Thunderbook Atlas W115 Quick User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
QUIck user'S GUIDE
ATLAS W115

Advertisement

loading
Need help?

Need help?

Do you have a question about the Atlas W115 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Thunderbook Atlas W115

Summary of Contents for Thunderbook Atlas W115

  • Page 1 QUIck user’S GUIDE ATLAS W115...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Package Contents..................3 Safety Instructions..................4 Device Description..................8 Replacing the battery................10 Inserting SIM y Micro-SD Cards.............12 Configure programmable buttons............14...

  • Page 3: Package Contents

    Package contents Check your product box for the following items: • Rugged Tablet Atlas W115 • Stylus pen • Crystal clean cloth • DC-Jack Charger 220VAC Package contents This device is in compliance with the essential safety requirements and other relevant provisions set out in the...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS Warning: Please read and observe carefully before using the device! Batteries: Batteries are parts whose life cycle depends on handling. If no failure is reported within 3 months after receipt of the equipment, the battery will be considered to be functioning properly. Failure to comply with these regulations will lead to the loss of guarantee.
  • Page 5 • Do not expose the battery to mechanical stress. • Do not damage the batteries with sharp or pointed objects. • Do not throw batteries into fire - they may explode. • Do not throw liquids on the batteries. • Avoid short-circuiting the batteries, as it can lead to overheating and ignition of the battery.
  • Page 6 SAFETY INSTRUCTIONS Environment: Protect the device from temperatures outside the specified range. The device is protected against spray water but must not be submerged in water or be exposed to water jets. Do not expose the unit to strong magnetic fields or strong static electricity. Once water or liquid has entered the unit, turn it off and do not use until it is dried.
  • Page 7 Cleaning: Never clean the surface of the appliance with solvents, detergents or other chemical products. Use a soft, dry cloth instead. Power supply: Always use the original charger or one with suitable current and voltage rating to prevent damage to the device. If you use an universal charger, consider the polarity of the charger as well as the current and the voltage rating.

  • Page 8: Device Description

    DEVICE DESCRIPTION 2MP camera Status LEDs Power Programmable Keys Brightness / Volume Adjustment...
  • Page 9 HDMI (D.P. optional) USB 3.0 SIM Card Mic / Headset combo jack DC-IN Kensington lock RJ-45 SmartCard / CAC reader Micro SD Hot swappable battery pack Quick release SSD Docking connector...

  • Page 10: Replacing The Battery

    Removing the battery Attention Removing the battery while the tablet is still on will start the consumption of the secondary battery whose duration is 5 minutes. We recommend putting the tablet in suspension. Remove the battery 1. Press the button and slide the latch to the right to unlock the battery as shown in the image 2.
  • Page 11 INSERTING THE BATTERY Insert the battery 1. Insert the battery from the contact side. 2. Push down the opposite side slightly and slide the locking latches by pressing its respective button.

  • Page 12: Inserting Sim Y Micro-Sd Cards

    Inserting SIM & Micro-SD cards Attention: Your device may not have 4G Modem, depending on the configuration acquired. Inserting the mini SIM card The slot accepts only mini SIM cards. Insert the card into the SIM slot like shown in the picture on the next page. Inserting a SD card Insert the micro SD card into SD card slot.

  • Page 14: Configure Programmable Buttons

    configurar botones programables Attention: It may be necessary to deactivate the tablet mode In order to view background applications. Background applications Access the background applications section of Windows 10. Open app Open the “Quick menu” application (image 14.1). Configure buttons Once the menu is opened (image 14.2), you can configure the P1 / P2 buttons as well as the “Up”...
  • Page 15 Image 14.2...
  • Page 16 Av. Corts Catalanes, 5-7 08173 - Sant Cugat del Valles Barcelona - Spain https://www.thunderbook.eu...
