Summary of Contents for Thunderbook Colossus A100
- Page 1 Quick user’s guide COLOSSUS A100...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents..................3 Safety Instructions..................4 Device Description..................8 Replacing the battery................10 Inserting SIM y Micro-SD Cards.............12 Use of the barcode reader...............14... -
Page 3: Package Contents
Package Contents Check your product box for the following items: - Rugged Tablet Colossus A100 - Hand Strap - Carrying Case Handle - Micro-USB to female USB cord (15cm) - Micro-USB to male USB cord (1m) - DC-Jack Charger - USB Charger... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: Please read and observe carefully before using the device! Batteries: Batteries are parts whose life cycle depends on handling. If no failure is reported within 3 months after receipt of the equipment, the battery will be considered to be functioning properly. Failure to comply with these regulations will lead to the loss of guarantee. - Page 5 • Do not expose the battery to mechanical stress. • Do not damage the batteries with sharp or pointed objects. • Do not throw batteries into fire - they may explode. • Do not throw liquids on the batteries. • Avoid short-circuiting the batteries, as it can lead to overheating and ignition of the battery.
- Page 6 SAFETY INSTRUCTIONS Environment: Protect the device from temperatures outside the specified range. The device is protected against spray water but must not be submerged in water or be exposed to water jets. Do not expose the unit to strong magnetic fields or strong static electricity. Once water or liquid has entered the unit, turn it off and do not use until it is dried.
- Page 7 Cleaning: Never clean the surface of the appliance with solvents, detergents or other chemical products. Use a soft, dry cloth instead. Power supply: Always use the original charger or one with suitable current and voltage rating to prevent damage to the device. If you use an universal charger, consider the polarity of the charger as well as the current and the voltage rating.
-
Page 8: Device Description
DEVICE DESCRIPTION Webcam Ambient light sensor Touchscreen... - Page 9 POGO-Pin Kensington Lock Audio-in Mini-HDMI RJ-45 (Ethernet) Micro-USB RS-232 (COM) USB Type A Camera DC-in Barcode Scanner (Optional) Volume - / + Hand Strap Fixation Points Programmable Button Battery Release Lock Power Button Barcode Scanner Trigger Accessories Attachement 10 11 12 13...
-
Page 10: Replacing The Battery
Removing the battery Warning: Make sure the device is properly shut down before attempting to remove the battery. Removing the battery 1. Press and slide the Release Lock Button to unlock the battery. 2. Slide the battery, as shown in the picture. 3. - Page 11 INSERTING THE BATTERY Inserting the battery 1. Insert the battery with the non-contact side first. 2. Push down the other side of the battery and slide the battery like shown in the picture. 3. Press the Release Lock Button and slide it to the “Locked” position.
-
Page 12: Inserting Sim Y Micro-Sd Cards
Inserting SIM & Micro-SD cards Warning: • Before inserting SIM or SD card the device has to be shut down. • To install or to remove the SIM card or SD card, the battery Has to be removed first (page 6). Inserting the mini SIM card The slot accepts only mini SIM cards. -
Page 14: Use Of The Barcode Reader
Use of the barcode reader Attention: • To activate the reader it is necessary to start the “application” HardDeCode if the device has been rebooted, shut down or restored. • Your device may not have a barcode reader, depending on the configuration acquired. •... - Page 15 Barcode reader location Location of the barcode reader trigger button...
- Page 16 Av. Corts Catalanes, 5-7 08173 - Sant Cugat del Valles Barcelona - Spain https://www.thunderbook.eu...
