ELEEELS P2 Instruction Manual

P2
Pocket
Massage
Gun
Instruction Manual
CORDLESS/RECHARGEABLE
7.4 V Lithium-ion Battery
LIGHTWEIGHT DESIGN
0.79 lbs. / 360 g
We have developed the ELEEELS massage gun to accelerate recovery, prevents muscle
damage, relieves pain, promotes circulation, and everyday relaxation anytime, anywhere.
EN
1
2
3
5
Round Fork
1) Durable and lightweight with aluminium alloy body inside (360 grams)
2) High-torque and high-speed 38 mm brushless motor (delivers up to 50
strokes per second)
3) Rubberized surface for a no-slip grip
4) FOUR speed settings and FOUR applicators to t a wide range of therapeutic
and relaxation needs
5) Rechargeable lithium-ion battery with 7.4V output voltage (up to 6 hours of
use per charge)
6) Mini Piston Technology
Vibration Frequency:
Level 1 (30 strokes per second), Level 2 (37 strokes per second)
Level 3 (43 strokes per second), Level 4 (50 strokes per second)
Weight: 0.79 lbs. / 360 g
Charging Port: USB Type-C
INSTRUCTIONS
PLEASE READ PRIOR TO USE
CHARGING
1) Connect USB Type-C cable to the charging port
2) The charging speed depends on what adapter is used. It is suggested to use an
adapter supporting Type C (5V/3A), QC 3.0, or PD (9V/2A) to fully charge in
approximately 3 hours.
EN
3) During charging, the power indicator is in red solid light. When the green solid light is
Bullet Flat on, the device is fully charged.
4) The power indicator shows the battery level:
- Red ( ashes 1 time): 0-10%
- Green ( ashes 1 time): 11- 30%
- Green ( ashes 2 times): 31-70%
- Green ( ashes 3 times): 71-99%
- Green (solid light): 100%
OPERATING
• First, press the power button for 1.5 seconds to switch on. The power indicator will light
to show the battery level.
• Then, press the power button repeatedly to select the required speed level. The
currently selected speed level is shown by the blue speed indicator.
• Press the power button for 1.5 seconds to switch o .
• Massage the desired body part at the desired speed by applying pressure as needed.
• When the massage gun stops operation after a 10-minute session, simply press the
power button to start a new one.
MAINTENANCE, CLEANING & STORAGE
• Use a slightly damp towel to clean the device and a soft cloth to dry it.
• Do not clean the device with chemicals or alcohol.
• Only use the USB Type-C cable supplied by the ELEEELS for recharging.
WARNINGS & CAUTION
• Do not immerse in water. Keep away from liquids or heat sources. Keep ventilation
ports free from dust and debris.
• Do not remove screws or attempt to disassemble.
• Do not operate continuously for more than one hour. Allow device to rest for 10
minutes before re-using.
• For adult use only. Do not use if injured. Consult your doctor before using this product.
EN
Speed Indicator (Blue Light)
SAFETY INSTRUCTIONS
DANGER: TO REDUCE RISKS OF ELECTRIC SHOCK, FIRE, AND PERSONAL INJURY,
THIS PRODUCT MUST BE USED IN ACCORDANCE WITH THE FOLLOWING
USB Type-C Charging Port
INSTRUCTIONS:
Power Indicator
• Apply to a clean, dry clothed area of the body by lightly pressing and moving
across the body for approximately 60 seconds per area.
Power Button
• Only use the device on the body's soft tissue as desired. Do not use on the head or
any hard, bony areas of the body. Discontinue use immediately if experiencing
any pain.
• Do not drop the device.
• Do not tamper or alter the device in any way.
• Never leave the device unattended during operating or charging.
DISCLAIMER
Please do not use the ELEEELS P2, or any massage device without rst obtaining
approval from your doctor if you have any of the following conditions: pregnancy,
neuropathy, retinal damage, pacemaker user, recent surgery, epilepsy or migraines,
herniated disks, spondylolisthesis, spondylolysis, or spondylosis, recent joint
replacements, surgical pins or plates, or you have any concerns about your physical
health.
WARRANTY
IF WITHIN ONE YEAR FROM THE DATE OF PURCHASE, THIS PRODUCT FAILS DUE TO
A DEFECT IN THE MATERIAL OR WORKMANSHIP, ELEEELS WILL REPAIR OR REPLACE
THE PRODUCT; OR FAILED COMPONENT(S), FREE OF CHARGE
THIS WARRANTY EXCLUDES:
(a) Damage caused by accident, abuse, or mishandling during transport;
(b) Damage arising from use of units from unauthorized repair;
(c) Malfunction of units that are not used in accordance with ELEEELS care
instructions;
(d) Damage for which the cost of repair exceeds the cost of the product;
(e) Deterioration of the delivered product resulting from abnormal storage and/or
. safeguarding conditions on the client's premises, and
(f ) Any product for which a dated proof of purchase cannot be provided.
Please visit below link for instruction manual in other languages:
http://www.eleeels.com/im
EN
