June 2011©
Jacobsen HR6010 ROPS
** Shown with optional Golf Ball Mesh Package
Caution
** Please read installation instructions and follow all safety statements before attempting operating
this ROPS product.
** A copy of this operator manual should be kept with the machine operating manuals.
Jacobsen HR6010 ROPS Operator Manual
Jacobsen HR6010 ROPS
This ROPS is designed and built to fit
the Jacobsen HR6010.
Designed and Built by:
Tektite Manufacturing Inc:
24157 Hwy 3
P.O. Box 639
Winkler, MB
R6W 4A8
Canada
PH: 204-331-3463
Fax: 204-331-4159
sales@tektite.ca
www.tektite.ca
One year standard product
warranty provided by Tektite.
Advertisement
Related Manuals for Jacobsen HR6010
Summary of Contents for Jacobsen HR6010
- Page 1 June 2011© Jacobsen HR6010 ROPS Operator Manual Jacobsen HR6010 ROPS Jacobsen HR6010 ROPS ** Shown with optional Golf Ball Mesh Package This ROPS is designed and built to fit the Jacobsen HR6010. Designed and Built by: Tektite Manufacturing Inc: 24157 Hwy 3 P.O.
- Page 2 June 2011© Jacobsen HR6010 ROPS Operator Manual Tektite Manufacturing Incorporated thanks you for purchasing a Jacobsen HR6010 ROPS! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.
-
Page 3: Safety Precautions
June 2011© Jacobsen HR6010 ROPS Operator Manual Safety Precautions Safety First Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS. - Page 4 June 2011© Jacobsen HR6010 ROPS Operator Manual General Safety 1. Never let an unqualified or untrained driver operate the utility vehicle. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use.
- Page 5 June 2011© Jacobsen HR6010 ROPS Operator Manual Safe Operation on Rough Terrain 1. Drive the utility vehicle slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns.
- Page 6 June 2011© Jacobsen HR6010 ROPS Operator Manual 9. Use your turn signals, checking for traffic well in advance of turning. If the utility vehicle is not equipped with turn signals and law requires them, install them prior to operating on or near public roads.
- Page 7 June 2011© Jacobsen HR6010 ROPS Operator Manual Operating Instructions Important The following section locates, identifies and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the tractor. Failure to do so may result in unsafe operation of the tractor and possible injury or death to operators and bystanders.
- Page 8 June 2011© Jacobsen HR6010 ROPS Operator Manual 4. Rear Work Light Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work light is on. 5. Beacon Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work lights are on.
- Page 9 June 2011© Jacobsen HR6010 ROPS Operator Manual After your ROPS has been installed: Before starting a utility vehicle equipped with a Tektite ROPS: 1. Clear the operator platform of all tools. Tools left in or around the ROPS and utility vehicle can cause operator interference which could lead to bodily injury and/or damage the machine.
- Page 10 Index Service Part # File Name Description A00-0135 HEAD-LIGHT Head Light A00-0136 RED_TAIL_FLASH Red Turn, Tail Light A00-0143 TURN_LIGHT Turn light, Amber JaHR6010-01 JA6010-ASM-03_ROPS Main 4-Post ROPS Tektite Manufacturing Inc. 24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada Req'd: CNC: Description:...
