adjustments are only possible in FM BASS: adjustment of bass tones;...
  • Page 187 To listen to a preset station, select the NOTE The Uconnect™ system may Calling someone in the phonebook desired frequency band with the RADIO not support some USB keys: in this using voice commands: you can call button, briefly press ABC button to case, it will not automatically switch someone in your mobile phonebook select the preset band (A, B or C), and...
  • Page 188 Quick guide to the SMS message Connect the device to the USB port select the item chosen and confirm reader on the dashboard; with SRC/OK; It is also possible to access the same (only for mobile phones that support Turn the ignition key to MAR. The functions with the voice commands: this function) system will automatically start playing...
  • Page 189 Next track BLUETOOTH® DEVICE Press and say “Settings”. Then, at the end of the message, say To skip to the next track using manual IMPORTANT NOTES "Pairing". Access to the phonebook copied interaction: while listening to a digital The system will show a PIN number track, press (steering wheel controls) onto the system is possible only when...
  • Page 190 DIAL; (for Uconnect Mobile versions) your phone). CALL (followed by name); To use the Panda Uconnect app you Answering a call: CALL (followed by number); must download it from the Apple App To answer the call, press CALL BACK;...
  • Page 191 The app interface may change 188) Read and follow these instructions: 192) Looking at the display for a long time: before using your system, read and follow while driving, do not use any function depending on how it is used: all the safety information and instructions in that requires looking at the display for a connected or not connected to the car...
  • Page 192 OFFICIAL TYPE APPROVALS All radio equipment supplied with the vehicle complies with the 2014/53/EU directive. For further information visit the websites www.mopar.eu/owner or http://aftersales.fiat.com/elum/...
  • Page 193 DASHBOARD (RIGHT-HAND DRIVE VERSION) The presence and position of controls, instruments and gauges may vary depending on the versions. F0W0476 1. Adjustable and directable air diffusers 2. Exterior light control stalk 3. Driver front airbag 4. Windscreen wiper/rear window wiper/trip computer control lever 5.
  • Page 194 CONTROL PANEL AND ON-BOARD INSTRUMENTS The instrument background colour and type may vary according to the versions. The warning lights on the instrument panel may change according to the version/trim level (e.g. LPG, Cross etc.) of the vehicle. Warning lights are available on diesel versions only.
  • Page 195 The car should be braked after a few clicks of the lever, if it is not, contact a F0W0294 Fiat Dealership to have it adjusted. 198) In the case of parking manoeuvres on roads on a gradient, the front wheels...
  • Page 196 WIRING FOR RADIO SYSTEM If you wish to have a sound system installed after purchasing the vehicle, first contact a Fiat Dealership whose qualified personnel will give you advise about a sound system that does not damage the battery charge. Excessive non­running consumption damages the battery and may cause your battery warranty to be terminated.
  • Page 197 Fully comply with the regulations in force concerning maximum clearance. WIRING FOR RADIO SYSTEM For connection to the radio system set-up, contact a Fiat Dealership to prevent any problem that could impair vehicle safety. BODYWORK In order to preserve the aesthetic appearance of the paint abrasive products and/or polishes should not be used for cleaning the vehicle.
  • Page 202 MAINTAIN YOUR VEHICLE IN TIP TOP CONDITIONS WITH Mopar Vehicle Protection offers a series of service contracts that are designed to give all our customers the pleasure of driving their vehicle without any hitch's and concerns. Our product portfolio consists of a wide and flexible range of extended warranty and maintenance plans endorsed by FCA.
  • Page 203 NOTES...
  • Page 205 INDEX Daytime running lights (DRL) Front ceiling light ....19 "Daytime Running Lights" ..17 Front/rear fog lights....18 BS (system) .
  • Page 206 ccupant protection systems ..65 SBR (Seat Belt Reminder) echnical specifications... .143 system ......67 Official type approvals .
  • Page 207 At Fiat Service authorised workshops you can find technicians directly trained by us, offering quality and professionalism for all service operations. Fiat workshops are always close to you for the regular servicing operations, season checks and practical recommendations by our experts.
  • Page 208 The data contained in this publication is intended merely as a guide. FCA Italy S.p.A. reserves the right to modify the models and versions described in this booklet at any time for technical and commercial reasons. If you have any further questions please consult your FIAT dealer. Printed in recycled paper without chlorine.

Table of Contents

Save PDF
