- Page 1 Quick user’s guide COLOSSUS W103...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents..................3 Safety Instructions..................4 Device Description..................8 Replacing the battery................10 Inserting SIM & Micro-SD cards.............12 Use of the barcode reader...............14... -
Page 3: Package Contents
Package Contents Check your product box for the following items: - Rugged Tablet Colossus W103 - Hand Strap - Charger This device is in compliance with the essential safety requirements and other relevant provisions set out in the European Directive. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: Please read and observe carefully before using the device! Batteries: Batteries are parts whose life cycle depends on handling. If no failure is reported within 3 months after receipt of the equipment, the battery will be considered to be functioning properly. Failure to comply with these regulations will lead to the loss of guarantee. - Page 5 • Do not expose the battery to mechanical stress. • Do not damage the batteries with sharp or pointed objects. • Do not throw batteries into fire - they may explode. • Do not throw liquids on the batteries. • Avoid short-circuiting the batteries, as it can lead to overheating and ignition of the battery.
- Page 6 SAFETY INSTRUCTIONS Environment: Protect the device from temperatures outside the specified range. The device is protected against spray water but must not be submerged in water or be exposed to water jets. Do not expose the unit to strong magnetic fields or strong static electricity. Once water or liquid has entered the unit, turn it off and do not use until it is dried.
- Page 7 Cleaning: Never clean the surface of the appliance with solvents, detergents or other chemical products. Use a soft, dry cloth instead. Power supply: Always use the original charger or one with suitable current and voltage rating to prevent damage to the device. If you use an universal charger, consider the polarity of the charger as well as the current and the voltage rating.
-
Page 8: Device Description
DEVICE DESCRIPTION Frontal camera Barcode scan trigger Windows button Volume (+ / -) Power button... - Page 9 USB 3.0 Rear camera Audio Battery lock Mini HDMI User removable battery USB type C Docking connector Barcode reader RJ45...
-
Page 10: Replacing The Battery
Removing the battery Removing the battery 1. Slide the two latches to unlock the protective battery cover. 2. Take off the protection cover. 3. Slide the battery lock latch up 4. Remove the battery Warning: Make sure the device is properly shut down before attempting to remove the battery. - Page 11 INSERTING THE BATTERY Inserting the battery 1. Insert the battery from the contact side. 2. Slide the battery lock latch down 3. Put the battery cover back in place. 4. Slide the two latches to lock the protective battery cover...
-
Page 12: Inserting Sim & Micro-Sd Cards
Inserting SIM & Micro-SD cards Warning: • Before inserting SIM or SD card the device has to be shut down. • To install or to remove the SIM card or SD card, the battery Has to be removed first (page 10). •... - Page 13 Micro-SD...
-
Page 14: Use Of The Barcode Reader
Use of the barcode reader Attention: • Your device may not have a barcode reader, depending on the configuration acquired. • Note that the default configuration of the reader is via USB HID. Use barcode reader 1. Make sure there is an application open on the device and that a text field is focused (with the text cursor in the text field). - Page 15 Location of the barcode reader trigger button Scan the following barcodes to configure the barcode reader if necessary. Install barcode reader driver Restore to factory settings...
- Page 16 Av. Corts Catalanes, 5-7 08173 - Sant Cugat del Valles Barcelona - Spain https://www.thunderbook.eu...
